Operating Instructions – Alde Compact 3020 HE

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Compact 3020 HE and is the answer not in the manual?

Questions and answers

Related Manuals for Alde Compact 3020 HE

Summary of Contents for Alde Compact 3020 HE

  • Page 1 Operating Instructions – Alde Compact 3020 HE...

  • Page 2: Operating Instructions

    Care and maintenance Important information Warranty Cable connection between boiler and control panel Install an Alde Compact 3020 High Efficiency together with Truma AC and obtain fully automatic climate control (ACC). The panel already supports the automatic climate control function.

  • Page 3: The First Time The Heating System Is Started

    For installation guidelines, see the separate instructions. These instructions are approved for the Alde Compact 3020 boiler fitted in vehicles in accordance with CE 0402 no. SC0653-13 and have the E5 mark for installation in vehicles in accordance with R122 and R10. Installation and repairs may only be carried out by a specialist.

  • Page 4: Turning The Boiler On And Off

    D. Circulation pump. The symbol is NB. If an additional hot water tank 22°C displayed when the pump is in is installed (*Alde Flow part no. 3020 160) operation. 6°C and the panel is in more hot water E. Automatic start of the boiler.
  • Page 5 NB. If an additional hot water tank is installed and (*Alde Flow part no. 3020 161) the panel is in more hot water mode, the hot water function can then be in operation for longer than 30 minutes.
  • Page 6 *FULLY AUTOMATIC CLIMATE CONTROL (ACC) If a Truma AC is connected up to the Alde, then the ACC button is visible and it is possible to control ACC from the panel. This function makes it possible to have fully automated climate control for both heating, cooling and hot water.
  • Page 7 * Booster is on. However, it does not have to be within the time setting. High altitude mode is activated. * This function is used if *Alde Smart Con- trol is installed to control (part no. 3020 057) the boiler via a Smart Phone.

  • Page 8: Tools Menu

    7. TOOLS MENU The tools menu can be accessed from the settings menu. 1. The control panel showing the settings menu. Press the tool symbol to access the tools menu +22°C 1 kW TOOLS MENU – FUNCTIONS The following tools are available from the tools menu. A grey function button means the function has not been installed and/or activated in ”Installed Accesso- ries”, see section 11.
  • Page 9 This also 15. Offset (temperature adjustment) applies to Truma Comfort AC if connec- ted to the Alde 3020. Due to voltage fluc- If the temperature that is displayed in tuations and tolerances, different regula- the panel does not correspond to the tion levels can be selected (5-17 A).
  • Page 10 Turn the button sound on and off. • Audible signal on reaching hot The accessories that are installed are water temperature when Alde Flow* activated here (see section 11). is installed and more hot water is 24. Service menu. selected.

  • Page 11: Service Menu

    8. SERVICE MENU The Service menu is accessed by pressing Service (see fig. 1). The function shows the values from the boiler on the screen (fig. 2 and 3). The values are updated every second. Figure 1 Figure 2 Figure 3 Settings Service Service...
  • Page 12 Red connection fail: Problem with the red cable or red ports. There is no communication with the 3020 heater, AC or iNet. Yellow connection fail: Problem with the cable between the Alde panel and the CI master panel or its ports. iNet connection fail: Cannot find the INet box. Probably a problem with iNet. In the event of ”INet connection fail”, this button is displayed.

  • Page 13: Activation Of Installed Functions

    EisEx Engine Pre-Heat Pump The relevant box must be checked if you have: Connected a gas bottle changer Connected an external panel or Alde (DuoComfort or DuoControl). Smart Control (part no. 3020 057) Connected a defroster (EisEx). Connected an extra 12 V pump, often located in the expansion tank.

  • Page 14: Care And Maintenance

    The boiler must not be started if there is no glycol fluid in the system. Filling with glycol fluid. The system is filled through the expansion tank, either manually or using the Alde •...
  • Page 15 Opening manual Opening automatic safety valve/drain valve safety valve/drain valve Closed Open Fluid level Functions marked with a (*) are accessories, which are not installed on all vehicles, refer to the vehicle manufacturer’s instructions.

  • Page 16: Warranty

    • The ethylene glycol mixture should be changed every other year, as certain properties such as corro- sion protection deteriorate over time. If Alde Premium Antifreeze is used, the interval for changing the mixture can be extended to five years under normal operating conditions.
  • Page 17 15. CABLE CONNECTION COMPACT 3020 HE AND CONTROL PANEL 3020 HE Connect accessories to the boiler and control panel as shown in the diagram below. NB. Do not clamp 12 V cables or sensor cables together with 230 V cables.Do not position the cables close to one another.
  • Page 18 Alde International Systems AB Box 11066 • S-291 11 Färlöv • Sweden Tel: +46 (0)44 712 70 info@alde.se • www.alde.se...
