Bartec TC78ex-NI Quick Start Manual

Touch computer
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Touch Computer TC78
-NI
ex
Quick Start Guide

Advertisement

Table of Contents
loading

Related Manuals for Bartec TC78ex-NI

Summary of Contents for Bartec TC78ex-NI

  • Page 1 Touch Computer TC78 Quick Start Guide...
  • Page 3 Status: October 2023 Proviso: Subject to technical changes. Changes, mistakes and printing errors do not substantiate any claim to damages. Content Pages English 1-52 BARTEC GmbH Max-Eyth-Straße 16 Fon: +49 7931 597-0 Support: em-support@bartec.com 97980 Bad Mergentheim Fax: +49 7931 597-119 Download: http://automation.bartec.de...

  • Page 5: Table Of Contents

    TC78 - Touch Computer Table of content Type B7-A2D*-****/******** Basic safety information ........................1 Information on this Quick Start Guide ................1 1.1.1 Languages ........................2 1.1.2 Changes in the document ....................2 1.1.3 Registered trademarks ..................... 2 Handling the product ......................2 Intended use ........................
  • Page 6 TC78 - Touch Computer Table of content Type B7-A2D*-****/******** Product description ..........................17 TC78 -NI ........................17 Purpose of use ....................... 17 Structure .............................. 18 Technical data ............................. 20 Explosion protection ....................... 20 Features ......................... 22 5.2.1 Performance features ..................... 22 5.2.2 Physical features ......................

  • Page 7: Basic Safety Information

    The BARTEC company reserves the right to carry out technical changes at any time. In no event will BARTEC company be responsible or liable for indirect or consequential damages resulting from the use or application of this Quick Start Guide.

  • Page 8: Languages

    1.1.2 Changes in the document BARTEC reserves the right to change the content of this document without notification. No warranty is assumed for the correctness of the information. In cases of doubt, the German safety instructions apply because it is not possible to rule out errors of translation or printing.

  • Page 9: Intended Use

    TC78 - Touch Computer Basic safety information Type B7-A2D*-****/******** Intended use 1.3.1 Exclusive purpose The Touch Computer series is a handheld piece of electrical equipment. It serves the purpose of the mobile recording, processing and/or radio transmission of data within potentially explosive atmospheres.

  • Page 10: Maintenance

    Repairs to explosion-protected devices may only be performed by authorised personnel with original spare parts and according to the state of the art. Therfore all repairs to the Touch Computer have to conducted by BARTEC. Contact information and instructions for repair requests and processing can be found at: https://bartec.com/service-support/returns-repair...

  • Page 11: Warranty

    The information contained herein refers to the explosion-protected version of the Touch Computer TC78 -NI. This Quick Start Guide contains all important information on the subject of explosion protection. Further product information on handling and commissioning can be found on the BARTEC support page: https://automation.bartec.de/indexE.htm Subject to technical changes. 5/52...

  • Page 12: Co-Applicable Documents

    Co-applicable documents All documents are available online from the following websites: BARTEC: www.bartec.com or http://automation.bartec.de/indexE.htm ZEBRA: www.zebra.com In the event of an overlaps with Zebra, the instructions of BARTEC apply. Document BARTEC Explanation Quick Start Guide This Quick Start Guide describes the safety-...

  • Page 13: Configuration

    6“Color Display with 2160 x 1080 Pixel resolution Memory 4 GB Mass storage 64 GB The TC78 -NI is delivered by BARTEC according to the Operating system currently available Android version. (Details see data sheet) 5G/4G/3G/2G WLAN IEEE 802.11 a/b/g/n/ac/d/h/i/r/k/v/w/mc/ax Bluetooth Klasse 2, Bluetooth v5.2...

  • Page 14: Regulatory Information

    Type B7-A2D*-****/******** Regulatory information All BARTEC devices are designed to be compliant with the rules and regulations in locations they are sold and will be labeled as required. Any changes or modifications to BARTEC equipment, not expressly approved by BARTEC, could void the user’s authority to operate the equipment.

  • Page 15: Restricted Use Locations

    Reducing RF Exposure – Use Properly The device complies with internationally recognized standards covering human exposure to electromagnetic fields. Use only BARTEC tested and approved accessories to ensure RF exposure compliance. To satisfy RF exposure requirements, this device must operate with a minimum separation distance of 1.5 cm or more from a user's body and nearby persons.

  • Page 16: Optical Devices

    TC78 - Touch Computer Regulatory information Type B7-A2D*-****/******** Optical devices 2.3.1 Laser Class 2 laser scanners use a low power, visible light diode. As with any very bright light source such as the sun, the user should avoid staring directly into the light beam. Momentary exposure to a Class 2 laser is not known to be harmful.

