Intrusion Alarm Systems | ITS-SPDIAL-FR Speech Dialer
ITS-SPDIAL-FR Speech Dialer
www.boschsecurity.com
This voice and digital speech dialer is used for indoor
security applications. It contains a French language
pack only.
This dialer has a tamper contact to detect opening the
enclosure.
Functions
• One general, user recordable, 20 sec. voice message
• Two user recordable, 20 sec voice messages,
associated with the two inputs E1 and E2
• 8 x 20 digits telephone numbers (4 voice and 4
digital)
• Adjustable timer between two call cycles
• Low battery detection programmable between 10 to
12 VDC
• Audio monitoring time programmable from 0 to 99
sec
• On / off input
• E1 input slaved to the on/off input
• E2 input for 24 hour tamper loop
• Inputs can be 0 to 12 V loss-configured
• Input timer from 0 to 999 sec
• Siren block output for audio monitoring
• 2 remote control outputs: one bi-stable and one
impulse
• Five ways of acknowledge alarms
• Memory holds the last 250 time stamped log events
Transmission via voice and digital
u
Programming via keypad or remotely with a phone
u
Tamper proof housing
u
Supports Cesa 200 Bauds and Contact ID
u
French language pack
u
• Compliant with EN50130-4 standard
Certifications and approvals
Region Certification
Europe CE
Parts included
Qty. Component
1 Speech Dialer
1 Installation Manual
Technical specifications
Electrical
Minimum operating voltage in
VDC
Maximum operating voltage in
VDC
Maximum residual ripple in mV
9
15
250
