Graco Extend2FitTM Platinum Instruction Manual

Hide thumbs

Advertisement

Quick Links

Download this manual
www.gracobaby.ca
Extend2Fit
Platinum
TM
CONVERTIBLE CAR SEAT
Read This Instruction Manual
Do not install or use this child restraint
until you read, understand and follow
the instructions in this manual and the
warnings on the car seat.
FAILURE TO PROPERLY USE THIS
CHILD RESTRAINT INCREASES THE
RISK OF SERIOUS INJURY OR DEATH
IN A SUDDEN STOP OR CRASH.
NWL0000803031A 6/18

Advertisement

loading

Related Manuals for Graco Extend2FitTM Platinum

Summary of Contents for Graco Extend2FitTM Platinum

  • Page 1 www.gracobaby.ca Extend2Fit Platinum CONVERTIBLE CAR SEAT Read This Instruction Manual Do not install or use this child restraint until you read, understand and follow the instructions in this manual and the warnings on the car seat. FAILURE TO PROPERLY USE THIS CHILD RESTRAINT INCREASES THE RISK OF SERIOUS INJURY OR DEATH IN A SUDDEN STOP OR CRASH.
  • Page 2 1 Important Pages 6-23 1-A A Quick Guide to Your Manual 1-B Welcome to the Graco Family 1-C Right Mode of Use 1-D Before You Begin Register This Car Seat If You Need Help Certification Aircraft Installation Car Seat’s Useful Life...

  • Page 3: Rear-Facing Use

    3 Rear-Facing Use Pages 30-47 3-A Rear-Facing 3-B Installing Rear-Facing with EZ Tight™ UAS 3-C Install Rear-Facing With Vehicle Seat Belt 4 Forward-Facing Use Pages 48-61 4-A Forward-Facing 4-B Installing Forward-Facing With EZ Tight™ UAS and Tether 4-C Install Forward-Facing With Vehicle Seat Belt and Tether...

  • Page 4: Securing Child

    5 Securing Child Pages 62-69 5-A Securing Child in Harness Mode 6 Accessories Page 70 7 Moving the UAS Strap Pages 71-73...

  • Page 5: Additional Information

    8 Additional Information Pages 74-84 8-A How to Remove EZ Tight™ UAS and Top Tether 8-B Choosing Vehicle Seat Location 8-C Unsafe Vehicle Seat Locations 8-D Vehicle Seat Belts 9 Cleaning Seat Pad Pages 85-91 9-A Cleaning Seat Pad 9-B Cleaning Crotch Buckle 9-C Cleaning Harness and EZ Tight™...
  • Page 6 1-A A Quick Guide to Your Manual This car seat is for children: Rear-Facing: 1.8-22.5 kg (4-50 lb), 46-125 cm (18-49 in) Forward-Facing: 10-30 kg (22-65 lb), 69-125 cm (27-49 in) • Children less than 10 kg (22 lb) and cannot walk unassisted MUST use this car seat rear-facing.
  • Page 7 Get to Know Your Car Seat Review section 2-A to see all of the features of this car seat. According to collision statistics, the safest place for your child in any vehicle is the back seat. The centre of the back seat can be the safest during a possible side impact.
  • Page 8 What is UAS? UAS consists of lower anchors and top tether anchors, which are built-in to your vehicle, and connecting hooks that are built-in to your car seat. Lower anchors are used INSTEAD of the vehicle’s seat belt to secure the child seat to the vehicle. Top tethers are used IN ADDITION to the lower anchors OR the vehicle’s seat belt to secure a forward-facing car seat to the vehicle.
  • Page 9 When Installing Rear-Facing & Forward-Facing EZ Tight™ UAS UAS consists of two lower anchors, which are built-in to your vehicle, and connectors that are built-in your car seat. Review section 3-B & 4-B of this manual AND your vehicle owner’s manual. EZ Tight™...
  • Page 10 Does Your Car Seat Fit Your Child Correctly? To make sure your child is secured properly, review section 3 and 4 to understand all of the actions you need to take to properly adjust the car seat to fit your child. For Rear-Facing, You Need to Adjust: Harness Height, Rear-Facing (A) Harness straps at or just below the child’s...
  • Page 11 For Forward-Facing, You Need to Adjust: Harness Height, Forward-Facing (A) Harness straps at or just above the child’s shoulders and top of child’s ears below top of headrest (B). Review section 5. Buckle Position (C) The correct slot is the one that is closest to your child without being underneath them.

