3. SPECIFICATIONS AND CONTROLS

3.1. HypotULTRA III Functional Specifications, 7620 and 7650
INPUT
Voltage
Frequency
Fuse
DIELECTRIC WITHSTAND TEST MODE
Output Rating
Output Adjustment
Ramp-HI
Charge-LO
Max and Min-Limit
AC Total Range 1:
AC Real Range 1:
14
115 / 230 VAC ± 10 %, automatically selected
50/60 Hz ± 5%
4 Amp 250V Slo-Blo
5 KV @ 30 mA AC
5 KV @ 10 mA DC for 7650 only
Range:
0 – 5000V DC for 7650 only
Resolution: 1 Volt
± (2% of setting + 5 volts)
Accuracy:
(Can be adjusted during operation. Disabled when key
lockout is active.)
12mA peak maximum, ON/OFF selectable
Range:
0.0 – 350.0µA DC or Auto set
0.000 – 9.999mA
Resolution: 0.001mA
Range 2: 10.00 – 30.00 mA
Resolution: 0.01 mA
± (2% of setting + 2 counts)
Accuracy:
0.000 – 9.999mA
Resolution: 0.001mA
Range 2: 10.00 – 30.00 mA
Resolution: 0.01 mA
± (3% of setting + 0.05mA) All Ranges
Accuracy:
PF > 0.1
V > 250VAC
0 – 5000V AC
