Page 1
SPC11 Soft Stop Supplementary manual Drive-specific supplement for operating the SPC11 with drive type DGP(I)(L)-... Manual 196 730 en 0012NH [647 464]...
Page 3
....... . . 196 730 E (Festo AG & Co., D-73726 Esslingen, Federal Republic of Germany, 2000) Internet: http://www.festo.com...
Page 4
Contents and general instructions Trade marks ® Temposonics is a registered trade mark of MTS Sensortechnologie GmbH & Co Festo P.BE-SPC11-DGP-EN en 0012NH...
Contents and general instructions Intended use The SPC11 has been designed for fitting into a machine or an automation device. In conjunction with permitted drives and measuring systems and a proportional directional control valve type MPYE-5-..., the SPC11 enables: –...
Contents and general instructions Service If you have any technical problems, please contact your local Festo Service. Target group This manual is intended exclusively for personnel trained in control and automation technology. Festo P.BE-SPC11-DGP-EN en 0012NH...
This means that failure to observe this instruction may result in damage to property. The following pictogram marks passages in the text which describe activities with electrostatically sensitive compo- nents. Electrostatically sensitive components may be damaged if they are not handled correctly. Festo P.BE-SPC11-DGP-EN en 0012NH...
Page 10
Accessories: Information on necessary or sensible accessories for the Festo product. Environment: Information on environment-friendly use of Festo products. Text markings The bullet indicates activities which may be carried out in any order. 1. Figures denote activities which must be carried out in the numerical order specified.
Teach procedure In the Teach procedure, the SPC11 checks the set parameters, learns the position of the mechanical fixed stops as well as various characteristic system values and saves these in the integrated EEPROM.
1) These manuals contain the permitted drive-valve combinations, drive diameters and mass loads as well as the parameter settings of the SPC11 which are valid in these cases. Please note For installation and commissioning you will require the System manual as well as the manual “Drive-specific sup-...
Only then can the correct func- tioning of the system be guaranteed. Please note For operating the DGPI(L)- ... you will require the SPC11 type SPC11-MTS-AIF. For operating the DGP(L)-... with the MLO-POT-...-TLF measuring system you will require the SPC11 type SPC11-POT-TLF.
1. Summary of components System structure with the DGP(I)(L)-... The following diagram shows the structure of a drive with the SPC11, using as an example drive type DGP(L)-..Drive (here type DGP(L)-...) Proportional directional control valve type MPYE-5-...-010B Measuring system (here external measuring system type MLO-POT-...-...)
General rules on setting up the system can be found in the System manual type P.BE-SPC11-SYS..The following sec- tions contain special instructions on operation with the linear module type DGP(I)(L)-..
Page 18
1 ... 9 Notes on installation see following pages Fig. 1/2: Summary of pneumatic installation Compressed air supply ( 1 ) see System manual type P.BE-SPC11-SYS... Service unit ( 2 ) see System manual type P.BE-SPC11-SYS... Compressed air reservoir ( 3 ) see System manual type P.BE-SPC11-SYS...
Page 19
1. Summary of components Compressed air tubing and screw connectors ( 4 ) see System manual type P.BE-SPC11-SYS... Lay the tubing between valve (MPYE-5-...) and drive (DGP(I)(L)-...) symmetrically. Recommendation: Tubing length = drive length Use sizes for the compressed air tubing and tube con- nectors in accordance with the following table.
Page 20
450 to 500 MPYE-5-1/4-010B QS-1/4-10 QS-1/4-10 PUN-10x1,5 600 to 2000 MPYE-5-3/8-010B QS-3/8-10 QS-1/4-10 PUN-10x1,5 DGP(I)(L)-63-... 225 to 300 MPYE-5-1/8-HF-010B QS-1/8-8 QS-3/8-8 PUN-8x1,25 360 to 450 MPYE-5-1/4-010B QS-1/4-10 QS-3/8-10 PUN-10x1,5 500 to 2000 MPYE-5-3/8-010B QS-3/8-12 QS-3/8-12 PUN-12x2 Festo P.BE-SPC11-DGP-EN en 0012NH...
Page 21
750 to 2000 MPYE-5-3/8-010B QS-3/8-10 QS-1/4-10 PUN-10x1,5 DGP(I)(L)-50-... 225 to 300 MPYE-5-1/8-LF-010B QS-1/8-8 QS-1/4-8 PUN-8x1,25 360 to 450 MPYE-5-1/8-HF-010B QS-1/8-8 QS-1/4-8 PUN-8x1,25 500 to 600 MPYE-5-1/4-010B QS-1/4-10 QS-1/4-10 PUN-10x1,5 750 to 2000 MPYE-5-3/8-010B QS-3/8-10 QS-1/4-10 PUN-10x1,5 Festo P.BE-SPC11-DGP-EN en 0012NH...
Page 22
QS-3/8-12 PUN-12x2 Proportional directional control valve ( 5 ) see System manual type P.BE-SPC11-SYS... The DGP(I)(L)-... is suitable for both slide operation and yoke operation. Work connection 2 of the proportional directional control valve must be wired to the drive connection on the same side as the electrical connection for the potentiometer.
Page 23
1. Summary of components Electrical connection Fig. 1/3: Tubing for slide operation Electrical connection Fig. 1/4: Tubing for yoke operation and measuring system running parallel 1-11 Festo P.BE-SPC11-DGP-EN en 0012NH...
Page 24
(PPV). Do not use restrictors in the supply air line. Lubricate the guide of the drive at the service intervals specified in the operating instructions for the drive (see operating instructions for the drive or the guide). 1-12 Festo P.BE-SPC11-DGP-EN en 0012NH...
