When the user sets the safety space and the robot moves into the safety space, the robot will
enter the collaborative mode. At this time, the purple light will be added. Please refer to the
following table for the definition of each status:
Mode
Manual Mode
Auto Mode
I Hardware Installation Manual 4. System Hardware
Standby/running
Standby status
Project running
Standby status
Project running
Space
Full speed Space
Collaboration Space
Stop Space
Full speed Space
Collaboration Space
Stop Space
Full speed Space
Collaboration Space
Stop Space
Full speed Space
Collaboration Space
Stop Space
Color/blinking
Solid green light
Alternating between
Green(9)/ Purple(1)
Alternating between
Green/ Red
Flash green light
Alternating between
Purple/ Red
Alternating between
Green/ Red
Solid blue light
Alternating between
Blue(9)/ Purple(1)
Alternating between
Blue/ Red
Flash blue light
Alternating between
Purple/ Red
Alternating between
Blue/ Red
40
