Summary of Contents for inbody InBody570
- Page 1 User’s Manual...
- Page 2 Visit our website http://www.inbody.com to view and download further information about the functions of the InBody570, the explanation of results output, and more. InBody Co., Ltd reserves the right to modify the appearance, specifications, and etc. of the InBody570 to improve the quality of the product, without prior notice for reasons of performance improvement.
-
Page 3: Table Of Contents
III. Transportation and Storage A. Cautions during Transportation B. Repacking Instructions C. Transportation and Storage Environment IV. Frequently Asked Questions (FAQ) A. Regarding the InBody B. Regarding the InBody Test V. Others A. Exterior and Functions B. Safety Information C. Classification D. Specifications... -
Page 4: Inbody570 Installation
I. InBody570 Installation A. Product Components The InBody570 consists of the following components. Please make sure all of the following components are present. * Please inspect each component of the InBody570 for defects prior to installation. ❶ Keypad InBody570 ❷... -
Page 5: Operating Environment
30 ~ 75% RH Atmospheric pressure 70 ~ 106kPa C. Installation Instructions 1. Open the packing box of the InBody570 and remove the packing pads. Then take the InBody570 out of the box. Polyethylene foam cover Packing pads UTION NOTE... - Page 6 ) into a grounded 3-socket outlet. * The InBody570 can be used in connection with other equipment such as a stadiometer, a blood pressure monitor, data management software called Lookin’Body120, or a barcode reader. For more information, please refer to ‘A. Exterior and Functions 3. Rear Panel’...
- Page 7 InBody570 first. This is necessary to minimize electrical surges on the InBody570. Always use the specified adapter provided by InBody as it is a part of the InBody570. Using other adapters • may result in malfunction of the InBody570.
-
Page 8: Initial Setup
D. Initial Setup 1. The InBody570 automatically starts booting when it is turned on. While booting, it performs a self weight calibration. * While booting (about 5 minutes), make sure there is nothing on top of the footplate. Please do not stand on the footplate, or place objects on the footplate. - Page 9 USB Thumb Drive. 09. Printer Setup : Connect the printer to the InBody. A connected printer will allow for printing results sheets after testing. 10. Results Sheet Types : Select which results sheets to print among the results sheets provided by the InBody570 (InBody Results Sheet and InBody Results Sheet for Children).
- Page 10 : Adjust the alignment of where the results will be printed on the results sheets. 16. Internet Options : You can connect the InBody to the Internet. When the InBody is connected to the internet, can connect to data management software Lookin’Body120, regardless of location.
- Page 11 2) Troubleshooting: See additional information on how to use the InBody. Refer to troubleshooting checklist when there are problems that occur during the InBody use/test. 01. Customer Service Information : See the customer service contact information saved under the Setup of the Administrator Menu ‘24.
-
Page 12: Connecting Printer, Stadiometer, Blood Pressure Monitor, And Barcode Reader
* You may experience connection issues in connecting the printer to the InBody570 if the InBody is turned on. 2) Plug the USB cable provided with the printer into the USB HOST port on the rear panel of the InBody570 and plug the other end of the USB cable into the printer. - Page 13 1) First turn off the InBody570 and then the blood pressure monitor. * You may experience connection issues in connecting the blood pressure monitor to the InBody570 if the InBody is turned on. 2) Plug the serial cable provided with the blood pressure monitor to the 9-pin blood pressure monitor serial port on the rear panel of the InBody570.