  • Page 12: Rear-Facing Installation

    Rear-Facing Installation Car Seat Does Not Move More than 2.5 cm (1”) at the Belt Path (A) Review section 3 Check level indicator (B) Review section 3 Harness Straps at or Just Below Child’s Shoulders (C) Review section 5 3 + months 0 + months / mois / mois...

  • Page 13: Forward-Facing Installation

    Forward-Facing Installation Use the top tether strap when using forward-facing harness mode (A) When used properly, the top tether helps reduce injury in a sudden stop or crash. Review section 4 Car Seat Does Not Move More than 2.5 cm (1”) at the Belt Path (B) Review section 4 Harness Straps at or Just Above Child’s Shoulders (C)
  • Page 14 1-B Welcome to the Graco Family! Your child’s safety depends on you. No car seat can guarantee protection from injury in every situation, but proper use helps reduce the risk of serious injury or death. Even if this car seat seems easy to figure out on your own, you must follow the detailed...
  • Page 15 1-C Right Mode of Use 22.5 kg 1.8 kg 10 kg 30 kg (4 lb) (22 lb) (50 lb) (65 lb) Rear-Facing Harness Mode 1.8-10 kg (4-22 lb) and cannot walk unassisted MUST be rear-facing. 10-22.5 kg (22-50 lb) SHOULD be rear-facing. Forward-Facing Harness Mode with Top Tether 10-22.5 kg (22-50 lb) can walk unassisted CAN be forward- facing.
  • Page 16 1-D Before You Begin Register This Child Restraint Please fill out the prepaid registration postcard attached to the harness and mail it in today or register online at www.gracobaby.ca. Child restraints could be recalled for safety reasons. You must register this restraint to be reached in a recall.
  • Page 17 For future reference or if you change addresses, record the model name, model number, date of manufacture and purchase date of this car seat on the below. You can find this information either on the registration card if you still have it or on the date label located on the back of the car seat.

  • Page 18: Aircraft Installation

    STOP using this car seat and throw it away 10 years after the date of manufacture. Look for this sticker on back of the car seat. Graco Children’s Products Inc. advises against loaning or passing along a car seat unless you know the complete history of the product. We also advise against...
  • Page 19 Vehicle Seat Protection Protect vehicle seat. Use a car seat mat, towel, or thin blanket under and behind car seat. Warm Weather Use Car seat parts can get very hot in the sun or warm weather. To avoid burns, al- ways check before putting child in car seat.
  • Page 20 NEVER PLACE THIS CHILD RESTRAINT REAR-FACING IN A VEHICLE SEATING LOCATION THAT HAS AN ACTIVE FRONT AIR BAG. If an air bag inflates, it can hit the child and car seat with great force and cause serious injury or death to your child. Experts recommend that children ride rear-facing until the age of 2 or until they reach the maximum rear-facing height or weight rating for their seat, and when forward-facing, children should use the built-in...
  • Page 21 Choose the correct mode of use for the car seat depending on your child’s size. Infants less than 10 kg (22 lb) MUST use this car seat rear- facing. Select a suitable location for the car seat in your vehicle. Secure car seat with a vehicle seat belt or EZ Tight UAS that is properly routed as shown in this manual.
  • Page 22 DO NOT use car seat if it is damaged or missing parts. DO NOT use accessories or parts other than those provided by Graco except for a thin towel or mat to protect your vehicle seat or a rolled towels or pool noodles to help get your car seat level.
  • Page 23 According to experts, these infants may suffer breathing issues if improperly reclined in a car seat. When rear-facing, use the corrected age for preemies. Graco advises that you have your physician or hospital staff evaluate your infant and recommend the proper...
  • Page 24 2-A Car Seat Features...
  • Page 25 A Height Adjust Lever B Headrest C Head Support D Harness Cover E Buckle Pockets F Cupholder G Harness Release Lever (under seat pad) H Extender Handle I Chest Clip J Harness Buckle K Body Support L Harness Adjustment Strap M Base Recline Handle...
  • Page 27 A Tether Storage Ring B Tether Hook C Tether Strap D EZ Tight™ UAS Storage E EZ Tight™ UAS Strap F Cup Holder G Level Indicator...
  • Page 29 A Tether Strap B Harness Straps C EZ Tight™ UAS Storage Bars D Splitter Plate E Instruction Manual Storage F Tether Storage Bar G Tether Hook H EZ Tight™ UAS Button (press to extend UAS strap) I EZ Tight™ UAS Retractor J EZ Tight™...

