Steps to Set IP Address on Control Board ...cont'd
14. As an option, you can set a secondary IP address and/or set an override port number
as outlined below provided they have been specified by the host location; otherwise
go to step 17.
 To set a secondary IP address, select 2) Set Secondary IP Address and enter a
secondary IP address. You must have entered a primary IP address, otherwise
the secondary address will not be used if a primary IP address is non-existent. If
not entering a different secondary address, Keyscan recommends entering the
primary IP address in the secondary location.
 To set a port number which is an override to the Reverse Network Port Number
programmed into the NETCOM6P, select 5) Set Port Number and enter a valid
port. This override port can also be entered in the Keyscan Client software.
15. When you have completed the ACU programming, select 9) Exit.
16. Exit HyperTerminal and close the NETCOM Program Tool Utility.
17. Disconnect the serial programming cable wires from the Communication terminal
block—TB4 on the control board and from the PC/laptop.
18. Go to the next set of instructions—Configure the Control board and CIMs.
