BARTEC
Integration Manual
MC9000ex – Series
Mobile Computer MC92NOex
RuBee
Sheett 1/7

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MC9000ex Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Bartec MC9000ex Series

  • Page 1 BARTEC Integration Manual MC9000ex – Series Mobile Computer MC92NOex RuBee Sheett 1/7...
  • Page 2 BARTEC Integration Manual 1. Table of contents TABLE OF CONTENTS ..................... 2 ASSEMBLY BOTTOM HOUSING ................3 RFID/R ..................... 3 EE EXTERNAL RICK RFID/R ....................... 4 EE EXTERNAL INSTALLATION RUBEE READER EXTERNAL (BRICK/GUN) ........ 5 Sheett 2/7...
  • Page 3 BARTEC Integration Manual 2. Assembly bottom housing RFID/RuBee external Brick Drill 7 holes (1,0mm) and 4 holes (5,5mm) with the fixture in the lower housing. Press 4 inserts into the big holes. Lead the 7 wires (each with different colour) through the drillings.
  • Page 4 BARTEC Integration Manual Seal the screw heads and the wire openings with Sikaflex. Seal accomplished wires and inserts with Sikaflex. RFID/RuBee external Gun Drill 7 holes (1,0mm ) and 4 holes (5,5mm) with the fixture in the lower housing. Press 4 inserts into the big holes.
  • Page 5 BARTEC Integration Manual Fix the RFID lower housing with 4 screws and 4 washers with the top housing of the mobile computer. Seal the screw heads and the wire openings with Sikaflex. Seal accomplished wires and inserts with Sikaflex. 3. Installation RuBee Reader external (Brick/Gun) Cut the antenna pins of the housing.
  • Page 6 BARTEC Integration Manual Solder appropriate wires on RuBee Reader as shown in the picture and fix them with UV glue. Position the reader on the according 4 pins and glue with UV glue. Apply Sikaflex in the sealing area of the housing.
  • Page 7 BARTEC Integration Manual Lock the opening with the according cover. Sheett 7/7...