  • Page 30: Rear-Facing

    3-A Rear-Facing Rear-Facing: 1.8-22.5 kg (4-50 lb), 46-125 cm (18-49 in), and whose head is at least 2.5 cm (1”) below the headrest adjustment handle • Infants who weigh less than 10 kg (22 lb) and cannot walk unassisted MUST be rear- facing.
  • Page 31 • Check recline level making sure the ball is within the blue area. The vehicle MUST be on level ground. • Harness straps need to be even with or just below the top of child’s shoulders and chest clip is at armpit level. •...
  • Page 32 0 + months nths 0 + months nths / mois 0 + months / mois nths / mois When reading the level indicator, Vehicle MUST be on level ground. 0 + months nths / mois Use corrected age for preemies. - If the ball is entirely in light blue, the restraint is level for infants 0+ months in age.
  • Page 33 3-B Install Rear-Facing With EZ Tight™ UAS Review your vehicle’s owner manual for UAS location and use. Do not install by this method for a child weighing more than 20 kg (45 lb). 1. Store Top Tether Strap Attach tether hook to the plastic bar on right side of the car seat.
  • Page 34 3. Make Sure EZ Tight™ UAS Strap is in the Rear-Facing Belt Path Marked With a Blue Label and it is Not Twisted If not, See section 7 to move EZ Tight UAS strap. 4. Recline the Car Seat Pull out on handle on front of child restraint and adjust to one of the three rear-facing positions.
  • Page 35 5. Place Car Seat Rear-Facing in Back Seat of the Vehicle Place car seat rear-facing in vehicle seat and centre the car seat between the lower UAS anchors. The base should sit as flat as possible on the vehicle seat. 6.
  • Page 36 7. Make Sure Base is a minimum of 80% on Vehicle Seat 8. Check the Level Indicator Vehicle MUST be on level ground. Ball must be completely in the blue zone. 3 + months 0 + months Readjust the incline if needed. / mois / mois Or if needed, rolled towels may be placed...
  • Page 37 9. Extend the EZ Tight™ UAS Strap Press in and hold on the blue release button on the EZ Tight™ UAS retractor and pull the EZ Tight UAS strap until it is fully extended. 10. Attach Each EZ Tight UAS Connector to Vehicle’s Lower UAS Anchors EZ Tight UAS strap should lie flat and not...
  • Page 38 11. Pull All of the EZ Tight™ UAS Strap Slack to the Retractor Side 12. Activate the EZ Tight™ UAS Retractor Slide and release the gray EZ Tight™ UAS retractor’s slider to remove the slack. 13. Tighten the EZ Tight™ UAS Push down firmly on the car seat in the locations shown and release.
  • Page 39 14. Test For Tightness Grab the sides of the seat where the EZ Tight™ UAS strap is and slide the car seat side-to-side and front-to-back. If the seat moves less than 2.5 cm (1”), it is tight enough. If it moves more than an 2.5 cm (1”), repeat steps 11, 12, 13 and 14.
  • Page 40 Is Everything Correct? Car Seat Does Not Move More than 2.5 cm (1”) at the Belt Path Level Indicator’s Ball in the Blue Zone and 3 + months 0 + months Vehicle on Level Ground / mois / mois Harness Straps at or Just Below the Child’s Shoulders Review section 5 Chest Clip Even With Armpits...
  • Page 41 3-C Install Rear-Facing with Vehicle Seat Belt 1. Store Top Tether. Store EZ Tight™UAS in the Forward-Facing Belt Path Attach tether hook and EZ Tight connectors to the plastic bars as shown. Review section 7-A to move the EZ Tight™ UAS.
  • Page 42 3. Place Car Seat Rear-Facing in Back Seat of the Vehicle Place car seat rear-facing in vehicle seat. The base should sit as flat as possible on the vehicle seat. 4. Make Sure Base is a minimum of 80% on Vehicle Seat 5.
  • Page 43 6. Check the Level Indicator Vehicle MUST be on level ground. Ball must be completely in the blue zone. Readjust if needed. 3 + months 0 + months / mois / mois For infants 3 months and under, the ball must completely cover the light blue circle.
  • Page 44 Review your vehicle’s owner manual for vehicle seat belt use 7. Route the Vehicle Seat Belt Thread vehicle seat belt through the rear-facing belt path (marked with a blue label) and out the other side. Buckle it. The seat belt should lie as flat as possible and not be twisted.
  • Page 45 8. Lock Vehicle Seat Belt In most vehicles today, slowly pull the shoulder belt all the way out and then let it go back in. You will hear a clicking sound. Slowly pull out on the seat belt and it should be locked. If not, review your car’s owner manual and section 8-D.
