Quick start GuiDE - compact 3010
1. The standby and on-position of the

control panel

2. Start the heater
3. Switch off the heater
4. Set the temperature you want in
the vehicle
5. Warm water
Working with the lower menu row, see operating/installation instruction
for Compact 3010
1.
The standby and on-position of the control panel
In standby, the functions which are activated in the
boiler are shown, and there is no background lighting
in the display. The control panel automatically goes to
standby from the on position after two minutes if no
buttons are pushed or if you step to standby (left of
On/Off) with the arrow keys.
2. Start the heater
Start the heating in the caravan with the settings last
used.
1 Press the button with the arrow
until "Off" (main breaker) in the
display flashes.
blinkar
flashes
10. Temperature
11. Resetting the system
Start the on position by pressing any button.
The background lighting comes on (blue light) and
a function that can be set flashes. Select a function
that can be set with the arrow keys. The settings are
automatically saved.
If you break the power to the heater, the settings which
were last used will automatically be used when the
power comes back on.
2 Press the +/On button."On"
(main breaker) in the display
flashes.
blinkar
flashes
6. Heating with gas
7. Heating with electricity
8. Circulation pump
9. 230V connectiong
3 The settings are ready."On"
(main breaker) is shown in the
display when the panel returns to
standby.
GB
