Reference
DE Channel
7
8
Boundary
9
10
11
12
13
14
15
16
Multivariable Considerations: The following 'rules' must be followed when integrating
multivariable devices:
No instrument can be physically wired to the FTA terminals within the logical
1
limits of another instrument
Cannot cross from Channel 8 to 9 with an MV transmitter, or rollover from
2
Channel 16 to 1
The Tag ID must be identical and non-blank across all logical channels
3
configured for use by a multivariable device
You must perform a Download Command on the physical channel in order to
4
change the number of PV's being transmitted (DECONFIG can only be
written to the first slot of a multivariable transmitters
Module Power Up
On power up, the module begins performing the following logical functions:
Initialize hardware components
1
Initialize backplane driver
o
Test and clear all RAM and shared RAM
o
Test and initialize both DE processors
o
Initialize the serial communication ports
o
Initialize the databases and ports
2
Set up the communication interface for the debug/configuration port
3
After the module receives the configuration, the module begins receiving and
transmitting messages with devices on the serial networks.
