４－４．Setting DRIVE CURRENT SELECT switch
(1) Set the switch No. to the setting specified in the table "10-4. Applicable Motors."
●Relationship between the DRIVE I.SEL switch No. and DRIVE CURRENT.
DRIVE I.SEL
No.
A high setting value may cause burn on the
skin due to overheating of the motor.
Do not select a high value beyond the
required.
DRIVE CURRENT is set up with the DRIVE I.SEL switch.
A/phase
０ 0.9
１ 1.0
２ 1.1
３ 1.2
４ 1.3
５ 1.4
６ 1.5
７ 1.6
８ 1.7
９ 1.8
Ａ 1.9
Ｂ 2.0
Ｃ 2.1
Ｄ 2.2
Ｅ 2.3
Ｆ 2.4 (Factory setting）
CAUTION
-18-
