Troubleshooting; Specifications - Ivation IVALDH95PWWP User Manual

Troubleshooting

Problem
Unit does not start
Unit does not opperate efficiently/runs too much
The unit makes a loud noise while operating
Frost appears on the coils
Water leaking from unit
Pumping indicator light blinking
Unit is operating but room is not dry enough

Specifications:

Rated power: 115V, 60Hz
Power input: 680W
Rated current: 6.8A
Refrigerant: R410A/14.64 oz.
Moisture removal: 95 pints/day
EEV: 2.0L/kW.H
Design pressure: 540PSIG/300PSIG
Airflow: 457 – 482m3/h / 269 – 284 CFM
Reservoir capacity: 21 pints (10L)
Noise level: 58/56dbA
Selectable relative humidity range: 35% – 85%
Environment ambient temp: 41°F (5°C) – 95°F (35°C)
Dimensions: 18.8" x 14.2" x 24.6" (47.7 x 36 x 62.5cm)
Weight: 60.6 lbs. (27.5kg)
Make sure the power cord and plug are not damaged and that the plug is
pushed completely into the wall socket.
Check the fuse/circuit breaker box.
Reservoir may be full.
Reservoir not in the proper position.
Unit has cycled off because the desired humidity level has been reached.
Enough time to dry the air has not been allowed.
Vents or hoses may be blocked.
The humidity selected may not be low enough.
Doors or windows in the room are open.
Room temperature is too low (below 41°F/5°C).
A kerosene heater or other appliance is giving off water vapor in the room.
Air grilles may be obstructed or dirty.
Room area is too large.
The air filter is clogged.
The unit is tilted or not placed on a level surface.
This is normal. The Auto Defrost feature will remove the frost.
Hoses or connectors may be loose.
The drain plug in the back of the unit has been removed when the
reservoir is being used to collect water.
Pump filter may be dirty or clogged.
Pump drain hose may be obstructed or kinked.
The humidity setting may be too high. We recommend setting the RH% to
at least 10% lower than the current RH%.
Ensure there is at least 10" of clearance for proper ventilation.
The appliance will not operate satisfactorily if the room temperature is
below 41°F/5°C.
Close windows or doors.
Possible Causes