-
Page 14: Maintenance
F. Maintenance NOTE DANGER Caution 참 조 주 의 참 고 주 의 • Do not bend the handles of the hand electrodes or rotate them in the reverse direction beyond its limitation. • Do not extend the handles of the hand electrodes beyond its limitation. •... -
Page 15: Inbody Test
Children and people with limited mobility should be supervised or assisted when attempting to test on the InBody. • After an individual with any kind of contagious disease or infection tests on the InBody, use an InBody Tissue to clean the equipment. -
Page 16: Test Instructions
* The screens vary according to the Settings of the Administrator Menu ‘02. Self Mode/Professional Mode’. Professional Mode: An examiner is present and guiding the examinee through the InBody Test. Self Mode: The examinee takes the InBody Test following the instructions that are displayed on screen. 2. Weight measurement begins. -
Page 17: Test Posture
6. When the test is completed, the results will be shown on screen. Professional Mode Self Mode C. Test Posture The examinee must maintain proper posture to have accurate test results. * The test will proceed when there is good electrical contact. Your arms must not touch the sides of your body. -
Page 18: Transportation And Storage
2. Separate the connected adapter, cords, and cables from the equipment, and cover the InBody570 with the polyethylene foam cover. After covering the InBody, lower the upper part. Polyethylene foam cover 3. Put the InBody into the packing box. Place the packing pad over the equipment and tape up the packing box. 재포장... -
Page 19: Frequently Asked Questions (Faq)
* Customer contact information can be found under Settings of the Administrator Menu ‘24. Customer Service Information’. A. Regarding the InBody If a problem arises with the InBody570, you may first attempt to check the ‘Troubleshooting’ in the Administrator Menu. The InBody570 can help you diagnose and solve some problems. If your problem cannot be resolved through the ‘Troubleshooting’, please refer to the possible solutions below. Question... - Page 20 If you cannot enter the Administrator Menu due to touchscreen problems, • please restart the InBody. The InBody stores the last touchscreen alignment and will automatically recall the previous touchscreen settings. The InBody can also recognize if its touchscreen alignment is off screen and will automatically take the user to the calibration screen after restarting.
-
Page 21: Regarding The Inbody Test
• harmful to the body? that is not harmful to the body. The safety of the InBody has been tested and proven. The InBody products have been approved for medical use by the CE and all over the world. Many medical institutions around the world are actively using the InBody. -
Page 22: Others
V. Others * The InBody570 is manufactured according to the quality management procedure of InBody. InBody complies with the ISO9001 and ISO13485 which are international quality management systems. * This equipment satisfies the IEC60601-1 (EN60601-1), an international safety standard for electronic medical equipment. This equipment a lso satisfies the IEC60601-1-2 (EN60601-1-2), an international standard for electromagnetic conformity. A. Exterior and Functions The following are the names and functions of each part of the InBody. - Page 23 Rear sole electrode: The examinee makes contact with this electrode by stepping with the heel of their foot. ❸ Footplate: This is connected to the scale, which measures the examinee’s weight. ❹ Level Indicator: Indicates the current horizontal level of the InBody570. ❺ Joint: Joins the upper part and lower part of the equipment together. ❻...
- Page 24 USB HOST port: Used for connecting to a printer, a barcode reader, or a USB Thumb Drive. ❾ Power input port: Used for connecting to the power adapter. * Always use the specified adapter provided by InBody as it is a part of the InBody570. Using other adapters may result in malfunction of the InBody570. ❿...
-
Page 25: Safety Information
B. Safety Information Indicators 9-pin serial port (Female, RS-232C) LAN port (10T Base) USB port Safety Symbols Dangerous High Voltage Warning, Caution BF Type Equipment Adapter Power On Power Off Follow instructions for use Suivez les instructions d’utilisation WARNING Electric shock hazard – do not dismantle. Dismantling will void the warranty. -
Page 26: Classification
• Rate Pressure Product) Results Interpretation QR Code Impedance (Each frequency, Each segment) Outputs Results and Interpretations (InBody Result Sheet for Body Composition Analysis (Total Body Water, Protein, Soft Lean Mass, Minerals, • Children) Body Fat Mass, Weight) • Muscle-Fat Analysis (Weight, Skeletal Muscle Mass, Body Fat Mass) •... - Page 27 Provides audible indication for test in progress, test complete, and successfully saved settings changes. Database Test results can be saved if the member ID is utilized. The InBody can save up to 100,000 results. Test Mode Self Mode, Professional Mode...
- Page 28 ⓒ2015 InBody Co., Ltd. All rights reserved. BM-ENG-D3-D-150520...
