Related Manuals for Bartec MC 9190ex-NI
Summary of Contents for Bartec MC 9190ex-NI
- Page 1 ATEX Zone 2 UL Division 2 Mobile Computing User Manual Mobile Computer MC 9190 -NI, Type B7-A28.-../..Document No. B1-A280-7D0001 Issue: April 2011...
- Page 3 Contents Page English 1 - 50 Appendix Declaration of Conformity Certificate of Compliance GmbH Max-Eyth-Straße 16 Phone: +49 7931 597-0 Contact: 97980 Bad Mergentheim Fax: +49 7931 597-119 info@bartec.de Germany...
- Page 4 - blank -...
- Page 5 BARTEC reserves the right to alter the contents of this document without notice. No guarantee is given for the correctness of the information. In the event of a legal dispute, the “General Terms and Conditions” of the BARTEC group shall apply in addition.
- Page 6 In the event of information overlap, the information in this User Manual is valid and replaces the Motorola information. Documentation Set BARTEC User manual for the MC 9190 -NI mobile computer series −...
- Page 7 Mobile Computer MC 9190 General Type B7-A28.-………… The current version of the Motorola documentation is available at: − http://www.motorola.com/enterprisemobility/manuals For Software Installation and Adjustment Possibilities refer to the Symbol/Motorola manual: http://www.supportcentral.motorola.com under: - Support - Get Product Manuals - Product Manuals - Mobile Computers - MC 9190-G Safety Instructions Safety instructions and warnings are specially highlighted in this manual and marked by...
- Page 8 Mobile Computer MC 9190 General Type B7-A28.-………… Configurations This user manual refers to the following configurations: Confi- Data acquisition Key- Wireless Display Memory guration option 1D Laser scanner Standard Range 1D Laser scanner WLAN: Long Range 802.11 a/b/g MC 9190 1D /2D WPAN: Standard Range...
- Page 9 blank -...
-
Page 10: Table Of Contents
Mobile Computer MC 9190 Contens Type B7-A28.-………… Product Description ......................1 Definition ........................1 Use ..........................2 Technical Data ........................3 Explosion Protection ATEX Zone 2/22................ 3 Explosion Protection UL Division 2 ................3 Characteristics ......................3 Performance Features ....................4 User Environment ....................... - Page 11 Mobile Computer MC 9190 Contents Type B7-A28.-………… Operation ..........................20 Getting started ......................20 Recommended position for the MC 9190 -NI ............20 Parts of the MC 9190 -NI ..................21 Battery ........................21 4.4.1 Battery information..................22 4.4.2 Installing the Battery ................... 22 4.4.3 Replacing a battery ..................
- Page 12 Mobile Computer MC 9190 Contens Type B7-A28.-………… Maintenance, Inspection, Repair ..................41 Servicing ........................42 Inspection ......................... 42 Cleaning ........................42 8.3.1 Required materials..................43 8.3.2 Housing ...................... 43 8.3.3 Display ......................43 8.3.4 Scan window ....................44 8.3.5 Interface connection ................... 44 8.3.6 Cradle/Battery contacts ................
