Ivation IVALDH95PWWP User Manual page 9

2. Continuous Draining (Gravitational)
Water can be automatically emptied into a floor drain by attaching a hose with a female threaded end
(not included) to the continuous drain hose.
a) Remove the plastic cover from the drain outlet in the back of the unit. Water may drip from the outlet if
the dehumidifier was previously used.
b) Remove the water reservoir. Insert drain hose through the drain outlet in the back of the unit. Connect
it to the connection point inside the unit and press it securely into the place.
c) Tighten the adapter and the unit with two screws (not included).
d) Install the female threaded end of the water hose into the adapter, then lead the water hose to the
floor drain or a suitable drainage facility.
NOTE: Make sure the connection is tight and there are no leaks. The floor drain or other suitable drainage
facility should be lower than the drain outlet of the unit. When the continuous drain feature is not being
used, remove the drain hose from the outlet.
PLASTIC COVER
DRAIN HOSE
SUBASSEMBLY
3. Pump Draining
Water can be pumped from the unit into a floor drain or a suitable drainage facility, and also pumped
up with approximately 15 ft. of vertical lift. When activated, the pump will begin to operate when the
reservoir is 3/4 full.
a) If a water drain hose has been used for continuous gravitational draining, remove it and the drain hose
assembly. Place the cover back onto the outlet.
b) Insert one end of the pump drain hose into the pump
drain hose outlet. Lead the other end of the hose to a
suitable drainage facility.
c) Press the pump button on the control panel. Some
operational noise for the first 3 – 5 minutes is normal.
NOTE: Do not use this feature when the outdoor
temperature is equal to or less than 32°F (0°C) as
discarded water may freeze and damage the unit.
CONNECTOR
DRAIN HOSE
FEMALE
THREADED
END
WATER HOSE
REINSTALL THE PLASTIC COVER
USING TWO SCREWS.
REMOVE THE DRAIN HOSE
AND DRAIN HOSE SUBASSEMBLY.
PUMP DRAIN
INSERT PUMP
HOSE OUTLET
DRAIN HOSE TO
THE DRAIN HOSE
OUTLET
