8.5.6.3.3. Control Options Screen
PI PARAMETERS
P: 2.0
I: 0.10
TEMP: FAHRENHEIT
The PID Parameters have been set to default
values 2.00 and 0.10. These values should not need to
be changed.
TEMP: Used to set the HHT display option. All
temperatures are in degrees Celsius internally, but
when TEMP is set to Fahrenheit (default) they are
displayed as Fahrenheit.

8.5.7. Upgrading ACC Using HHT

Return to the main HHT screen by pressing F1 for
approximately 6 seconds (if you are talking to an
ACC and in the ACC mode)
SELECT
1= SLAVE TERMINAL
2= ACC HHT MODE
3= UPGRADE ACC FW
Select 3 for upgrade firmware and a new screen
will appear:
CONTROLLINK ACC
VER: 3.10B006
SLOT: 1
UPGRADE: NO
Use the right/left arrow to see the arrow appear
next to NO (default). Press the – (dash) button to
toggle to YES.
ACC SETUP:
BAUD: 19200
PARITY: NONE
ADDR: 1
Select the address of the ACC to upgrade.
Press the down arrow to start the upgrade. The
Block number will update as blocks are sent to the
ACC.
26 • Control Link ACC I&O Manual
CNT: 0
If the upgrade was successful this screen will
display:
UPGRADE RESULT:
FIRMWARE UPDATED
Press the down arrow to go to the Menu screen.
8.5.8. Changing ACC Address Using
HHT
If you are setting the address of the ACC with the
HHT, you must be connected directly to one and only
one ACC. From the Home screen, choose 2 (ACC
HHT mode), choose the address, and press down
arrow. (The user can also set the baud and parity,
19200 and no parity is recommended)
ACC SETUP:
BAUD: 19200
PARITY: NONE
ADDR: 1
Pressing the down arrow may show you the next
screen if the HHT doesn't find an ACC at that selected
address.
ONE-ON-ONE?
NEED TO SET NODE
BAUD AND PARITY.
PROCEED?: NO
The HHT will ask if you are connected to the ACC
that you wish to communicate with directly; the user
has to be connected directly to set the address of an
ACC. Press the left or right arrow keys to display the
arrow next to the NO (default). Press the - (dash) key
to toggle it to YES.
Once the address (and/or baud and parity) is
changed, you will be connected in ACC HHT mode
and you will see the ACC Home Screen. See Section
8.5.4. for more details.
NOTE: If the address is already pre-set on the
ACC using the dip switches, the address cannot
be changed with the HHT. The pre-set dip
switches on the ACC will always take priority.