-
Page 13: Product Description
Mobile Computer MC 9190 Product Description Type B7-A28.-………… Product Description Definition The MC 9190 -NI Mobile Computer is a compact unit for high-standard barcode scanning in hazardous (potentially explosive) areas. ATEX Zone 2 and 22 − Class I, II, III Division 2 −... -
Page 14: Use
Enterprise Mobility Developer Kits (EMDK) from Motorola. 256 MB RAM and 1 GB flash drive integrated in the device are available for storing user- defined applications and data. For larger applications and volumes of data, BARTEC offers SD memory cards. -
Page 15: Technical Data
Mobile Computer MC 9190 Technical Data Type B7-A28.-………… Technical Data Explosion Protection ATEX Zone 2/22 Type B7-A283-…./…….. Ex protection II 3G Ex nA IIC T6 II 3D Ex tD A22 IP54 T80 °C Ambient temperature -20 °C ≤ Ta ≤ +50 °C Temperature Code Certification B1-A283-7C0001... -
Page 16: Performance Features
Mobile Computer MC 9190 Technical Data Type B7-A28.-………… No emulation software is installed on the Mobile Computers with the emulation key version. The customer must order the emulation software separately from Symbol/Motorola and its distributors and install it himself. The devices are modified to suit the selected keypad version. The end user can replace Note the keypad later himself. -
Page 17: Voice And Data Transmission Wireless Lan
Mobile Computer MC 9190 Technical Data Type B7-A28.-………… More tools are available from Rem Capture for processing registry files. − Motorola for the devices Application Launcher dividing − e.g. applications into categories and access regulation to the individual applications or operating system. -
Page 18: Se1524-Er 1D Long Range Scan Engine
Mobile Computer MC 9190 Technical Data Type B7-A28.-………… For decode zone and more detailed information of the scan engine look into the Integrator Guide of Motorola. Note 2.9.1 SE1524-ER 1D Long Range Scan Engine Reading range up to approx. 13.7 m up to approx. -
Page 19: Decodable Bar Code Types
Mobile Computer MC 9190 Technical Data Type B7-A28.-………… 2.9.5 Decodable Bar Code Types Laser Decode Capability MC 9190 -NI with SE1524-ER 1D Long Range Scan Engine 1D code Code 39 Code 128 Code 93 Codabar Code 11 Discrete 2 of 5 Interleaved 2 of 5 EAN-8 EAN-13... -
Page 20: Technical Data Battery
Mobile Computer MC 9190 Technical Data Type B7-A28.-………… 2.10 Technical Data Battery The battery may only be charged and changed outside the hazardous area! Caution! Battery type B7-A2Z0-0006 Lithium ions 7.4 V/2200 mAh Operating temperature 0 °C to +40 °C 32 °F to 104 °F during charging −... -
Page 21: Product Marking
Mobile Computer MC 9190 Technical Data Type B7-A28.-………… 2.12 Product Marking MC 9190 CAUTION - CLASS 3R LASER LIGHT WHEN OPEN. AVOID DIRECT EYE EXPOSURE. ATTENTION - LUMIÈRE LASER DE CLASSE 3R, EN CAS D’OUVERTURE. EXPOSITION DANGEREUSE AU FAISCEAU. Warning Laser VORSICHT - LASERLICHT KLASSE 3R, WENN ABDECKUNG GEÖFFNET. - Page 22 Mobile Computer MC 9190 Technical Data Type B7-A28.-………… Battery Type B7-A2Z0-0006 Type Label Technical data subject to change without notice. Page 10 of 50 Issue: Revision 2 / August 2012...
-
Page 23: Safety Instructions
Mobile Computer MC 9190 Safety Instructions Type B7-A28.-………… Safety Instructions Warnings about the Mobile Computers The device may not be opened by the user outside the hazardous area either! The user may not make any alterations to the device. Do not exchange or replace components Caution! and do not retrofit any components on internal plug connectors or slots. -
Page 24: Warnings For Battery
Mobile Computer MC 9190 Safety Instructions Type B7-A28.-………… Equipment that is damaged in any way or that does not function properly must − instantly be removed from the hazardous area and sent in for inspection/repair! Take the device out of the hazardous areas before wiping it with a dry cloth or −... -
Page 25: Laser Devices
LED Devices Complies with IEC/EN60825-1:2001 & IEC/EN60247:2006 Health and Safety Recommendations Use only the accessories, batteries and battery chargers approved by BARTEC. Do not attempt to charge damp/wet MC 9190 -NI or batteries. All components must be dry Caution! before they are connected to an external power supply. -
Page 26: Installation In Vehicles
Mobile Computer MC 9190 Safety Instructions Type B7-A28.-………… Provide adjustable tables and chairs. − Ensure sufficient clearance for easy movement − Provide a suitable working environment − Optimise work procedures − Alternate hands as often as possible when doing repetitive tasks. −... -
Page 27: Rf Exposure Guidelines
3.6.2 Europe Handheld Devices This device was tested for typical body-worn operation. Use only BARTEC tested and approved belt-clips, holsters, and similar accessories to ensure EU Compliance. The MC 9190 -NI must be switched off before it may be carried on the body. -
Page 28: Us And Canada
Handheld Devices This device was tested for typical body-worn operation. Use only BARTEC tested and approved belt-clips, holsters, and similar accessories to ensure FCC Compliance. The use of third-party belt-clips, holsters, and similar accessories may not comply with FCC RF exposure compliance requirements, and should be avoided. - Page 29 Mobile Computer MC 9190 Safety Instructions Type B7-A28.-………… Frequency of Operation – FCC and IC 5 GHz Only The use in the UNII (Unlicensed National Information Infrastructure) band 1 5150 - 5250 MHz band is restricted to Indoor Use Only; any other use will make the operation of this device illegal.