  • Page 17: Power Supply

    Standard battery – Type B7-A2Z0-0088/**** (3.85 V / 4680 mAh) Extended battery – Type B7-A2Z0-0089 (3.85 V / 7000 mAh) BARTEC approved rechargeable battery packs are designed and constructed to the highest standards within the industry. However, there are limitations as to how long a battery can operate or be stored before needing replacement.

  • Page 18: Battery Safety Guidelines

    TC78 - Touch Computer Regulatory information Type B7-A2D*-****/******** 2.5.2 Battery Safety Guidelines IMPORTANT – SAFETY INSTRUCTIONS – SAVE THESE INSTRUCTIONS WARNING When using this product basic safety precautions should always be followed, including the following: The area in which the units are charged should be clear of debris and combustible materials or chemicals.

  • Page 19: United States And Canada Regulatory

    TC78 - Touch Computer Regulatory information Type B7-A2D*-****/******** To reduce the risk of injury, close supervision is necessary when used near  children. Please follow local regulations to promptly dispose of used re-chargeable  batteries. Do not dispose of batteries in fire. Exposure to temperatures over 100°C (212°F) ...

  • Page 20: Radio Frequency Interference Requirements - Canada

    TC78 - Touch Computer Regulatory information Type B7-A2D*-****/******** 2.6.2 Radio Frequency Interference Requirements – Canada Innovation, Science and Economic Development Canada ICES-003 Compliance Label: CAN ICES-003(B)/NMB-003(B) This device complies with Innovation, Science and Economic Development Canada’s licence-exempt RSSs. Operation is subject to the following two conditions: (1) This device may not cause interference;...

  • Page 21: Use With Hearing Aids - Fcc

    TC78 - Touch Computer Regulatory information Type B7-A2D*-****/******** 2.6.4 Use with Hearing Aids – FCC When some wireless devices are used near some hearing devices (hearing aids and cochlear implants), users may detect a buzzing, humming, or whining noise. Some hearing devices are more immune than others to this interference noise, and wireless devices also vary in the amount of interference they generate.

  • Page 22: Ul Listed Products With Gps

    GPS de ce produit. United Kingdom Statement of Compliance BARTEC hereby declares that this radio equipment is in compliance with the Radio Equipment Regulations 2017 and the Restriction of the Use of Certain Hazardous Substances in Electrical and Electronic Equipment Regulations 2012.

  • Page 23: Product Description

    The TC78 -NI is a tough Touch Computer with 4.7" color display, which has been designed for use in the industrial environments and especially developed by BARTEC in close cooperation with ZEBRA for use in potentially explosive atmospheres. Purpose of use The Touch Computer TC78 -NI are handheld electrical devices.

  • Page 24: Structure

    TC78 - Touch Computer Structure Type B7-A2D*-****/******** Structure Takes photos and videos. Front camera (8MP) Indicates data capture status. Scan LED Use for audio playback in Handset mode. Receiver Proximity/light Determines proximity and ambient light for controlling display backlight intensity. sensor Indicates battery charging status while charging and application- Battery status LED...
  • Page 25 TC78 - Touch Computer Structure Type B7-A2D*-****/******** Turns the display on and off. Press and hold to reset the device, to Power button power it off, or to swap the battery. Use for noise cancellation. Microphone Provides host communications, audio, device charging via cables, and Back common I/O 8 pins accessories.

  • Page 26: Technical Data

    TC78 - Touch Computer Technical data Type B7-A2D*-****/******** Technical data Explosion protection ATEX Zone 2 / Zone 22 Type B7-A2D3-*B**/******** TC78 Labelling II 3G Ex ic op is IIC T4 Gc II 3D Ex ic op is IIIC T135 °C Dc IP64 -20 °C ≤...
  • Page 27 TC78 - Touch Computer Technical data Type B7-A2D*-****/******** X - labelling (special conditions of use for secure operation within the potentially explosive atmosphere) The battery may only be replaced or charged outside potentially explosive atmospheres. Only use battery with type B7-A2Z0-0088/**** or B7-A2Z0-0089 for the TC78 -NI.

  • Page 28: Features

    Type B7-A2D*-****/******** Features 5.2.1 Performance features Qualcomm 6490 Octa-Core, 2.7 GHz Operating system The TC78 -NI is delivered by BARTEC according to the currently available Android version. (Details see data sheet) Android Enterprise Certified AER by Zebra Google Recommended (AER) Memory 4 GB RAM;...

