Chapter 6: Parts Lists, Schematic Diagrams and Warranty

Parts List - Handlebar Assembly

NOTE: Part numbers listed are available through DR Power Equipment.
Ref# Part# Description
1 13905 Cable, Throttle, 50"
2 35283 Tank, Gas, Assembly, EPA/CARB
3 34432 Bracket, Battery
4 34443 Strap, Tank
5 33332 Nut, Nylon Lock, Flanged, 5/16-18
6 26575 Carbon Canister, 300cc, 3/16" Ports
7 24230 Strap, Battery
8 13447 Battery, 12v, 9Ah
9 33331 Nut, Nylon Lock, Flanged, 1/4-20
10 35033 Bolt, Carr, 5/16-18 X 1.75", GR5, ZP
11 12797 Cable Tie, 17", # 50
12 35115 Cable, Brake
13 30297 Lever, Brake, W/O Hardware
14 11214 Cable Tie, 7-1/2" Long
15 35281 Bolt, Hex, Flange, Tri Lobe, 3/8-16 X
3/4", GR5, ZP
16 35983 Harness, Wire, ES, B&S
35982 Harness, Wire, Briggs, M/S
17 34428 Handlebar, Left
18 34429 Handlebar, Right
19 16519 Switch, Snap-In, E/S
20 15720 Key, Ignition Switch
21 19123 Switch, Push/Pull
22 33333 Nut, Nylon Lock, Flanged, 3/8-16
23 35106 Lever, Shift
®
DR
26 FIELD and BRUSH MOWER
Ref# Part# Description
24 35107 Mount, Lever, Shift
25 18069 Lever, Op Presence W/ Harness
26 16496 Grip, 1.00"
27 37052 Lever, Cable, Black, Traction Drive
28 35118 Cable, Traction Drive
29 35275 Console, With Label
30 35274 Label, Control Panel, Front
31 11173 Bolt, HCS, Serrated Flange, 5/16-18 X
.50"
32 35131 Cable, Shift
33 15036 Knob, PTO Clutch Cable
34 16497 Guard, Switch, Magura
35 35277 Panel, Control, With Label
36 35276 Label, Control Panel, Top
37 36372 Label, Warning
38 36373 Label, Wheel Speed and Throttle
39 15131 Plug, Hour Meter Hole, 2" X 1-1/4"
40 35290 Bolt Shoulder, 1/2" X 5/8"l, 3/8-16
41 15049 Screw 8-32 x 1/2"
42 19003 Plug, Plastic, 1/2" Hole
43 17923 Screw, SHCS, M6 X 25mm
44 36353 Harness, Ground
45 35051 Spacer, Idler
46 37090 Washer, Star, Internal, 7/16", ZP
