Magic Matrix
This product manual contains important information about the
safe installation and use of this projector. Please read and follow
these instructions carefully and keep this manual in a safe place
User manual
Please read the instructions carefully before use
1

Advertisement

loading

Related Manuals for Brighter Magic Matrix

Summary of Contents for Brighter Magic Matrix

  • Page 1 Magic Matrix This product manual contains important information about the safe installation and use of this projector. Please read and follow these instructions carefully and keep this manual in a safe place User manual Please read the instructions carefully before use...

  • Page 2: Table Of Contents

    TABLE OF CONTENTS 1. Safety Instructions ..................... ……………………………..3 2. Technical Specifications ..................……………………………..4 3. How to control the device ................. ……………………………..5 4. How to control the device with Art-net ............. …………………..13 5. Troubleshooting ....................……………………………..13 6. Cleaning the device…..…………………………………………………………………………………………..…………….……….14 Statement The product has full capability and intact packing when it leaves factory.

  • Page 3: Safety Instructions

    1. Safety Instructions  Please keep this User Guide for future consultation. If you sell the unit to another user, be sure that they also receive this instruction booklet.  Unpack and check carefully there is no transportation damage before using the unit. ...

  • Page 4: Technical Specifications

    2. Technical Specifications  Light Sources: 25x 4in1 RGBW LED  LENS Beam Angle: 6.5-60°  Power Consumption: 484W  Power Voltage: AC 100-240V, 50/60H  Dimension: 40*31*47CM  Net Weight: 14Kgs Control  Control Modes: DMX512,Artnet control  DMX mode: 13/ 24/88/113 Channels ...

  • Page 5: How To Control The Device

    3. How To Control the device The DMX512 is widely used in intelligent lighting control system. Connect several lights together with a DMX 512 controller. DMX in and DMX out, 3 pin XLR connectors are: Pin 1: GND, Pin 2: Negative signal (-), Pin 3: Positive signal (+) Display: MENU...
  • Page 6 Menu: Address Address 001~XXX Set DMX Address Display DMX DMX Value ALL.. Value LED Temperature XXXC/F Current Hours Fixture Hours Total Hours Last Hours X.X.X.X IP Address Ethernet IP X.X.X.X IP Mark Software Version VX.X.X… Software Version Pan Reverse ON/OFF Tilt Reverse ON/OFF Pan Tilt...
  • Page 7 ZOOM ZOOM=XXX Rotation Rotation=XXX Reset Reset ALL Reset All Motors Standard Standard Mode Shape RGB Shape Mode With RGB DMX Mode Shape RGBW Shape Mode With RGBW DMX&Net RGB Shape Mode With RGB While DMX&Art-Net select DMX&Net RGBW Shape Mode With RGBW While DMX&Art-Net select 1.
  • Page 8 Value Mode/Channel Shape Shape DMX&Net DMX&Net RGBW RGBW Standard PAN Movement 8bit : 0-255 Pan Movement Pan Fine 16bit 0-255 Fine control of Pan movement TILT Movement 8bit : Tilt Movement 0-255 Tilt Fine 16bit 0-255 Fine control of Tilt movement Speed Pan/Tilt movement: 0-255 max to min speed...
  • Page 9 180-239 Gamma 2.6 240-255 Gamma 2.8 Rainbow: No function 8-39. RED to YELLOW 40-71 YELLOW to GREEN 72-103 GREEN to CYAN 104-135 CYAN to BLUE 136-167 BLUE to MAGENTA 168-199 MAGENTA to RED 200-231 RED to WHITE 232-255 Crossfading colours from slow to fast Color Presets: No function 5--9...
  • Page 10 0-255 Dimmer 100 to 0% Chase Patterns: No function 6-10 Number'0' 11-15 Number'1' 16-20 Number'2' 21-25 Number'3' 26-30 Number'4' 31-35 Number'5' 36-40 Number'6' 41-45 Number'7' 46-50 Number'8' 51-55 Number'9' 56-60 61-65 66-70 71-75 76-80 81-85 85-90 91-95 96-100 101-105 106-110 111-115 116-120 121-125...
  • Page 11 236-240 Pattern function8 241-245 Pattern function9 246-250 Pattern function10 251-255 Pattern function11 Chase Patterns Direction: 0-49 ↑Chase Up 50-99 ←Chase Left 100-149 ↓Chase Down 150-255 →Chase Right Chase Speed: 0-125 Fast to Slow Backward 126-130 Stop(Speed=0) 131-255 Slow to Fast Forward Chase Fade: 0-255 Fade Chase...
  • Page 12 0-255 Red ( 0-Black , 255-100% Red ) Green LED-array 3 0-255 Green ( 0-Black , 255-100% Green ) Blue LED-array 3 : 0-255 Blue ( 0-Black , 255-100% Blue ) White LED 0-255 White ( 0-Black , 255-100% White ) Red LED -array 4 0-255 Red ( 0-Black , 255-100% Red )

  • Page 13: How To Control The Device With Art-Net

    4. How to control the device with Art-Net 1. Setting IP Address, choose Manual set to input IP address manually. You can also choose ON IP2 or ON IP10 auto set. 2. IP Mask, input 255.0.0.0 3. Universe choose OFF or 1 4.

  • Page 14: Cleaning The Device

    3. If you have intermittent DMX signal problems, check the pins on connectors or on PCB of the unit or the previous one. 4. Try to use another DMX controller. 5. Check if the DMX cables run near or alongside to high voltage cables that may cause damage or interference to DMX interface circuit.
