- Page 1 Preface Introduction Installing Device RUGGEDCOM RS416P Communication Ports Technical Specifications Dimension Drawings Installation Guide Certification 06/2015 RC1019-EN-03...
- Page 2 Warranty Siemens warrants this product for a period of five (5) years from the date of purchase, conditional upon the return to factory for maintenance during the warranty term. This product contains no user-serviceable parts. Attempted service by unauthorized personnel shall render all warranties null and void.
-
Page 3: Table Of Contents
RUGGEDCOM RS416P Installation Guide Table of Contents Table of Contents Preface ........................ Alerts ..............................v Related Documents ..........................v Accessing Documentation ........................v Training .............................. vi Customer Support ..........................vi Chapter 1 Introduction ......................1.1 Feature Highlights ........................1 1.2 Description ..........................2 1.3 Precision Time Protocol (PTP) Support .................. - Page 4 RUGGEDCOM RS416P Table of Contents Installation Guide 3.3 Serial Ports ..........................21 3.4 BNC Ports ..........................24 3.5 Connecting Multiple RS485 Devices .................... 25 Chapter 4 Technical Specifications ..................4.1 Power Supply Specifications ....................... 27 4.2 PoE Power Supply Specifications ....................28 4.3 Failsafe Relay Specifications ......................
-
Page 5: Preface
Installation Guide Preface Preface This guide describes the RUGGEDCOM RS416P. It describes the major features of the device, installation, commissioning and important technical specifications. It is intended for use by network technical support personnel who are responsible for the installation, commissioning and maintenance of the device. -
Page 6: Training
Siemens sales representative. Customer Support Customer support is available 24 hours, 7 days a week for all Siemens customers. For technical support or general information, contact Siemens Customer Support through any of the following methods: • Online Visit http://www.siemens.com/automation/support-request... -
Page 7: Introduction
Introduction Introduction The RUGGEDCOM RS416P is an industrially hardened serial device server with an integrated, fully managed, 4-Port Power over Ethernet (PoE) switch, designed to operate reliably in electrically harsh and climatically demanding utility substation and industrial environments. Featuring a modular design that can support up to 16 serial ports, the RS416P is able to interconnect multiple types of intelligent electronic devices (IEDs) that have different methods of communications. -
Page 8: Description
The RS416P features various ports, controls and indicator LEDs on the display panel for connecting, configuring and troubleshooting the device. The display panel can be located on the rear, front or top of the device, depending on the mounting configuration. Figure 1: RUGGEDCOM RS416P 1. Serial Ports 2. Fiber Optic Ethernet and/or BNC (Optional) Ports 3. -
Page 9: Precision Time Protocol (Ptp) Support
RUGGEDCOM RS416P Chapter 1 Installation Guide Introduction • Communication Ports – Ports for communicating with other devices or accessing the RUGGEDCOM ROS operating system are described in Chapter 3, Communication Ports. • Port Status Indicator LEDs – Port status indicator LEDs indicate the operational status of each port, dependent on the currently selected mode. -
Page 10: Supported Time Synchronization Sources
Chapter 1 RUGGEDCOM RS416P Introduction Installation Guide NOTE The PTP module can only be installed in slot 5. For more information, refer to Chapter 3, Communication Ports. Figure 2: PTP Module 1. TTL OUT Port 2. TTL IN Port For more information about the BNC ports, refer to Section 3.4, “BNC... -
Page 11: Ttl Outputs
(VL) the connected devices see is greater than the minimum required voltage. Section 1.3.3 IEEE 1588 Support RUGGEDCOM RS416P supports various IEEE 1588 time synchronization capabilities and provides synchronization in 2-step mode. This mode supports the following clock types: • End-to-End Slave Clock • End-to-End Master Clock •... - Page 12 RUGGEDCOM RS416P Chapter 1 Installation Guide Introduction IEEE 1588 Support...
