Fig.11
GDB-5K50
PK566H-A(B)
1.4A/PHASE
TORQUE(N･m)
2.0
HOLD 40% = 0.46N・m
1.6
1.2
PULLOUT TORQUE
0.8
0.4
DRIVER INPUT CURRENT
0.0
0.01 0.1 1
MOTOR ROTATION SPEED(s
0.6 6 60
MOTOR ROTATION SPEED(r/min)
DRIVE I.SEL = No5
MOTOR SEL = OFF
RM1,RM2,RM3,RM4 = OFF, OFF, ON, OFF
DC24V
DRIVER INPUT CURRENT(A)
10.0
8.0
6.0
4.0
2.0
0.0
fs
10 100
-1 )
600 6000
-50-