-
Page 30: Warnings About The Use Of Wireless Devices
Mobile Computer MC 9190 Safety Instructions Type B7-A28.-………… Requirements for protection from radio-frequency interference – Canada This class B digital device complies with the guidelines in the Canadian standard ICES-003. Cet appareil numérique de la classe B est conforme à la norme NMB-003 du Canada. Radio Transmitters for RLAN Devices The use of 5 GHz RLAN’s, for use in Canada, have the following restrictions: Restricted Band 5.60 –... -
Page 31: Safety In Hospitals
Mobile Computer MC 9190 Safety Instructions Type B7-A28.-………… 3.8.2 Safety in Hospitals Wireless devices radiate radio frequencies and can cause interference in electrical medical devices. If you are in a hospital, clinic or public health service, please turn off wireless devices if asked to do so. This is to prevent any interference with sensitive medical equipment. -
Page 32: Operation
Mobile Computer MC 9190 Operation Type B7-A28.-………… Operation Before assembling the device, make sure you have all the components and documents. Scope: 1 x MC 9190 1 x Lithium-ion battery 1 x Strap assembly 1 x Protective overlay on the display window 1 x Stylus 1 x User manual The safety and accident prevention regulations relevant to the respective application... -
Page 33: Ex -Ni
The temperature range for charging the battery is 0 °C to +40 °C. Use only accessories approved by BARTEC and Motorola to charge the batteries. Note Technical data subject to change without notice. -
Page 34: Battery Information
Batteries must be charged within the 0° to +40 °C (32° to 104° F) temperature range. Standard warranty period for all BARTEC batteries is 1 year, regardless of whether the battery was purchased separately or included as part of the Mobile Computer. -
Page 35: Replacing A Battery
Mobile Computer MC 9190 Operation Type B7-A28.-………… 4.4.3 Replacing a battery The battery may only be charged and changed outside the hazardous area! It must be ensured that only original batteries of the following type/s are used in safety- oriented operation. B7-A2Z0-0006 with 7.4 V/2200 mAh Caution! The use of imitation batteries or batteries from other manufacturers will render the type of ignition protection ineffective and there will then be a risk of fire or explosion. -
Page 36: Charging The Battery
Mobile Computer MC 9190 Operation Type B7-A28.-………… 4.4.4 Charging the battery Before using the MC 9190 -NI for the first time, charge the main battery until the amber charge indicator light remains lit (see Table 4-1: Charging indications). The main battery fully charges in less than four hours. - Page 37 Charge the main battery Note that battery type B7-A2Z0-0006 with 7.4 V/2200 mAh may only be charged outside the hazardous area. Use only accessories approved by BARTEC. Do not attempt to charge damp/wet Mobile Computers or batteries. All components must be dry before Note they are connected to an external power supply.