  • Page 29: User Environment

    TC78 - Touch Computer Technical data Type B7-A2D*-****/******** 5.2.3 User environment Operating temperature -20 °C to +50 °C ( -4 °F to +122 °F) Charging temperature 0 °C to +40 °C (+32 °F to +104 °F) Storage temperature -40 °C to +70 °C (-40 °F to +158 °F) (without battery) Relative humidity...
  • Page 30 TC78 - Touch Computer Technical data Type B7-A2D*-****/******** Certifications Wi-Fi Alliance Certifications: Wi-Fi CERTIFIED n; Wi-Fi CERTIFIED ac; Wi-Fi CERTIFIED 6; Wi-Fi Enhanced Open; WPA2-Personal; WPA2- Enterprise; WPA3-Personal; WPA3-Enterprise (includes 192-bit mode); Protected Management Frames; Wi-Fi Agile Multiband; WMM; WMM-Power Save; WMM-Admission Control;...

  • Page 31: Voice And Data Transmission Wan

    TC78 - Touch Computer Technical data Type B7-A2D*-****/******** 5.2.5 Voice and data transmission WAN The available radio frequency bands depend on the device configuration. Radio frequency band North America: 5G FR1: n2, 5, 7, 12, 13, 14, 25, 26, 29, 38, 41, 48, 66, 71, 77, 78 4G: B2, 4, 5, 7, 12, 13, 14, 17, 25, 26, 29, 38, 41, 48, 66, 71...

  • Page 32: Nfc/Hf Rfid Reader

    TC78 - Touch Computer Technical data Type B7-A2D*-****/******** 5.2.8 NFC/HF RFID Reader NFC/HF RFID is a short-range wireless connectivity technology standard that enables secure transaction between a reader and a contactless smartcard. The technology is based on ISO/IEC 14443 type A and B (proximity) and ISO/IEC 15693 (vicinity) standards, using the HF 13.56 MHz unlicensed band.

  • Page 33: Battery

    TC78 - Touch Computer Technical data Type B7-A2D*-****/******** Battery The life of the battery will depend on different use factors and the device settings, e.g.:  Use and setting of WLAN/Bluetooth Background lighting/screensaver  The settings in power management  Use and setting of scanner ...

  • Page 34: Product Labelling

    TC78 - Touch Computer Technical data Type B7-A2D*-****/******** Product labelling 5.4.1 Touch Computer Laser warning Marking B7-A2D3-*B**/******** Marking B7-A2D2-*A**/******** Subject to technical changes. 28/52 October 2023...
  • Page 35 TC78 - Touch Computer Technical data Type B7-A2D*-****/******** Type label B7-A2D3-*B**/******** Type label B7-A2D2-*A**/******** Subject to technical changes. 29/52 October 2023...

  • Page 36: Battery

    TC78 - Touch Computer Technical data Type B7-A2D*-****/******** 5.4.2 Battery Battery marking Type B7-A2Z0-0088/0001 Subject to technical changes. 30/52 October 2023...

  • Page 37: Transport And Storage

     Additional information on the batteries The batteries of BARTEC (Type B7-A2Z0-0088/**** and Type B7-A2Z0-0089) are developed and manufactured in accordance with the highest industrial standards. The operating time or storage period of a battery is restricted, however. The actual life of a battery is influenced by different factors, e.g.

  • Page 38: Commissioning

    TC78 - Touch Computer Commissioning Type B7-A2D*-****/******** Commissioning DANGER Avoid electrostatic charging in potentially explosive atmosphere. Danger to life in explosive atmosphere! Do not dry wipe or clean the devices.  Wear suitable clothing and shoes.  Do not use rubber gloves or similar. ...
  • Page 39 Accessories Only install or replace accessories outside the potentially explosive atmosphere.  User accessories exclusively which have been tested or certified by BARTEC for  this purpose. The end user can replace the Battery, MicroSD card, Nano SIM cards, Scan ...

  • Page 40: First Steps

    TC78 - Touch Computer Commissioning Type B7-A2D*-****/******** First steps Unpack the Touch Computer.  Insert and charge the battery into the Touch Computer.  charge the battery and then insert it into the Touch Computer. Use one of the following accessories to charge: Charging process Battery Description...

  • Page 41: Operation

    Operation Handling accessories DANGER Non certified accessories endanger explosion protection. Danger to life exists in potentially explosive atmospheres! Only use original accessories from BARTEC.  Only permitted outside the potentially explosive atmosphere: Insert/replace nano SIM cards.  Insert/replace microSD card.
  • Page 42 TC78 - Touch Computer Operation Type B7-A2D*-****/******** Slide the SIM card holder to the unlock position. Lift the SIM card holder door. Place the Nano SIM card into the card holder with contacts facing down. Close the SIM card holder door. Subject to technical changes.
  • Page 43 TC78 - Touch Computer Operation Type B7-A2D*-****/******** Slide to SIM card holder door to the lock position. Replace the access door. 10. Access door must be replaced and securely seated to ensure proper device sealing. Subject to technical changes. 37/52 October 2023...

