Melec GDB-5K50 Instruction Manual page 49

Fig.9
GDB-5K50
PKP545N18A(B)
1.8A/PHASE
TORQUE(N･m)
0.50
HOLD 40% = 0.18N・m
0.40
PULLOUT TORQUE
0.30
0.20
0.10
DRIVER INPUT CURRENT
0.00
0.01 0.1
MOTOR ROTATION SPEED(s
0.6 6
MOTOR ROTATION SPEED(r/min)
Fig.10
GDB-5K50
PKP546N18A(B)
1.8A/PHASE
TORQUE(N･m)
1.00
HOLD 40% = 0.21N・m
0.80
0.60 PULLOUT TORQUE
0.40
0.20
DRIVER INPUT CURRENT
0.00
0.01 0.1
MOTOR ROTATION SPEED(s
0.6 6
MOTOR ROTATION SPEED(r/min)
DRIVE I.SEL = No9
MOTOR SEL = OFF
RM1,RM2,RM3,RM4 = OFF, ON, OFF, OFF
DC24V
DRIVER INPUT CURRENT(A)
10.0
8.0
6.0
4.0
2.0
0.0
fs
1 10 100
-1 )
60 600 6000
DRIVE I.SEL = No9
MOTOR SEL = OFF
RM1,RM2,RM3,RM4 = OFF, ON, OFF, OFF
DC24V
DRIVER INPUT CURRENT(A)
10.0
8.0
6.0
4.0
2.0
0.0
fs
1 10 100
-1 )
60 600 6000
-49-