- Page 38 Charge battery separately or a spare batteries Note that battery type B7-A2Z0-0006 with 7.4 V/2200 mAh may only be charged outside the hazardous area. Use only accessories approved by BARTEC. Do not attempt to charge damp/wet Mobile Computers or batteries. All components must be dry before Note they are connected to an external power supply.
- Page 39 Mobile Computer MC 9190 Operation Type B7-A28.-………… 7. Insert the MC 9190 -NI into a cradle or attach the appropriate snap-on module. 8. The MC 9190 -NI starts to charge automatically. The amber charge LED, in the Indicator LED Bar, lights to indicate the charge status. See Table 4-1: Charging indications.
-
Page 40: Keypad
Mobile Computer MC 9190 Operation Type B7-A28.-………… Keypad 4.5.1 Replacing Keypad The MC 9190 -NI has interchangeable modular keypads. The keypad may only be changed outside the hazardous area! − It must be ensured that only original keypads are used in safety-oriented operation. −... - Page 41 Do not apply more than 0.452 NM or 4 in-lbs of torque when tightening the keypad screws. Caution! After the exchange of the keyboard a cold boot (see chapter 7.2 “Resetting the MC 9190ex-NI”) must be performed. Note The current drivers are installed on the unit and initialized automatically by the cold boot.
-
Page 42: Secure Device (Sd) Card
Secure Device (SD) Card The SD card may only installed and replaced outside of the hazardous area! Only SD cards tested by BARTEC for that purpose may be used in the slot. Caution! The SD card slot provides secondary non-volatile storage. The slot is located under the keypad. -
Page 43: Screen Protector
Do not use any sharp object to remove the screen protector. This could damage the display. Attention! You can order screen protector from your customer consultant or from BARTEC. Installation instructions for the screen protector are part of the delivery scope. Part Note number: 17-A1Z0-0003 screen protector, pack of 5. -
Page 44: Removing The Screen Protector
Do not use any sharp object to remove the screen protector. This could damage the display. Attention! You can order screen protector from your customer consultant or from BARTEC. Installation instructions for the screen protector are part of the delivery scope. Part Note number: 17-A1Z0-0003 screen protector, pack of 5. -
Page 45: Connection To The Pc
Mobile Computer MC 9190 Operation Type B7-A28.-………… Connection to the PC The MC 9190 -NI series is delivered with a Microsoft WM 6.5 operating system or follow- up version. Microsoft supplies software free of charge to establish a connection to a PC for synchronisation, installation and data exchange. -
Page 46: Commissioning
Mobile Computer MC 9190 Trouble Shooting Type B7-A28.-………… Commissioning The operator of an electrical system in a hazardous environment must keep the operating equipment in an orderly condition, operate it correctly, monitor it and do the required maintenance and repairs. Before commissioning the MC 9190 -NI, check that all components and documents are there. -
Page 47: Software Versions
Mobile Computer MC 9190 Software Versions Type B7-A28.-………… Software Versions This user manual various software configurations and references are made to operating system or software versions for: Adaptation Kit Update (AKU) version − OEM version − BTExplorer version − Fusion version −... -
Page 48: Trouble Shooting
− MC9190-G − Click on “More” for a complete list. − If you have problems with your device, please contact the BARTEC sales company or commercial representation responsible for your region. You can find contact information under: http://www.bartec.de/homepage/eng/10_unternehmen/10_unternehmen/s_10_10_50.asp?C=1 Battery Management... -
Page 49: Changing The Backlight Settings
Mobile Computer MC 9190 Trouble Shooting Type B7-A28.-………… 7.1.2 Changing the Backlight Settings To change the display backlight settings in order to conserve more battery power: 1. On devices with Windows Mobile 6.5, tap Start > Settings > System > Backlight > Battery Power. -
Page 50: Turning Off The Radios
