ENSTROM F-28F/280FX OPERATOR'S
ROTORCRAFT FLIGHT MANUAL
GTX 345 ADS-B TRANSPONDER
HELICOPTER SERIAL NO.
HELICOPTER REGISTRATION NO.
THIS SUPPLEMENT MUST BE CARRIED IN THE
HELICOPTER AT ALL TIMES IF EQUIPPED WITH THE
GTX 345 INSTALLATION. CHAPTERS 1, 2, 3, AND 4 ARE
FAA APPROVED.
FAA APPROVED
ACTING MANAGER, SOUTHWEST FLIGHT TEST SECTION,
AIR-713
FEDERAL AVIATION ADMINISTRATION
FT. WORTH, TX
DATE
THE ENSTROM HELICOPTER CORPORATION
FAA Approved: Mar 28/19
This electronic document is not linked to a subscription for revision control or distribution. Refer to the Optional
Equipment Supplement Publications Status link under the Technical Support Page of the Enstrom Helicopter website
for the current revision level of the Rotorcraft Flight Manual Supplement.
MANUAL
AND
FAA APPROVED
SUPPLEMENT
* * * * *
REPORT NO. 28-AC-081
* * * * *
2209 22
MENOMINEE, MICHIGAN 49858-3515
STREET
ND
Jan 15/19
