- Page 1 IP Touch 4008/4018 Extended Edition SIP Phone Installation Guide 8AL90824AAAA ed02 August, 2010 Alcatel-Lucent All Rights Reserved © Alcatel-Lucent 2010...
-
Page 2: Table Of Contents
Overview...................3 Connecting the Alcatel-Lucent IP Touch 4008/4018 Extended Edition phone...3 2.1. Connecting the IP Touch 40x8 EE phone to the LAN ........4 2.2. Connecting power supply ..............4 2.3. Plugging a PC to an IP Touch 4018 EE phone..........4 SIP stand-alone mode ................4 3.1. -
Page 3: Overview
1. Overview The Alcatel-Lucent IP Touch 4008/4018 Extended Edition phones (IP Touch 40x8 EE) are part of the Alcatel-Lucent IP Touch 8-series Extended Edition phone range. The following chapters in this document describe SIP stand-alone operations. From firmware version identification to switching from NOE to SIP stand-alone mode, SIP mode initialization (configuration &... -
Page 4: Connecting The Ip Touch 40X8 Ee Phone To The Lan
Only one additional equipment can be connected to the set connector labeled PC on an IP Touch 4018 EE phone. Note 1: reminder, the Alcatel-Lucent IP Touch 4008 EE phone set has no PC connector. Note 2: if 802.1x authentication is used, the PC port cannot be used until the IP Touch 418 EE phone authentication is completed. -
Page 5: Switching From Noe To Sip Mode
9- Press ‘#’ to save the new configuration. 10- Press the Hang Up key to reset the device to take into account the new configuration. For checking SIP status, follow ‘Firmware version identification already installed’ section. Page 5 All Rights Reserved © Alcatel-Lucent 2010... - Page 6 This file must be reachable from root location of the TFTP Server. The IP Touch 40x8EE phone is compatible with any DHCP server that correctly supports the BOOTP server IP address - siaddr (also called ‘next-server’) field. See standard RFC 951 further information. Page 6 All Rights Reserved © Alcatel-Lucent 2010...
-
Page 7: Initializing An Ip Touch 40X8 Ee Phone
The SIP binary files must be set into the server at the same location as the sipconfig.txt and sipconfig-MacAddress.txt configuration files. For IP Touch 4008EE phone, the available binary files are: – noesip4008 (application) – datsip4008 (resources including the ringing melodies) Page 7 All Rights Reserved © Alcatel-Lucent 2010... -
Page 8: Selecting The Downloading Mode
Use default port: Yes DL @: TFTP Server @ DL port: 69 7- Press OK to save. Warning: no administrator action within 30 seconds in the configuration menu will automatically lead to quit this menu. Page 8 All Rights Reserved © Alcatel-Lucent 2010... - Page 9 The syntax for the ‘Option’ 43 IP is as follows: <opcode> <length> <IP> <opcode> = 0x40 (64 decimal) <length> = 0x04 (4 decimal) <IP> = IP Address in hexadecimal – e.g. for 192.168.1.30 content should be (0xC0 A8 01 1E) Page 9 All Rights Reserved © Alcatel-Lucent 2010...
-
Page 10: Http(S)
DL Path: The path to the directory where Configuration and Binaries are located 7- Press OK to save. Warning: no administrator action within 30 seconds in the configuration menu will automatically lead to quit this menu. Page 10 All Rights Reserved © Alcatel-Lucent 2010... - Page 11 Windows 2003 Server >>> Option 43 + Sub option 64 Linux (5305) >>> Option 43 + sub option 64 Priority 1* >>>Next Server – Siaddr: Windows 2003 Server >>> Option 66 (URL) + Option 67 (dummy) Linux (5305) Siaddr Page 11 All Rights Reserved © Alcatel-Lucent 2010...
- Page 12 66 with "IP Address of the HTTP(S) file server" and option 67 with "dummy non empty value". For Windows DHCP server, it is mandatory to activate option 67 with any name in it. Page 12 All Rights Reserved © Alcatel-Lucent 2010...
- Page 13 Example with Linux DHCP ISC server (dhcpd.conf file): option space ALU; option ALU.https-server-address code 67 = text; class "vendor-classes" { match option vendor-class-identifier; subclass "vendor-classes" "alcatel.sip.0" { vendor-option-space ALU; option ALU.https-server-address "https://fileserver.mycompany.com/iptouch/"; Page 13 All Rights Reserved © Alcatel-Lucent 2010...
