Hwasung HP-500 User's & Technical Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Technical Manual
(Model : HP-500)

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the HP-500 and is the answer not in the manual?

Questions and answers

Related Manuals for Hwasung HP-500

Summary of Contents for Hwasung HP-500

  • Page 1 Technical Manual (Model : HP-500)
  • Page 2 • Please clear the air / open the disclosed place. • Please set the product without damage enviornment. • Please set the product at the stable place. • Pleaes keep the requires as necessary as general electrics. Title Rev. Page HP-500 Ver 1 Ver1.0...

  • Page 3: Table Of Contents

    4-4)BlueTooth 5. Command 6.Windows Driver 6-1) Set up the function 6-2) Set up the paper 6-3) Set up the new paper 7. USB User Interface 7-1) functions 7-2) Caution for using USB Interface Title Rev. Page HP-500 Ver 1 Ver1.0...

  • Page 4: Printer Features & External Dimension

    1. Printer features & External Dimension 1-1) Name of each parts 1. Button and LED 2. Open Lever 3. Maual Cutter 4. Battery 5. DC Connect 6. USB/RS232C Interface Title Rev. Page HP-500 Ver 1 Ver1.0...

  • Page 5: 1-2) Operation Part

    ② Open the paper cover and Press the FEED button for 2 seconds. ③ When Melody is alaming, Put the paper of label in the printer and close the paper cover. When it comes back to Receipt Option, Please follow this step again. Title Rev. Page HP-500 Ver 1 Ver1.0...

  • Page 6: Operation

    The paper setting up is as below. ① Open the cover in Mobile Printer by Lever ② Please insert the paper, till the paper comes out from the cover. Lever ③ Close the cover and cut the extra paper. Title Rev. Page HP-500 Ver 1 Ver1.0...
  • Page 7 Please turn off and on the power, while you press down the feed button. And you can see the Error Led light kept then the following informations are being feeded. ******************************  Model. HP-500 Control Board  Firmware version / creare date. Firmware :: Ver0 .45 ...
  • Page 8 3) Successively, select from printed items and confirm. Ex) [Wireless Type] 1.WiFi -> 2.Bluetooth -> : Indicate current set status Select and then Enter... Ex) In here, arrow((->) indicates current settings. To change, select item and enter. TO move to Title Rev. Page HP-500 Ver 1 Ver1.0...

  • Page 9: 2-4) Hex Dump

    A B C D E F G H I 30 31 32 33 34 35 36 37 38 0 1 2 3 4 5 6 7 8 FF 1B 69 ^ . i Title Rev. Page HP-500 Ver 1 Ver1.0...
  • Page 10 Please stop the update program and make sure the cable and other connections. Please return the process “1.” and follow the step again. 5) Atfer update, automatically the printer will be reset for using and use the printer. Title Rev. Page HP-500 Ver 1 Ver1.0...

  • Page 11: 2-6) Memory Switch

    1) 2byte codes : korean(24 x 24), korean(16 x 16), Japenes(24x24), Chinese(24x24). 2).1byte codes : ASCII(12x24), ASCII(8x16,9x16) Reservation Reservation Reservation Setting paper Code Page Manu Font Manu After setting, Press the button Title Rev. Page HP-500 Ver 1 Ver1.0 P.10...
  • Page 12 [Memory Switch information] ================================ Code Page = PC437(U.S) 2Byte Font = Korean(24x24) 1Byte Font = ASCII(12x24) Mem1:FFh Mem2:FFh,FFh Mem3:FFh,FFh Mem4:00h Mem5:00h Mem6:FFh Mem7:FFh Mem8:FFh Mem9:FFh Mem10:FFh Mem11:40h Mem12:F9h (Ex) Sample of printing by selftest Title Rev. Page HP-500 Ver 1 Ver1.0 P.11...
  • Page 13 ③ Turn on the printer and atfer 3 second automatically IP Address and SSID and Password will be printed. ④ And please connect with PC or Smart Phone then put in the SSID and Password. ⑤ When the connection is complete, using IP address printed. Title Rev. Page HP-500 Ver 1 Ver1.0 P.12...

  • Page 14: Genearl Specification

    1) Temperature : 0∼40℃ 2) Humidity : 40∼90%RH(in not dew condensation) Notice : The printing is subjet to the operation condition. 3-6) MCBF 1) Mechanism : 15,000,000 Lines. 2) Thermal Print Head 50Km, 1 pulse. Title Rev. Page HP-500 Ver 1 Ver1.0 P.13...

  • Page 15: Interface Specification

    1) Standard : IEEE 802.11b/g/n, 2) Frequency : 2.400 GHz ~ 2.484 GHz 3) Channel : CH1 ~ CH11 4) Security : WEP, WPA/WPA2PSK 4-4) BlueTooth 1) Standard : Bluetooth 3.0 Class2 Title Rev. Page HP-500 Ver 1 Ver1.0 P.14...