-
Page 13: Installing Device
This product contains no user-serviceable parts. Attempted service by unauthorized personnel shall render all warranties null and void. Changes or modifications not expressly approved by Siemens Canada Ltd. could invalidate specifications, test results, and agency approvals, and void the user's authority to operate the equipment. -
Page 14: Mounting The Device To A Rack
Chapter 2 RUGGEDCOM RS416P Installing Device Installation Guide NOTE For detailed dimensions of the device with either rack, DIN rail or panel hardware installed, refer to Chapter 5, Dimension Drawings. The following sections describe the various methods of mounting the device: •... -
Page 15: Mounting The Device On A Din Rail
RUGGEDCOM RS416P Chapter 2 Installation Guide Installing Device Secure the adapters to the rack using the supplied hardware. Section 2.1.2 Mounting the Device on a DIN Rail For DIN rail installations, the RS416P can be equipped with panel/DIN rail adapters pre-installed on each side of the chassis. -
Page 16: Connecting Power
Chapter 2 RUGGEDCOM RS416P Installing Device Installation Guide Figure 6: Panel Mounting 1. Screw 2. Panel/DIN Rail Adaptor Install the supplied screws to secure the adapters to the panel. Section 2.2 Connecting Power The RS416P supports a single high AC or low DC power supply, and a separate 48 VDC power supply for PoE ports. -
Page 17: Connecting Ac Power
RUGGEDCOM RS416P Chapter 2 Installation Guide Installing Device • Equipment must be installed according to applicable local wiring codes and standards. The following sections describe how to connect power to the device: • Section 2.2.1, “Connecting AC Power” • Section 2.2.2, “Connecting DC Power”... -
Page 18: Connecting Dc Power
Chapter 2 RUGGEDCOM RS416P Installing Device Installation Guide Figure 7: Terminal Block Wiring 1. Screw-Type Terminal Block 2. Pluggable Terminal Block 3. Jumper 4. Positive/Live (+/L) Terminal 5. Negative/Neutral (-/N) Terminal (-/N) 6. Surge Ground Terminal 7. Chassis Ground Terminal Connect the negative wire from the power source to the negative/neutral (-/N) terminal on the terminal block. -
Page 19: Wiring Examples
RUGGEDCOM RS416P Chapter 2 Installation Guide Installing Device NOTE For PoE ports, connect a 48 VDC power supply to the terminals for Power Supply 2. Remove the terminal block cover. If a screw-type terminal block is installed, remove the screws from the appropriate terminals. Use these screws along with #6 ring lugs to secure the wires to the terminal block. - Page 20 Chapter 2 RUGGEDCOM RS416P Installing Device Installation Guide Figure 9: Single AC Power Supply Figure 10: Single DC Power Supply Wiring Examples...
- Page 21 RUGGEDCOM RS416P Chapter 2 Installation Guide Installing Device Figure 11: Dual DC Power Supply Figure 12: Dual AC/DC Power Supply Wiring Examples...
-
Page 22: Connecting The Failsafe Alarm Relay
Chapter 2 RUGGEDCOM RS416P Installing Device Installation Guide Figure 13: Dual AC/DC or AC and 48 V PoE Power Supply Section 2.3 Connecting the Failsafe Alarm Relay The failsafe relay can be configured to latch based on alarm conditions. The NO (Normally Open) contact is closed when the unit is powered and there are no active alarms. -
Page 23: Grounding The Device
RUGGEDCOM RS416P Chapter 2 Installation Guide Installing Device Figure 14: Failsafe Alarm Relay Wiring 1. Screw-Type Terminal Block 2. Pluggable Terminal Block 3. Normally Open Terminal 4. Common Terminal 5. Normally Closed Terminal Section 2.4 Grounding the Device The RS416P chassis ground terminal uses a #6-32 screw. It is recommended to terminate the ground connection with a #6 ring lug and torque it to 1.7 N·m (15 lbf·in). -
Page 24: Cabling Recommendations
Section 2.6 Cabling Recommendations Siemens does not recommend the use of copper cabling of any length for critical, real-time substation automation applications. All copper Ethernet ports on RUGGEDCOM products include transient suppression circuitry to protect against damage from electrical transients and conform with IEC 61850-3 and IEEE 1613 Class 1 standards. -
Page 25: Communication Ports
Installation Guide Communication Ports Communication Ports The RUGGEDCOM RS416P can be equipped with various types of communication ports to enhance its abilities and performance. Each communication port type has a specific place in the RUGGEDCOM RS416P chassis. Figure 17: Port Assignment 1. -
Page 26: Fiber Optic Ethernet Ports
Chapter 3 RUGGEDCOM RS416P Communication Ports Installation Guide RJ45 receptacles at either end. Ground loops can cause excessive noise and interference, but more importantly, create a potential shock hazard that can result in serious injury. LEDs Each port features LEDs that indicate the state of the port. -
Page 27: Serial Ports
RUGGEDCOM RS416P Chapter 3 Installation Guide Communication Ports Figure 21: LC Port Figure 20: MTRJ Port 1. Tx Connector 2. Rx Connector 1. Tx Connector 2. Rx Connector Figure 22: SC Port Figure 23: ST Port 1. Tx Connector 2. Rx Connector 1. - Page 28 Chapter 3 RUGGEDCOM RS416P Communication Ports Installation Guide Fiber Serial Port Figure 24: ST Port 1. Tx Connector 2. Rx Connector Serial DB9 Port Mode RS232 DCE RS485 RS422 TX/RX+ Common (Isolated) Ground Figure 25: Serial DB9 Port Pin Configuration...
- Page 29 RUGGEDCOM RS416P Chapter 3 Installation Guide Communication Ports Serial DB9 Port with IRIG-B Support Mode RS232 DTE RS485 RS422 TX/RX+ IRIG-B+ Common (Isolated) Ground Common (Isolated) Ground Figure 26: Serial DB9 Port Pin Configuration TX/RX- Common (Isolated) Ground Shield Chassis Ground In RS232 DTE mode, ports transmit to DTE devices on pin 2 and receive from DTE on pin 3.