  • Page 44: Insert Microsd Card

    TC78 - Touch Computer Operation Type B7-A2D*-****/******** 8.1.2 Insert MicroSD card ATTENTION Damage to the MicroSD card through electrostatic discharges! Use an antistatic base.  Ensure that the operator is correctly earthed.  The end user is free to choose which Micro SD card to use, as these components are not specified in the certificate.
  • Page 45 TC78 - Touch Computer Operation Type B7-A2D*-****/******** Insert the MicroSD card into the card holder door ensuring that the card slides into the holding tabs on each side of the door. Close the MicroSD card holder door. Slide the microSD card holder door to the Lock position. Replace the access door.

  • Page 46: Insert/Change Battery

    The battery (Type B7-A2Z0-0088/**** and Type B7-A2Z0-0089) may only be inserted/changed outside the hazardous area. Use only batteries which have been tested or certified by BARTEC for this purpose. Insert the battery, bottom first, into the battery compartment in the back of the device.
  • Page 47 Chapter: Replacing the Battery --- Battery True Hot Swap ATTENTION Incorrect handling may cause damage to property! Use only batteries which have been tested or certified by BARTEC for this  purpose. If the battery change takes longer than 1 minute, switch off the TC78 -NI with ...
  • Page 48 TC78 - Touch Computer Operation Type B7-A2D*-****/******** Lift the battery from the device. Insert the replacement battery, bottom first, into the battery compartment in the back of the device. Press the battery down until the battery release latch snaps into place. 10.

  • Page 49: Charging The Device/The Battery

    TC78 - Touch Computer Operation Type B7-A2D*-****/******** 8.1.4 Charging the device/the battery A standard battery charges from fully depleted to 90% in approximately 2 hours and from fully depleted to 100% in approximately 3 hours. In many cases, a 90% charge provides enough charge for daily use.
  • Page 50 TC78 - Touch Computer Operation Type B7-A2D*-****/******** 8.1.4.2 Charging the main battery in the device with charging cable Wall charger USB cabel 8.1.4.3 Charging a spare battery Charge the battery only outside hazardous areas. Insert a spare battery into the spare battery slot. Ensure the battery is seated properly.
  • Page 51 TC78 - Touch Computer Operation Type B7-A2D*-****/******** 8.1.4.4 Charge LED Indicator Status Indications The device is not charging. - The device has not been inserted correctly into the base/charging station or has not been connected to a power source. - Charger/base station/charging station is not connected to the power supply.

  • Page 52: Using The Touch Screen

    TC78 - Touch Computer Operation Type B7-A2D*-****/******** Using the touch screen Der Touch Bildschirm kann mit folgenden Methoden bedient werden. Finger  Gloves  Capacitive stylus (Type 17-S1Z0-0008)  It should be noted that the touch mode must be adjusted depending on the method used Work steps: 1.
  • Page 53 TC78 - Touch Computer Operation Type B7-A2D*-****/******** 3. Select “Touch panel mode“ in the menu. 4. Set the “Touch Mode“ for your input method.  Stylus and Finger (Screen protector off), for touching the screen with stylus or fingers. Glove and Finger (Screen protector off), for touching the screen with glove or fingers. ...

  • Page 54: Scanning

    TC78 - Touch Computer Operation Type B7-A2D*-****/******** Scanning Ensure that an application is open on the device and a text field is in focus (text cursor in text field). Point the top of the device at a barcode. Press and hold the Scan button or trigger. The green dash-dot-dash target LED is activated to help you aim.
  • Page 55 TC78 - Touch Computer Operation Type B7-A2D*-****/******** Pick List Mode with Multiple Barcodes in the target field Decoding of the image data is normally immediate. When the device is in Picklist Mode, the imager does not decode the barcode until the green bar-dot bar touches the barcode. Subject to technical changes.

  • Page 56: Disposal

    Disposal Touch Computer and accessories contains metallic and plastic parts and electronic components. WEEE registration number of the BARTEC GmbH: DE 95940350 TAs professional electrical devices, our devices are intended exclusively for commercial use, so-called B2B devices, in accordance with the WEEE Directive. The WEEE Directive provides the framework for the treatment of old electrical equipment throughout Europe.

  • Page 57: Declaration Of Conformity

    - Touch Computer Declaration of Conformity Type B7-A2D*-****/******** Declaration of Conformity The latest versions of the Declarations of Conformity and other certificates can be found on the BARTEC website at: www.bartec.com 10.1 EU Declaration of Conformity Subject to technical changes. 51/52...
  • Page 58 TC78 - Touch Computer Declaration of Conformity Type B7-A2D*-****/******** Subject to technical changes. 52/52 October 2023...