  • Page 16: Command

    Printing and row FEED ESC { 180° rotation ESC t Code page (International) ESC S Standard mode / Clear the area of page ESC L Page mode ESC FF Printing of page area Title Rev. Page HP-500 Ver 1 Ver1.0 P.15...
  • Page 17 Barcode (Extension / Reduction) GS r Status check GS a Status check (Auto reply) GS v Laster bit image (Horizontal) DLE ENQ Buffer clear (real time) DLE EOT Status transmission (real time) Title Rev. Page HP-500 Ver 1 Ver1.0 P.16...
  • Page 18 Print the data in the print buffer and returns to standard mode [Caution] Use the command ESC+FF , in order not to return the standard mode. The data is not deleted in the area of page. Title Rev. Page HP-500 Ver 1 Ver1.0 P.17...
  • Page 19 Please choose the barcode by the data of barcode. n1 : two dimension of barcode n2 : the number of data of barcode n3 : size of barcode d1… dk : the data of barccode Barcode PDF417 QR code Title Rev. Page HP-500 Ver 1 Ver1.0 P.18...
  • Page 20 It clears all of line zero (0). [Caution] Please use this command to write the line again. Please use the command line ON/ line OFF to write line 1 to speed up the progress. Title Rev. Page HP-500 Ver 1 Ver1.0 P.19...
  • Page 21 Set the space amount on the right of ASCII character [Format] ASCII Decimal 0≤n≤255 [Range] [Initial Value] [Descript] Set in n x 0.125mm the space amount on the right of ASCII character [Caution] Set the Korean space in FS+’S+n Title Rev. Page HP-500 Ver 1 Ver1.0 P.20...
  • Page 22 [Name] Set the bitmap image [Format] ASCII d1…dk d1…dk Decimal d1…dk [Range] m=0,1,32,33 1≤nL+nH×256≤1023, 0≤nL≤255, 0≤nH≤3, 0≤d≤255 [Descirpt] Due to fixing nL+nHx256, Printing from bit data to graphic data in Mode m Title Rev. Page HP-500 Ver 1 Ver1.0 P.21...
  • Page 23 Mode Dots in Dots in Data (k) vertical horizontal 8dots Single Density nL+nH×256 8dots Double Density nL+nH×256 24dots Single Density (nL+nH×256)×3 24dots Double Density (nL+nH×256)×3 •8 dots Mode Twice once Single Double Title Rev. Page HP-500 Ver 1 Ver1.0 P.22...
  • Page 24 Set underline in thick 0.75mm Set underline in thick 0.875mm ESC+’2’ [Name] Set the interval of initial line [Format] ASCII Decimal 0≤n≤255, [Range] [Initial Value] [Descirpt] Set the interval of initial value in 4mm Title Rev. Page HP-500 Ver 1 Ver1.0 P.23...
  • Page 25 Printing the data inner buffer, feeding in n x 0.125mm ESC+’j’+n [Name] Back Feeding [Format] ASCII Decimal 0≤n≤255 [Range] [Descript] Printing the data inner buffer and back feeding in n x 0.125mm Title Rev. Page HP-500 Ver 1 Ver1.0 P.24...
  • Page 26 Select the International character [Format] ASCII Decimal 0≤n≤13 [Range] [Initial Value] n=13 [Descirpt] Select the international character as follows:- Country Name France Germany England Denmark1 Sweden Italian Spain1 Japanese Norway Denmark2 Spain2 Latin America Korea Title Rev. Page HP-500 Ver 1 Ver1.0 P.25...
  • Page 27 You can see the following table of the international code page. [Caution] It is valid, if you direct the command SUB+”x” for 1 byte. It is not valid, if you direct the command SUB+”x” for 2 bytes. Title Rev. Page HP-500 Ver 1 Ver1.0 P.26...
  • Page 28 Switches from standard mode to page mode ESC+FF [Name] Printing as the page mode [Format] ASCII Decimal [Descript] It prints the data at the page mode. (The data is NOT deleted at the page.) Title Rev. Page HP-500 Ver 1 Ver1.0 P.27...
  • Page 29 Select print direction in page mode [Format] ASCII Decimal 0≤n≤3 [Range] [Initial Value] [Descript] Select the print direction & start position in page mode •n=0(Left→Right), •n=1(Bottom→Top), ABCD Feeding Feeding •n=2(Right→Left), •n=3(Top→Bottom), Feeding Feeding Title Rev. Page HP-500 Ver 1 Ver1.0 P.28...
  • Page 30 : Barcode or Graphic Paper Paper EFGH Standard Printing before ABCD (x,y) moving the standard line Move the standard line Printing Area by CR or LF EFGH (x+dx,y+dy) Printing after ABCD moving the standard line Title Rev. Page HP-500 Ver 1 Ver1.0 P.29...