  • Page 46 10. Test For Tightness Grab the sides of the seat where the vehicle seat belt is and slide the car seat side-to-side and front-to-back. If the seat moves less than 2.5 cm (1”), it is tight enough. 11. Check the Level Indicator Vehicle MUST be on level ground.
  • Page 47 Is Everything Correct? Car Seat Does Not Move More than 2.5 cm (1”) at the Belt Path Level Indicator’s Ball in the Blue Zone and 3 + months 0 + months Vehicle on Level Ground / mois / mois Harness Straps at or Just Below the Child’s Shoulders Review section 5 Chest Clip Even With Armpits...
  • Page 48 4-A Forward-Facing Forward-Facing: 10-30 kg (22-65 lb) and 69-125 cm (27-49 in) • Place car seat forward-facing in the vehicle back seat. • Make sure the EZ Tight™ UAS strap or vehicle seat belt is routed through the forward-facing belt path marked with a orange label. •...
  • Page 49 • Experts recommend that children ride rear- facing until the age of 2 or until they reach the maximum rear-facing height or weight rating for their seat, and when forward-facing, children should use the built-in harness system for as long as possible until they reach the maximum forward-facing weight or height for their car seat.
  • Page 50 4-B Install Forward-Facing with EZ Tight™UAS and Tether Review your vehicle’s owner manual for UAS location and use. Do not install by this method for a child weighing more than 20 kg (45 lb). 1. Remove EZ Tight™UAS from Storage Location 2.
  • Page 51 4. Unhook Top Tether Strap From Storage Unhook tether and lay it in the seat. 5. Adjust the Car Seat Place the car seat in the 4th, 5th or 6th recline position. 6. Place Car Seat Forward-Facing in Back Seat of the Vehicle Place car seat forward-facing in vehicle seat and centre the car seat between the lower UAS anchors.
  • Page 52 7. Make Sure Base is a minimum 80% on Vehicle Seat 8. Extend the EZ Tight™ UAS Strap Press in and hold on the blue release button on the EZ Tight™ UAS retractor and pull the EZ Tight™ UAS strap until it is fully extended.
  • Page 53 10. Pull All of the EZ Tight™ UAS Strap Slack to the Retractor Side 11. Activate the EZ Tight™ UAS Retractor Slide and release the gray EZ Tight™ UAS retractor’s slider to remove the slack. 12. Tighten the EZ Tight™ UAS Push down firmly on the car seat in the locations shown and release.
  • Page 54 13. Attach Top Tether Strap Extend the tether by pressing the grey button and pulling out on the strap and attach. Consult vehicle’s owner manual for specific location. 14. Tighten Top Tether Strap Remove all the slack. 15. Test For Tightness Grab the sides of the seat where the EZ Tight™...
  • Page 55 Is Everything Correct? Car Seat Does Not Move More than 2.5 cm (1”) at the Belt Path Harness Straps at or Just Above the Child’s Shoulders Review section 5 Chest Clip Even With Armpits Review section 5 Cannot Pinch Harness Straps at the Shoulder Review section 5...
  • Page 56 4-C Install Forward-Facing with Vehicle Seat Belt and Tether 1. Store EZ Tight™ UAS in the Rear-Facing Belt Path Attach UAS connectors EZ Tight to the plastic bars as shown. See section 7-A to move the EZ Tight™ UAS. 2. Adjust the Car Seat Place the car seat in the 4th, 5th or 6th recline position.
  • Page 57 3. Unhook Top Tether Strap From Storage Unhook tether and lay it in the seat. 4. Place Car Seat Forward- Facing in Back Seat of the Vehicle Place car seat forward-facing in vehicle seat. The base should sit as flat as possible on the vehicle seat. 5.
  • Page 58 Review your vehicle’s owner manual for vehicle seat belt use 6. Route the Vehicle Seat Belt Thread vehicle seat belt through the forward-facing belt path (marked with a orange label) and out the other side. Buckle it. The seat belt should lie as flat as possible and not be twisted.
  • Page 59 8. Tighten the Vehicle Seat Belt Press down firmly in the centre of the car seat. Pull on the shoulder belt to tighten while feeding the slack back in the retractor. 9. Attach The Tether Extend the tether by pressing the grey button and pulling out on the strap and attach.
  • Page 60 11. Test For Tightness Grab the sides of the seat where the vehicle seat belt is and slide the car seat side-to-side and front-to-back. If the seat moves less than 2.5 cm (1”), it is tight enough. See section 5-A to secure your child.
  • Page 61 Is Everything Correct? Car Seat Does Not Move More than 2.5 cm (1”) at the Belt Path Harness Straps at or Just Above the Child’s Shoulders Review section 5 Chest Clip Even With Armpits Review section 5 Cannot Pinch Harness Straps at the Shoulder Review section 5...
