Summary of Contents for APART SDQ5P

  • Page 1 SDQ5P Instruction manual...
  • Page 3 SDQ5P Instruction manual SDQ5P Manual...
  • Page 4: Safety Instructions

    Active loudspeaker set Safety instructions • Caution! This professional device needs to be installed by qualified personnel only. • Please check the carton box for any kind of damage on reception of the goods. In case of a damaged carton, please contact your dealer before opening the carton.
  • Page 5 SDQ5P Instruction manual • Set level controls on amplifiers all the way down during power- up to prevent speaker damage if there are high signal levels at the inputs. • Do not connect the inputs / outputs of amplifiers or consoles...
  • Page 6 Active loudspeaker set Features • The Apart SDQ5P powered loudspeaker set is a versatile and very compact, easy to use, plug and play sound system. It consists of an amplified loudspeaker with a 5.25” woofer, a high frequency unit and a second linkable passive loudspeaker, powered by the second amplifier built into the active speaker.
  • Page 7 • When the product shows signs of damage caused by transportation, contact your dealer immediately. Damage due to transport and rough handling is not covered by the manufacturer’s warranty. • The SDQ5P complies with CE regulations.
  • Page 8: Rear Panel

    Active loudspeaker set Rear panel 1. Volume control: set the desired volume. 2. Treble control: add or decrease the high frequencies. Adding high frequencies may improve intelligibility. Adjust to the desired level. 3. Bass control: add or decrease the low frequencies. Decreasing bass can improve the intelligibility of spoken messages, especially in reverberant rooms.
  • Page 9 !!! Connect + to + and – to -. 10. Mode switch: this switch turns your SDQ5P in a full stereo or a very compact mono system. When switched to mono mode, use the “Left” input only. The audio signal from the left input will sound through both speakers.
  • Page 10: Technical Specifications

    Active loudspeaker set Technical specifications input sensitivity RCA and stereo mini jack 500 mVrms input impedance RCA and stereo mini jack 22 Kohm input sensitivity Balanced Euroblock 500 mVrms input impedance Balanced Euroblock 22 Kohm tone control bass +/- 12 dB at 80 Hz tone control treble +/- 12 dB at 12 KHz low impedance dynamic power...
  • Page 11 SDQ5P Instruction manual Notes...
  • Page 12 Apart Audio NV Industriepark Brechtsebaan 8 bus 1 2900 Schoten - Belgium Company names, product names and trademarks are property of their respective owners. Apart-Audio specifications are subject to change without notice.
