PRELIMINARY
PRV599A
VHF PORTABLE TWO-WAY RADIO
OWNER'S MANUAL

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PRV599A and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for HYT PRV599A

Summary of Contents for HYT PRV599A

  • Page 1 PRELIMINARY PRV599A VHF PORTABLE TWO-WAY RADIO OWNER’S MANUAL...
  • Page 2 PRELIMINARY Shenzhen HYT Science & Technology Co., Ltd. THANK YOU Thank you for your purchase of HYT two-way portable radio. This easy-to-use radio adopts the latest advanced technology, providing reliable communications in high efficiency. Before operate this radio, please read this manual carefully to be...

  • Page 3: Table Of Contents

    PRELIMINARY CONTENTS USER SAFETY INFORMATION...................4 SUPPLIED ACCESSORIES ....................7 ANTENNA, BATTERY AND OTHER ACCESSORIES ....7 1, BATTERY ........................7 2, ANTENNA ........................8 3, EXTERNAL SPK-MIC JACK ..................8 4, BELT CLIP ........................8 GETTING ACQUAINTED ..................9 ■CONTROL KNOBS, FUNCTION KEYS AND JACKS..........9 ■LCD..........................10 FEATURES AND OPERATION ..............11 1,POWER ........................11 2,VOLUME ........................11...

  • Page 4: User Safety Information

    USER SAFETY INFORMATION READ THIS IMPORTANT INFORMATION ON SAFE AND EFFICIENT OPERATION BEFORE USING YOUR HYT PORTABLE TWO-WAY RADIO. ◇ Only qualified technicians are allowed to repair this product. ◇ Turn off your radio prior to entering any area with a potentially explosive atmosphere.
  • Page 5 PRELIMINARY • Institute of Electrical and Electronic Engineers (IEEE) C95. 1-1999 Edition • International Commission on Non-Ionizing Radiation Protection (ICNIRP) 1998 • Ministry of Health (Canada) Safety Code 6. Limits of Human Exposure to Radio frequency Electromagnetic Fields in the Frequency Range from 3kHz to 300GHz, 1999 •...
  • Page 6 PRELIMINARY connected. • Consult the dealer or an experienced radio/TV technician for help. Industry Canada Compliance This Class B digital apparatus complies with Canadian ICES-003. Cet appareil numerique de la classe B est conforme à la norme NMB-003 Canada. FCC Requirements Your radio must be properly licensed Commission prior to use.

  • Page 7: Supplied Accessories

    PRELIMINARY SUPPLIED ACCESSORIES Item Qty. (pcs) Antenna Belt clip Screw set External speaker-microphone jack cover Locking bracket for speaker-microphone Battery * Charger Warranty card Introduction manual Note：*---Not available in simple packing。 ANTENNA, BATTERY AND OTHER ACCESSORIES The battery is not charged by the factory, please charge it before use. Repeat charging and discharging cycle for two or three times can make battery in its normal capacity.

  • Page 8: 2, Antenna

    PRELIMINARY 2, ANTENNA Position the antenna base on the radio connector and screw the antenna in clockwise until clicks in place. 3, EXTERNAL SPK-MIC JACK Plug speaker-microphone pins into the SP/MIC jacks. Fix the external speaker-microphone with the retainer by using supplied screws(3mm×6mm ). If the external speaker-microphone is not used, cover the SP/MIC jacks with jack caps by using supplied screws(3mm×6mm).

  • Page 9: Getting Acquainted

    PRELIMINARY Antenna Speaker GETTING ACQUAINTED ■CONTROL KNOBS, FUNCTION KEYS AND JACKS ⑴ CHANNEL SELECTOR KNOB Used to select channel and squelch level. In addition, it can be programmed by the dealer to delete undesired channels from scan list or to select CTCSS frequency. ⑵...

  • Page 10: Lcd

    PRELIMINARY used to display operation status. ⑸ SCN KEY Used to control scanning. ⑹ DIAL KEY When store and send feature is enabled, it is used to send codes; and when auto-dial feature is enabled, it is used to store, confirm, send or delete codes. ⑺...

  • Page 11: Features And Operation

    PRELIMINARY FEATURES AND OPERATION 1,POWER To turn on the power, turn POWER/VOL knob clockwise until a “click” is heard (the tone also can be programmed as “beeps”), and characters will be displayed on LCD. To shut off the power, turn POWER/VOL knob counter clockwise until a “click” is heard, and characters disappears from LCD.

  • Page 12: Receive

    PRELIMINARY level is set too low, you may be interfered by noise or other unwanted signals. 6 RECEIVE CTCSS /CDCSS/ DTMF/Two-Tone function can be set by your dealer. When the signaling is set, only signals with same signaling can be received, otherwise, all conversations on your selected channel can be heard.

  • Page 13: 8,Channel Scan

    PRELIMINARY transmitted. To transmit a disconnect ID: Method 1: Release [PTT], disconnect ID is transmitted. Method 2: While holding down [PTT] button, press [DIAL], and then press [*], disconnect ID is transmitted. 8,CHANNEL SCAN Press [SCN], radio begins scanning from current channel in ascending order, and “SCAN” appears on LCD.

  • Page 14: 10, Dtmf Selective Call

    PRELIMINARY time, corresponding CTCSS/CDCSS encode and decode also be reversed. To enable or disable the feature, press [TA] key. Enable Disable There is some difference between TALK AROUND and FREQUENCY REVERSE. When TALK AROUND is enabled, TX frequency is changed to be same as RX frequency and at the same time CTCSS/CDCSS encode and decode change correspondingly.

  • Page 15: 11, Code Squelch

    PRELIMINARY ★Even if [A],[B],[C]and [D] have been set invalid in manual dialing, these keys can be used when this feature is enabled. ★If enter unwanted digits, press [MONI] button, and then re-enter the whole number. ★To disable this feature, press[PTT], [SCN] , [TA] or [LO] , and the stored codes are deleted. ②CONFIRM STORED DTMF CODE Press [DIAL] key, and then press [*], LCD displays as the below.

  • Page 16: 13, Two-Tone Selective Call

    PRELIMINARY used to transmit or receive combination message (maximum with 5 digits). The format is: ID code(3 digits) +1 intermediate code +message code (maximum with 5 digits) When the radio receives DTMF code as preset, the speaker is switched on, and message code appears on LCD.

  • Page 17: 16, Call Alert Tone

    PRELIMINARY 16, CALL ALERT TONE In receive mode, when the radio receives correct DTMF code, it will sound alert tone. To stop the alert tone, press any key. CARE AND CLEANING ◇ Avoid physical abuse of your radio such as carrying it by the antenna or remote microphone.
