HYT TC-268S User Manual

Portable two-way radio
Hide thumbs
1
2
3
4
5
6
7
8
9
Table of Contents

Advertisement

Quick Links

Thank you for your purchase of HYT portable two-way radio. HYT portable radios
will provide you with clear and reliable communications in high efficiency. Please
read this manual before your operation.
Models covered in this manual:
TC-268S VHF: 136MHz-150MHz
150MHz-174MHz
TC-368S UHF: 400MHz-420MHz
450MHz-470MHz
User Safety Information
Preparation ...............................................................1
Supplied Accessories .................................................2
.................................................2
Attaching/Removing the Battery................................3
Attaching the Antenna ...............................................4
Attaching/Removing the Belt Clip .............................4
..........................................................4
General .....................................................................4
Features ......................................................................
Operation....................................................................5
Notes ..........................................................................5
Additional Remarks ...................................................6
................................................7
Auxiliary Feature
.................................................8
Time-out Timer ..........................................................8
Battery Save .............................................................8
Low Battery Warning.................................................9
Monitor ......................................................................9
CTCSS & CDCSS ......................................................9
Channel Scan .............................................................9
Busy Channel Lockout .............................................10
Optional Accessories ............................................10
Troubleshooting .....................................................11
Care and Cleaning .................................................12
Service Warranty ...................................................13
Frequency Chart ..................................................14
User Safety Information
READ THIS IMPORTANT INFORMATION ON SAFE AND EFFICIENT OPERATION BEFORE USING YOUR HYT
PORTABLE RADIO.
Only qualified technicians are allowed to repair this product.
*
* To avoid electromagnetic interference and/or compatibility conflicts, turn off your radio in any place
where posted notices instruct you to do so. Hospitals or health care facilities may be using equipment
that is sensitive to external RF energy. When on aircraft, turn off your radio when airline crew instruct
you to do so.
* When in vehicles with an air bag, do not place a portable radio in the area over an airbag or in the
Thank You
Contents
.................. 1
..............................................6
4

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the TC-268S and is the answer not in the manual?

Questions and answers

Related Manuals for HYT TC-268S

Summary of Contents for HYT TC-268S

  • Page 1: Table Of Contents

    Thank You Thank you for your purchase of HYT portable two-way radio. HYT portable radios will provide you with clear and reliable communications in high efficiency. Please read this manual before your operation. Models covered in this manual: TC-268S VHF: 136MHz-150MHz...

  • Page 2: Preparation

    Rapid Charger Rapid Charger AC Adapter Battery Belt Clip Owner’s Manual Strap Warranty Card * Antenna mark: TC-268S(1) shamrock. TC-268S(2) grass green. TC-368S(1) dark red. TC-368S(2) milk white. Battery Information y/Antenna and Other Accessories Charging the Battery he battery is not charged in factory, charge it before use. When first charging the battery after purchase or extended storage (more than 2 months), battery capacity is lower than its normal capacity.

  • Page 3: Accessory Information

    Place the battery or the radio with a battery into the charger. * Make sure the battery is well connected with the charger connectors. * When rapid charging starts, red LED glows; when charging is complete, green LED glows. Accessory Information ...

  • Page 4: Operation

    Charge begins at the end of discharge. Notes: HYT adaptor is recommended to use to avoid damage to the charger circuit. Do not operate in high temperature or corrosive conditions. Do not pull/plug the adaptor or the battery in the charge process to avoid interfering with the charge phases.
  • Page 5 1. Antenna 2. Channel Selector knob Turn the selector knob to select channels 1-S (channel S can be programmed by dealer as scan function) 3. LED Indicator Red LED glows while transmitting. Green LED glows while receiving. Red LED flashes when the battery voltage is low.

  • Page 6: Basic Operation

    9. Speaker/microphone jacks 10. Belt clip 11. Battery 12. Battery latch Basic Operation 1. To turn on the power, turn the Power/Volume control knob clockwise until a beep sounds. 2. To adjust the volume level, turn the Power/Volume control knob while holding down the Monitor key.

  • Page 7: Channel Scan

    TB-86: Ni-MH battery (7.2V 1100mAH) TDC-28: Rapid Charger TDC-29: Standard Charger PDS-237A: AC Adapter (standard charger) PDS-237L: AC Adapter (rapid charger) TC-368S Leather Case Short Antenna: TC-268S (1) 136-150MHz Antenna mark is shamrock. TC-268S (2) 150-174MHz Antenna mark is grass green. TC-368S (1) 400-420MHz Antenna mark is dark red.

  • Page 8: Care And Cleaning

    TC-368S (2) 450-470MHz Antenna mark is milk white. TC-378 Metal Belt Clip 158K: Remote Speaker/Microphone Troubleshooting Guide Trouble Solution *Battery may be used up. Please replace or recharge the No power battery. *The battery may not be properly installed. Remove the battery and attach it again.