  • Page 62 WARNING! In cold weather, do not put snowsuits or bulky garments on your child when placing them in the car seat. Bulky clothing can prevent the harness straps from being tightened properly. To keep child warm, buckle your child in the car seat and place a blanket around the child or place the child’s coat on backwards after buckling in.
  • Page 63 Unbuckle the chest clip and the crotch buckle. On select models, place harness straps in buckle storage pocket.
  • Page 64 2. Place Your Child in the Seat Make sure their back is flat against the car seat back. 3. Place Harness Straps Over Child’s Shoulders and Buckle You will hear a “click” when buckle tongues are securely attached. Pull up on each buckle tongue to make sure it is securely attached.
  • Page 65 4. Be Sure the Harness Straps Are at the Proper Height 2.5 cm (1”) 2.5 cm (1”) Rear-Facing: Harness straps should be at or just below the child’s shoulders. Top of head must be 2.5 cm (1”) below Rear-Facing the headrest adjustment lever. Forward-Facing: Harness straps should be at or just above the child’s shoulders.
  • Page 66 5. To Raise or Lower Headrest/ Harness Height Squeeze the height adjustment handle and move headrest for the proper harness height. 6. Check the Buckle Position The correct slot is the one that is closest to your child without being underneath them.
  • Page 67 7. To Adjust Crotch Strap Recline the car seat and locate the metal retainer under the car seat shell. 8. Rotate Metal Retainer and Insert It Up Through the Shell and Pad From the top of the car seat, pull the crotch buckle out.
  • Page 68 10. Pull Up on Crotch Strap to Make Sure it is Secured 11. Buckle the Chest Clip You will hear a “click” when the chest clip is securely buckled. 12. Pull All the Slack Out From Around the Waist Pull up on the harness strap while pushing the chest clip down.
  • Page 69 13. Tighten the Harness by Pulling the Harness Adjustment Strap When you are not able to pinch any of the harness webbing at your child’s shoulder, the harness is tight enough. A snug harness should not allow any slack. It lies in a relatively straight line without sagging.
  • Page 70 6-A Accessories (on select models) Harness Covers Make sure that harness covers do not interfere with placement of the chest clip at armpit level. To remove, undo the fastening strips and remove. Head Support Slide head support into opening in headrest as shown.
  • Page 71 7-A Moving the EZ Tight™UAS Strap 1. For Ease of Moving the EZ Tight™ UAS Strap A. Undo Snaps and fastening strips in front of child restraint. B. Pull the EZ Tight™ UAS straps out of the belt path opening, so that the EZ Tight™ UAS connectors end up on the same side of the child restraint.
  • Page 72 2. Slide Entire EZ Tight™ UAS Strap Along Bar to Correct Belt Path Opening Rear-Facing: Slide EZ Tight strap down to the blue label. Forward-Facing: slide the EZ Tight UAS strap up to the orange label. 3. Feed the UAS Connector with the Adjuster Closest to it Through the Chosen Belt Path Rear-Facing: Make sure the EZ Tight™...
  • Page 73 Forward-Facing: Make sure the strap is flat and not twisted. 4. Replace the Seat Pad Fabric on the Front of the Child Restraint...
  • Page 74 8-A How to Remove EZ Tight™ UAS and Top Tether EZ Tight™ UAS To remove the EZ Tight™ UAS from the lower anchors, push in on the red buttons and pull them off. Top Tether To remove, press the grey button and pull out on the strap to release the tension.
  • Page 75 8-B Choosing Vehicle Seat Location Review your vehicle owner’s manual for seating locations. The best seating location for this car seat is one that: • Is recommended by your vehicle owner’s manual, and • Results in a secure installation of this car seat In the event there is no available back seat and / or you have no other option than to place a child in a front passenger seating position (other than rear-facing), experts recommend that you take the following steps:...
  • Page 76 8-C Unsafe Vehicle Seat Locations Never install this car seat in any of the following vehicle seating locations: rear-facing or side-facing rear-facing with an vehicle seats active front air bag...
  • Page 77 8-D Vehicle Seat Belts Review your vehicle owner’s manual for vehicle seat belt use This car seat can be installed using a vehicle seat belt. To do this, you will need to change the seat belt to a locked mode for use with car seats. With some vehicle seat belts, this is done with the latch plate;...
