Specifications

Input Power Requirements
Powered through CIM (NETCOM6P 140 mA + CIM 150 mA = 290 mA
Network
RJ45 (10/100 Base-T) Ethernet
LAN/ WAN (TCP/IP protocol—port 3001)
Agency Approvals—Ethernet Socket
Complies with Class B limits of EN 55022: 1998 Direct & Indirect ESD.
Complies with EN55024:1998
Dimensions
1 9/16" x 1 15/16" (41 mm x 49 mm)
Environmental
Suitable for industrial and commercial applications.
Operating temperatures: 5
Encryption
256 – bit AES Rijndael encryption
For more information on encryption, visit
http://www.bis.doc.gov/encryption/default.htm
http://www.bis.doc.gov/policiesandregulations/regionalconsiderations.htm
RJ45 Ethernet (Xport) LED States
Link LED (left side)
Amber – flashing
Green – flashing

Address Settings

*IP Address:
*Subnet Mask:
Gateway:
**Ethernet Connection Type:
*Encryption key
* Required fields for device configuration with software
** If other than Automatic Negotiation
Keyscan Inc. A Member of the Kaba Group
0 C to 70 0 C (41
10 Mbps
100 Mbps
Keyscan Inc.
901 Burns St., E. Whitby, Ontario, Canada L1N 0E6
1.888.539.7226 (toll free Canada/USA)
905.430.7226 (elsewhere)
www.keyscan.ca
Technical Support
Hours – 9:00 A.M. to 6:30 P.M. Eastern Time
NETCOM6P/CIM -RN Installation Guide (PC109x – 07.15)
0 F to 158 0 F)
Activity LED (right side)
Amber – flashing
Green – flashing
Half-duplex
Full-duplex
