INSTALLATION &
OPERATION MANUAL
IPSi2400 Series
PURE-SINE INVERTER
An ISO9001 and AS9100 Registered Company
Battery Chargers
•
Inverters
•
Power Supplies
•
Voltage Converters
8128 River Way, Delta B.C. V4G 1K5 Canada T. 604.946.9981 F. 604.946.9983 TF. 800.668.3884 (US/CANADA)
www.analyticsystems.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the IPSi2400 Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Analytic Systems IPSi2400 Series

Summary of Contents for Analytic Systems IPSi2400 Series

  • Page 1 INSTALLATION & OPERATION MANUAL IPSi2400 Series PURE-SINE INVERTER An ISO9001 and AS9100 Registered Company Battery Chargers • Inverters • Power Supplies • Voltage Converters 8128 River Way, Delta B.C. V4G 1K5 Canada T. 604.946.9981 F. 604.946.9983 TF. 800.668.3884 (US/CANADA) www.analyticsystems.com...
  • Page 2 Medical Equipment Notice Analytic Systems does not recommend the use of their products in life support applications where failure or malfunction of this product can be reasonably expected to cause failure of the life support device or to significantly affect its safety or effectiveness.
  • Page 3 • Product Warnings and Advisories • Table of Contents • Introduction • Box Contents • Main Parts • Operation • Two-Stage Charging • Installation • Troubleshooting • Specifications • Warranty Copyright (2005-2017) Analytic Systems Ware (1993) Ltd. Revised - September 20,2017...

  • Page 4: Box Contents

    • This User Guide (A PDF copy can be downloaded from www.analyticsystems.com) • Optional InverterWizard software can be downloaded from www.analyticsystems.com If anything is damaged or missing from your box, please contact your dealer or Analytic Systems for a replacement.

  • Page 5: Main Parts

    Main Parts Front Panel 1. Remote Control Connection Port 7. AC Output Connection: Phoenix VDFK4 Terminal Block 2. MicroUSB Port 8. AC Output Connection: 5-15 3. DC Input Connection: Marathon Power NEMA Outlet Stud Block (1/4” studs) 9. Thermal Carling 20A 4.

  • Page 6: Operation

    Operation Before operating, the Inverter must be properly installed and the load and power source must be properly connected. See Installation, DC Connections, and AC connections for more information. The IPSi2400 is designed for simple and intuitive operation. It is also designed to function unattended and will automatically attempt to recover from any alarm conditions or malfunctions.

  • Page 7: Installation

    Installation Mounting Mount the Inverter in a WELL VENTILATED and DRY area with at least 1 inch (2.54 cm) of clearance all around the unit. DANGER: Do not mount the unit anywhere explosive gases can accumulate. A slight arc may form when the power leads are connected and, in the unlikely event of a failure, sparks may be generated inside the unit.

  • Page 8: Dc Input Connection

    DC Connections BEFORE MAKING ANY CONNECTIONS, MAKE THE POWER SWITCH IS OFF. DC INPUT CONNECTION Before making any connections to the unit, you will need to prepare an external circuit breaker or fuse for the DC power source. See Specifications for the appropriate rating. This unit is equipped with a Marathon Terminal Block connector with 4 1⁄4”...

  • Page 9: Ac Output Connections

    AC Connections BEFORE MAKING ANY CONNECTIONS, MAKE THE POWER SWITCH IS OFF. AC OUTPUT CONNECTIONS This unit is equipped with two AC Output connections. • A standard NEMA 5-15 AC receptacle is provided for connection. This connection is protected by a Thermal Carling 15A circuit breaker. •...
  • Page 10 Pins 4 (Blue), 5 (White/Blue) and 6 (Green) are an isolated RS232 port that can be used for communication to/from the Inverter. Information on the standard data structure or custom programming is available from the Analytic Systems. Pin 4 is RX, Pin 5 is TX and Pin 6 is Return.
  • Page 11 Off-line UPS (Optional) The Off-line UPS (Uninterrupted Power Source) option allows the Inverter to be used as a backup power source in the event of external AC power failure. To set up the Off-line UPS Connect the external AC power source to the AC Input Connection. Connect the batteries to the DC Input Connection.

  • Page 12: Troubleshooting

    Troubleshooting This unit features eight LED indicators and an alarm buzzer to help diagnose any malfunctions. The Inverter will sound the buzzer to alert you prior to shutting down. You should immediately check the LED indicators to determine the cause of the shutdown. LED Indicator Meaning LOW VOLTAGE...

  • Page 13: Specifications

    -25°C to +40°C @ maximum output Isolation Input-Output, Input-Case & Output-Case: 1500VDC Safety Built to CSA 22.2.107.1 & UL458 standards Designed and manufactured by: ANALYTIC SYSTEMS WARE (1993) LTD. 8128 River Way p. 604.946.9981 f. 604.946.9983 Delta, BC V4G 1K5 Canada tf. 800.668.3884 US/Canada www.analyticsystems.com...

  • Page 15: Limited Warranty

    2 Years from date of manufacture for non-standard or OEM products 1 Year from date of manufacture for encapsulated products. 3. Analytic Systems will determine eligibility for warranty from the date of purchase shown on the warranty card when returned within 30 days, or...
  • Page 16 DESIGNED AND MANUFACTURED BY 800-668-3884 604-946-9983 sales@analyticsystems.com www.AnalyticSystems.com Battery Chargers • Inverters • Power Supplies • Voltage Converters 8128 River Way Delta, BC V4G 1K5 | Canada Register Products Online | www.analyticsystems.com/support/warranty-registration...