  • Page 78 Identify Your Seat Belt Type There are two different types of vehicle seat belts that can be used with this car seat: Lap/Shoulder Belt Lap Belt Only 3 connections points. Can be used in all car 2 connection points. seats modes of use. The following types of vehicle seat belts CANNOT Belts Forward of the be used safely with this car seat:...
  • Page 79 Switchable. If it can still be pulled out freely, it is ELR. Note: Most vehicles manufactured after 1996 will have Switchable retractors in the back seat. If you have any questions about your retractor type, consult your vehicle owner’s manual or call Graco for assistance.
  • Page 80 How to Lock Your Lap and Shoulder Vehicle Seat Belt Sliding Latch Plate and Switchable Retractor A latch plate that slides freely on the belt webbing and cannot, by itself, hold the belt snug around a car seat. When installing the car seat, route the vehicle seat belt through the proper belt path and buckle it in.
  • Page 81 Locking Latch Plate and ELR Retractor A latch plate that holds the lap belt snug after it has been adjusted; contains a metal bar on the underside of the hardware that “locks” the belt in position. When installing the car seat, route the vehicle seat belt through the proper belt path and buckle it in.
  • Page 82 Sliding Latch Plate and ALR Retractor A latch plate that slides freely on the belt webbing and cannot, by itself, hold the belt snug around a car seat. Slowly pull the shoulder belt all the way out. Route the vehicle seat belt through the proper belt path and buckle it in.
  • Page 83 Sliding Latch Plate and ELR Retractor A latch plate that slides freely on the belt webbing and cannot, by itself, hold the belt snug around a car seat. With this retractor, you will need to use the locking clip to lock the vehicle seat belt. To get a locking clip order online at gracobaby.ca or call 1-800 345-4109.
  • Page 84 Lap Belt Installation Always review your vehicle owner’s manual for specific information about your vehicle seat belts. Locking Latch Plate and No Retractor When installing the car seat, route the lap seat belt through the proper path and buckle it in. Then, pull upwards on the tail Grab the sides of the seat at of the belt so that the lap belt gets tight the belt path and slide the seat...
  • Page 85 9-A Cleaning Rapid Remove Seat Pad Seat Pad With the Rapid Remove™ seat pad, you do not need to uninstall the car seat to clean the seat pad. Raise headrest all the way up. From behind the seat undo the fastening strips.
  • Page 86 Pull side panel pocket off of side panel. Undo fastening strips on the front of the seat.
  • Page 87 Remove pad from shell. Machine wash pad in cold water on delicate cycle and drip-dry. DO NOT USE BLEACH. To put the seat pad back on, reverse preceding steps. Rear Pad You may need to uninstall the car seat to remove the pad. Undo elastic loops and remove.
  • Page 88 2. Attach the shorter loop first. 3. Pull the longer loop behind the shorter loop. 4. Wrap the Longer loop around the shorter loop one time and attach to the hook. Front Pad You may need to uninstall the car seat to remove the pad.
  • Page 89 Head Rest Cover Undo elastic loop underneath head support cover. Pull tab out from behind head support. Undo the elastic loops on the sides of the headrest. Peel cover off head support. DO NOT remove foam padding. Machine wash pad in cold water on delicate cycle and drip-dry.
  • Page 90 9-B Cleaning Crotch Buckle Recline the car seat and locate the metal retainer. Rotate the metal retainer up through the shell and pad. From the front, pull the crotch buckle out. To clean buckle, place in a cup of warm water and gently agitate the buckle.
  • Page 91 9-C Cleaning Harness and EZ Tight™ Surface wash only with mild soap and damp cloth. DO NOT IMMERSE THE HARNESS STRAPS or EZ Tight™ UAS STRAP IN WATER Doing so may weaken the straps. If harness straps or EZ Tight UAS belt are frayed or heavily soiled, contact Customer Service at www.gracobaby.ca or 1-800-345-4109.

  • Page 92: Replacement Parts

    Replacement Parts To purchase parts or accessories in Canada, please contact us at the following: www.gracobaby.ca gracoconsumercareca@newellco.com 1-800-345-4109 Store instruction manual behind the tab with the instruction book icon as shown.