-
Page 14: Sip Registration
When there are new binary files, the set automatically restarts and proceeds with a binary update. After user changes any parameters in admin settings and exits, phone will reset automatically. Page 14 All Rights Reserved © Alcatel-Lucent 2010... -
Page 15: Sip Configuration Files Description
Enter the address of the registrar server and registrar_addr= PCX adresse registrar_port= Enter the registrar port number outbound_proxy_addr= Enter the outbound proxy server address outbound_proxy_port= Enter the port used by the outbound proxy server Page 15 All Rights Reserved © Alcatel-Lucent 2010... - Page 16 Enter the port number used by the SIP set used local_sips_port= in secured mode sip_transport_mode=0 Enter level transport mode: – 0 for UDP or TCP 1 for UDP only – – 2 for TCP only Page 16 All Rights Reserved © Alcatel-Lucent 2010...
- Page 17 Enter the URI or the call number of the voice mail Complete SIP URI of the voice mail message_waiting_indication_uri= [qos] sip_diffserv=0 rtp_diffserv=0 sip_qos_tickets_enable=0 – 0 : disable – 1 : enable Enter Domaine name sip_qos_tickets_target= Page 17 All Rights Reserved © Alcatel-Lucent 2010...
- Page 18 Enter the country language of the user: – 0 for English – 1 for French – 2 for German – 3 for Italian – 4 for Spanish – 5 for Dutch – 6 for Portuguese Page 18 All Rights Reserved © Alcatel-Lucent 2010...
- Page 19 Voice Activity Detection: vad=1 – 0 VAD out of service – 1 VAD in service 0 = disable dtmf_feedback_enable=1 1 = enable rlr_handset=10 slr_handset=10 sidetone_handset=2 0 = disable hearing_aid_enable=1 1 = enable Page 19 All Rights Reserved © Alcatel-Lucent 2010...
- Page 20 Enter the first name to display when key 4 is activated Enter the last name to display when key 4 is speed_dial_2_last_name= activated speed_dial_2_uri= Enter the URI or the call number locally dialed by the set when key 4 is activated Page 20 All Rights Reserved © Alcatel-Lucent 2010...
-
Page 21: Third-Party Certificate Management
Path: path to your directory containing certificates Used MAC@file: Choose Yes if the name of the file is MAC @ File: name of the file containing the certificate Type: Custom cert 1 or 2 6- Get: OK Page 21 All Rights Reserved © Alcatel-Lucent 2010... -
Page 22: Phone Features
The word Conference is displayed on the set. Press the OK key to start the conference. Press the OK key (or hang up) to end the conference. Page 22 All Rights Reserved © Alcatel-Lucent 2010... -
Page 23: Speed Dialing Keys
When a new message has been received, the voice mail LED is on. LCD will indicate one more new message after pressing voice mail key. Note: In conversation, a SIP set switches automatically to DTMF mode. Page 23 All Rights Reserved © Alcatel-Lucent 2010... -
Page 24: Troubleshooting
Server is not responding BAD IP ADDRESS IP address is incorrect BAD ROUTER ADDRESS Router address is incorrect ROUTER PING FAILED Router not responding to ping BAD TFTP ADDRESS TFTP server address is incorrect Page 24 All Rights Reserved © Alcatel-Lucent 2010... - Page 25 2/5 network setup Phase 2 is running: the set is looking for IP addresses 3/5 config download Phase 3 is running: the set is trying to get a lanpbx file Page 25 All Rights Reserved © Alcatel-Lucent 2010...
-
Page 26: Ethernet Link
IP Touch set to an external device (switch on LAN side, PC on PC side). For each combination, the table shows the link status: valid or invalid (duplex or speed mismatch), as described above. Page 26 All Rights Reserved © Alcatel-Lucent 2010... -
Page 27: Net Log
In order to activate this net log function, telnet service must be available. On administrator console, type telnet SIP phone IP @ Telnet window appears. Enter telnet password (password stored in sipconfig.txt or sipconfig- mac@.txt). Page 27 All Rights Reserved © Alcatel-Lucent 2010... - Page 28 Type the following command netlog [<live|boot>_<disable|enable> | <list|save|dump>_config | {server <addr>} | {config <n>} | {uptime <minutes>} | {dump_config <n>}] Example: telnet 172.26.179.207 Enter the password defined in the sipconfig.txt or sipconfig-mac@.txt file. Page 28 All Rights Reserved © Alcatel-Lucent 2010...
- Page 29 Page 29 All Rights Reserved © Alcatel-Lucent 2010...
