NETCOM6P Operational Connections
Figure 9 and Figure 10 illustrate NETCOM6P operating connections via CIM 0. Refer to the
CIM Guide for complete instructions on setting up and installing CIMs.
Host PC with
Communication
to
network
Bit Rate / Distance
Bit CAN Bus
9600 3280' (999.7 m)
19200* 3280' (999.7 m)
57600 984' (299.9 m)
115200* 262' (80 m)
* not applicable for reverse
network communication
to
network
or
router
KI-00259E-07-12
NETCOM6P/CIM - RN Installation Guide
Figure 9 – NETCOM6P Mounted on CIM 0
Manager
Control Board
(PC 109x)
17 18 19 20
Common AUX Inputs - E
V +
(+12V)
GND
COM1
GND
10 or 100 Base T
TD1
RD1
RTS
NETCOMP
CTS
COM2
GND
Standoff
TD2
- correct
mounting
RD2
orientation
RTS
CTS
CIM
H2 H1
21 22 23 24
HDR1
U2
RJ45
Terminal
Jack
J1
SCKT1
NETCOMP
Standoffs
PC106x
Current Draw - CIM 150 mA + NETCOMP 140 mA = 290mA
Parts List
- RS-232 Data Cable
- Control Board
- PC with network connection
- CIM
- NETCOM2P or NETCOM6P
- 10/100 Base-T Cable
Connect ribbon cable from
HDR1 on CIM to H2 terminal
on control board.
Note - ensure the NETCOMP version is
a PC1051 or later printed circuit board.
The CIM is not compatible with older
NETCOMP versions.
J7
CAN2
J8
J5
CAN1
J6
CIM 0
RESET
J1
Jumper ON
B3 B2 B1 B0
1 2 1 2 1 2 1 2
COM CAN-Tx
Rx-COM CAN
See CIM to CIM
Connections
diagram.
-
CAN2
+
EGND
-
CAN1
+
J4
J10
J4
J11
J9
J3
Diag
J12
Power
Good
J2
Fault