-
Page 30: Bnc Ports
Chapter 3 RUGGEDCOM RS416P Communication Ports Installation Guide Serial RJ45 Port with IRIG-B Support RS232 Mode RS485 Mode RS422 Mode +IRIG-B Common (Isolated) Ground Common (Isolated) Ground Figure 28: Serial RJ45 Port Pin Configuration TX/RX+ TX/RX- Shield Chassis Ground In RS232 mode, the RJ45 ports conform to EIA-561 DTE, which transmit on TXD and receive on RXD. -
Page 31: Connecting Multiple Rs485 Devices
• The twisted pair should be terminated at each end of the chain. The following shows the recommended RS485 wiring. 120Ω 10nF 120Ω 10nF Figure 30: Recommended RS485 Wiring 1. RUGGEDCOM RS416P 2. Common (Isolated Ground) 3. Negative 4. Positive 5. Shield to Earth (Connected At a Single Point) 6. - Page 32 RUGGEDCOM RS416P Chapter 3 Installation Guide Communication Ports Connecting Multiple RS485 Devices...
-
Page 33: Technical Specifications
RUGGEDCOM RS416P Chapter 4 Installation Guide Technical Specifications Technical Specifications The following sections provide important technical specifications related to the device and available modules: • Section 4.1, “Power Supply Specifications” • Section 4.2, “PoE Power Supply Specifications” • Section 4.3, “Failsafe Relay Specifications”... -
Page 34: Poe Power Supply Specifications
Chapter 4 RUGGEDCOM RS416P Technical Specifications Installation Guide Section 4.2 PoE Power Supply Specifications Input Range Maximum Power Power Supply Type Internal Fuse Rating Consumption Minimum Maximum 48 VDC 37 VDC 72 VDC 2 A(T) 68 W (T) denotes time-delay fuse. -
Page 35: 10Base-Fl Ethernet Optical Specifications
RUGGEDCOM RS416P Chapter 4 Installation Guide Technical Specifications Section 4.5.1 10Base-FL Ethernet Optical Specifications Power Connector Cable Tx λ (typ.) Tx min Tx max Distance Mode Sensitivity Saturation Budget Type Type (µm) (nm) (dBm) (dBm) (typ.) (km) (dBm) (dBm) (dB) 62.5/125... -
Page 36: Copper Serial Port Specifications
Chapter 4 RUGGEDCOM RS416P Technical Specifications Installation Guide Section 4.6.1 Copper Serial Port Specifications Baud Rate Connector Isolation 1200 to 230400 kbps 2.5 kV 1200 to 230400 kbps RJ45 2.5 kV 1200 to 230400 kbps 2.5 kV 1200 to 230400 kbps RJ45 2.5 kV... -
Page 37: Mechanical Specifications
RUGGEDCOM RS416P Chapter 4 Installation Guide Technical Specifications Parameter Range Comments Ambient Relative Humidity 5% to 95% Non-condensing Ambient Storage Temperature -40 to 85 °C (-40 to 185 °F) Section 4.9 Mechanical Specifications Parameter Value Dimensions Refer to Chapter 5, Dimension Drawings Weight 4.5 kg (10 lbs) - Page 38 RUGGEDCOM RS416P Chapter 4 Installation Guide Technical Specifications Mechanical Specifications...
-
Page 39: Dimension Drawings
RUGGEDCOM RS416P Chapter 5 Installation Guide Dimension Drawings Dimension Drawings NOTE All dimensions are in millimeters, unless otherwise stated. 438.15 Figure 31: Overall Dimensions... - Page 40 Chapter 5 RUGGEDCOM RS416P Dimension Drawings Installation Guide 479.30 461.01 11.68 21.08 32.64 4.57 Figure 32: Rack Mount Dimensions...
- Page 41 RUGGEDCOM RS416P Chapter 5 Installation Guide Dimension Drawings 486.4 476.3 10.4 11.7 Figure 33: Panel and DIN Rail Mount Dimensions...
- Page 42 RUGGEDCOM RS416P Chapter 5 Installation Guide Dimension Drawings...
-
Page 43: Certification
RUGGEDCOM RS416P Chapter 6 Installation Guide Certification Certification The RUGGEDCOM RS416P device has been thoroughly tested to guarantee its conformance with recognized standards and has received approval from recognized regulatory agencies. • Section 6.1, “Standards Compliance” • Section 6.2, “Agency Approvals”... -
Page 44: Emi And Environmental Type Tests
Chapter 6 RUGGEDCOM RS416P Certification Installation Guide Section 6.3 EMI and Environmental Type Tests The RS416P has passed the following EMI and environmental tests. IEC 61850-3 Type Tests Test Description Test Levels Severity Levels IEC 61000-4-2 Enclosure ± 8 kV... - Page 45 5 kV (Fail-Safe Relay Output) DC Power ports 5 kV AC Power ports 5 kV Siemens specified severity level. IEEE 1613 EMI Immunity Type Tests NOTE The RS416P meets Class 2 requirements for an all-fiber configuration and Class 1 requirements for copper ports.
- Page 46 Chapter 6 RUGGEDCOM RS416P Certification Installation Guide Test Description Test Levels Severity Levels IEC 60255-21-1 Vibration 2 g @ 10-150 Hz Class 2 IEC 60255-21-2 Shock 30 g @ 11 ms Class 2 EMI and Environmental Type Tests...