Mobile Computer MC 9190 Trouble Shooting Type B7-A28.-………… 7.1.5 Turning Off the Radios Wireless connection options vary depending upon configurations. Note 7.1.6 On Devices with Mobile 6.5 Windows Mobile 6.5 devices include Wireless Manager, which provides a simple method of enabling, disabling, and configuring all the device’s wireless capabilities in one place. 1. -
Page 51: Resetting The Mc 9190 Ex -Ni
Mobile Computer MC 9190 Trouble Shooting Type B7-A28.-………… Resetting the MC 9190 There are several reset functions, warm boot, cold boot and clean boot. A warm boot restarts the MC 9190 -NI by closing all running programs. − A cold boot also restarts the MC 9190 -NI, but erases all stored records and entries −... -
Page 52: Clean Boot
Mobile Computer MC 9190 Trouble Shooting Type B7-A28.-………… To perform a cold boot: 1. Press the primary battery release on the MC 9190 -NI to partially eject the battery from the MC 9190 -NI. (described in chapter 4.4.3 Replacing a battery) 2. -
Page 53: Maintenance, Inspection, Repair
-NI use the supplied stylus or pens with plastic tip which are designed for use with touch screens. Never use a ballpoint pen, pencils or other pointed items on the MC 9190 -NI screen. BARTEC recommends using a screen protector, Part no. 17-A1Z0-0003. The touch-sensitive screen of the MC 9190 -NI contains glass. -
Page 54: Servicing
The relevant applicable regulations must be observed. Caution! Please direct any questions you may have to BARTEC GmbH. Cleaning If you wish to clean the MC 9190 -NI or components, take the device out of the Ex area first before you start any cleaning measures. -
Page 55: Required Materials
Mobile Computer MC 9190 Maintenance, Inspection, Type B7-A28.-………… Repair Approved Cleanser Active Ingredients 100% of the active ingredients in any cleaner must consist of one or some combination of the following: isopropyl alcohol, bleach/sodium hypochlorite, hydrogen peroxide or mild dish soap. Harmful Ingredients The following chemicals are known to damage the plastics on the MC 9190 -NI and... -
Page 56: Scan Window
Maintenance, Inspection, Mobile Computer MC 9190 Repair Type B7-A28.-………… 8.3.4 Scan window Wipe the scanner exit window periodically with a lens tissue or other material suitable for cleaning optical material such as eyeglasses. 8.3.5 Interface connection Remove the main battery from the MC 9190 -NI. -
Page 57: Cleaning Interval
Mobile Computer MC 9190 Maintenance, Inspection, Type B7-A28.-………… Repair Cleaning the charging station plug-connectors This is how you clean the plug-connectors of a charging station: Separate the DC power supply cable from the charging station. Dip the end of a cotton bud in Isopropyl. Rub over the contacts of the plug-connector(s) with the tip of the cotton bud. -
Page 58: Information About Repairs
Repair Type B7-A28.-………… Information about Repairs Customer Service Information If you have problems with your device, please contact the BARTEC sales company or commercial representation responsible for your region. You can find contact information under: http://www.bartec.de/homepage/eng/10_unternehmen/10_unternehmen/s_10_10_50.asp?C=1 Please have the following information available when you contact BARTEC: Serial number of the device (you can find this on the manufacturer label) −... -
Page 59: Accessories
Mobile Computer MC 9190 Accessories Type B7-A28.-………… Accessories Accessories for use in hazardous area Technical data subject to change without notice. Page 47 of 50 Issue: Revision 2 / August 2012... -
Page 60: Accessories For Use In Non Hazardous Area
Mobile Computer MC 9190 Accessories Type B7-A28.-………… Accessories for use in non hazardous area Technical data subject to change without notice. Page 48 of 50 Issue: Revision 2 / August 2012... -
Page 61: Order Numbers
Mobile Computer MC 9190 Additional Information Type B7-A28.-………… Order Numbers 10.1 MC 9190 Disposal The component of the Mobile Computers contains metal, plastic parts and electronic components. The statutory requirements for electrical scrap must be observed therefore (e.g. disposal by an approved disposal company). Dispatch and Packaging Instructions Important information regarding transport and dispatch ! Sensitive Devices! -