  • Page 31 Decimal [Descript] Cancel Korean mode (2Bytes mode) [Caution] In case of cancel 2 bytes mode in extended graphic mode Appointment is not required due to auto detection in Korean mode (Ref.SUB+’x’+n command) Title Rev. Page HP-500 Ver 1 Ver1.0 P.30...
  • Page 32 Set the font size in Korean [Format] ASCII Decimal 0≤n1≤255 [Range] [Initial Value] [Descript] Set the Korean font size twice (HorizontalxVertical) in Korean n=0, Cancel the font size two times n=1, Set the font size two times Title Rev. Page HP-500 Ver 1 Ver1.0 P.31...
  • Page 33 [Descript.] m : printing the registered N/V in ‘m’ mode n : indicating the regsitered logo in the ‘n’. Printing mode Standard Horizontal extension Vertical extension Horizontal,vertical extension in the same time Title Rev. Page HP-500 Ver 1 Ver1.0 P.32...
  • Page 34 8.0 ~ 8.3V 8.4V ~ 8.5V ※ Once it is a power on reset, the density is set up automatically, You can choose the density as per the conditions, such as power,printing quality. Title Rev. Page HP-500 Ver 1 Ver1.0 P.33...
  • Page 35 [Format] ASCII Decimal 0≤n≤3 [Range] [Initial Value] [Descript] Select the printing positions of numerical value & characters Printing Position Non printing Above the barcode Below the barcode Both above & below barcode Title Rev. Page HP-500 Ver 1 Ver1.0 P.34...
  • Page 36 Select barcode height by n×0.125mm GS+’k’+m+d1…dn+NUL [Name] Print barcode [Format] ASCII d1…dn NUL d1…dn 00h Decimal d1…dn 0 1≤m≤7, n & d depend on barcode system used [Range] [Descript] Refer the table as below Title Rev. Page HP-500 Ver 1 Ver1.0 P.35...
  • Page 37 Module barcode width Narrow Wide 0.25mm 0.125mm 0.375mm 0.375mm 0.25mm 0.625mm 0.5mm 0.375mm 0.625mm 0.5mm 1.25mm * Multi Level barcode : UPC-E, EAN13, EAN8 * 2 level barcode : CODE39, ITF, CODABAR Title Rev. Page HP-500 Ver 1 Ver1.0 P.36...
  • Page 38 0 : Print complete 1 : Print or Feeding ※ the status of bit 4 is effective when the realtim e conducts the command DLE + EOT + n, The others are fixed ‘0’. Title Rev. Page HP-500 Ver 1 Ver1.0 P.37...
  • Page 39 It’s only valid as you switch up ‘1’ as ‘ON’. This command is only effective if the printer is off. This command is only effective if it receives the data as same command. This command is not effective if it’s online. Title Rev. Page HP-500 Ver 1 Ver1.0 P.38...
  • Page 40 It’s only valid as you switch up ‘1’as ‘ON’. Please refer status table at the page 29. If the command is received same data, it could be same operation (Bit image data,etc) Title Rev. Page HP-500 Ver 1 Ver1.0 P.39...
  • Page 41 4) Please type the width 6.0 cm / the height 15.0 cm as image. 5) Please click the ‘form install’ Ticket (Size 60 x 150mm) as image. 6) Please click the tap ‘advanced’ and set the paper Ticket(Size 60 x 150mm). Title Rev. Page HP-500 Ver 1 Ver1.0 P.40...
  • Page 42 7-1) DLL Interface Please add the file HwaUSB.DLL at the folder System 32, or the folder SysWow64. 7-1-1) DLL function. 1) long UsbOpen(LPCTSTR SelPrinter); Please open the port USB by the printer Model “HP-500”  Parameters: SelPrinter : Printer Model Name ...
  • Page 43 Return : Print normal : 1 Print error Notice Please do not use any function we don’t provide, due to the debug usage. Notice Please ask the sample program for more details. Title Rev. Page HP-500 Ver 1 Ver1.0 P.42...
  • Page 44 If you release the spool, the data receipt is only made by USB Interface. ※ The Data diafram of window application. Window Driver (Graphic) Window Application USB Port Printer DLL Interface OCX Driver (Command, Character) Send Receive (Printer State Date) Title Rev. Page HP-500 Ver 1 Ver1.0 P.43...
  • Page 45 Date Descripction Page Ver. 2017.05.02 Release HP-500 V1.0 V1.0 Title Rev. Page HP-500 Ver 1 Ver1.0 P.44...
  • Page 46 Any changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate this equipment. This transmitter must not be co- located or operating in conjunction with any other antenna or transmitter. Title Rev. Page HP-500 Ver 1 Ver1.0 P.45...