Page 25
Mount the measuring system and the drive symmetrically, so that the centre of the measuring system stroke matches the centre of the complete drive stroke (see also System manual type P.BE-SPC11-SYS-...). In order to fit measuring system type MLO-POT-...-TLF reliably and quickly, use fastening kit type BB-TLF- DGPL-...
Page 26
Cushioning path of the internal end position cushioning Fig. 1/5: Cushioning path Specifications on the cushioning length of the drive used can be found in the operating instructions for the drive and in the Pneumatics catalogue. 1-14 Festo P.BE-SPC11-DGP-EN en 0012NH...
Page 27
Mass load ( 9 ) Fit the mass load free of play. Possible moveable mass loads see “Parameters for the DGP(I)(L)-...” in chapter 2. The tables shown there contain all the permitted combinations of drives, valves and mass loads. 1-15 Festo P.BE-SPC11-DGP-EN en 0012NH...
2, the slide must move away from the measur- ing system zero point. The arrows on the drive cover of the DGP(L)-... indicate the direction of movement. – The resulting positioning times can vary depending on the stroke direction. 1-16 Festo P.BE-SPC11-DGP-EN en 0012NH...
Page 29
Fig. 1/6: Tubing on the side opposite that with the measur- ing system zero point Electrical connection (measuring system zero point) Arrows mark the direction of movement Fig. 1/7: Tubing on the side opposite that with the measur- ing system zero point 1-17 Festo P.BE-SPC11-DGP-EN en 0012NH...
Page 30
Mount the measuring system and the drive symmetrically, so that the centre of the measuring system stroke matches the centre of the complete drive stroke (see also System manual type P.BE-SPC11-SYS-...). – The resulting positioning times depend on the actual stroke length used.
Caution Incorrect or missing earthing can cause faults. Connect drive type (DGP(I)(L)-... with low impedance (short cable with large diameter) to the earth potential, if the drive is not mounted on an earthed machine stand. 1-19 Festo P.BE-SPC11-DGP-EN en 0012NH...
Page 32
1. Summary of components 1-20 Festo P.BE-SPC11-DGP-EN en 0012NH...
Page 33
Parameters of the SPC11 for the DGP(I)(L)-... Chapter 2 Festo P.BE-SPC11-DGP-EN en 0012NH...
Page 34
2. Parameters of the SPC11 for the DGP(I)(L)-... Contents Parameters of the SPC11 for the DGP(I)(L)-......Parameters of the SPC11 .
Page 35
Take the utmost care when setting the parameters. Certain conditions of use must be made known to the SPC11. These conditions of use are described in the three following parameters which are entered directly on the SPC11:...
Page 36
2. Parameters of the SPC11 for the DGP(I)(L)-... Specifications for setting the parameters In order to set the parameters, you will require the following specifications: – Cylinder stroke length (see type plate for drive used). – Valve type (see type plate for proportional directional control valve used).
Page 37
2. Parameters of the SPC11 for the DGP(I)(L)-... Setting the parameters Warning Incorrectly set parameters can cause damage to the fixed stops and to the drive. Always set the amplification and cushioning stages for the maximum mass load used. If in doubt, set first the ampli- fication and cushioning stages for the larger mass load.
Page 38
2. Parameters of the SPC11 for the DGP(I)(L)-... The average positioning times specified apply to the maxi- mum permitted stroke (without cushioning path). Optimiz- ation of the positioning behaviour may be necessary in indi- vidual cases (see System manual). DGP(I)(L)-25-225 to ...-25-300...
Page 39
2. Parameters of the SPC11 for the DGP(I)(L)-... The parameters listed in the following tables are adapted exactly to the specified combinations of valves, drives, mass loads and fitting positions. Please note Faultless operation can only be guaranteed if all compo- nents are fitted correctly.
2. Parameters of the SPC11 for the DGP(I)(L)-... Parameters for the DGP(I)(L)-.. in horizontal operation 2.3.1 DGP(I)(L)-25-... in horizontal operation DGP(I)(L)-25-225 to ...-25-360 in horizontal operation DGP(I)(L)-25-225 DGP(I)(L)-25-300 DGP(I)(L)-25-360 MPYE-5-1/8-LF-010B MPYE-5-1/8-LF-010B MPYE-5-1/8-HF-010B 0.47 0.52 0.43 0.49 0.54 0.49 0.50 0.53 0.51...
Page 41
2. Parameters of the SPC11 for the DGP(I)(L)-... DGP(I)(L)-25-450 to ...-25-600 in horizontal operation DGP(I)(L)-25-450 DGP(I)(L)-25-500 DGP(I)(L)-25-600 MPYE-5-1/8-HF-010B MPYE-5-1/8-HF-010B MPYE-5-1/8-HF-010B 0.46 0.47 0.56 0.52 0.56 0.63 0.55 0.57 0.59 0.59 0.58 0.70 0.63 0.64 0.69 0.63 0.68 0.71 0.66 0.65 0.76...
Page 42
2. Parameters of the SPC11 for the DGP(I)(L)-... DGP(I)(L)-25-750 to ...-25-1250 in horizontal operation DGP(I)(L)-25-750 DGP(I)(L)-25-1000 DGP(I)(L)-25-1250 MPYE-5-1/8-HF-010B MPYE-5-1/8-HF-010B MPYE-5-1/8-HF-010B 0.63 0.79 0.90 0.68 0.80 0.93 0.73 0.85 0.97 0.76 0.89 0.99 0.76 0.87 1.02 0.78 0.91 1.07 0.81 1.01 1.10...
Page 43
2. Parameters of the SPC11 for the DGP(I)(L)-... DGP(I)(L)-25-1500 to ...-25-2000 in horizontal operation DGP(I)(L)-25-1500 DGP(I)(L)-25-1750 DGP(I)(L)-25-2000 MPYE-5-1/8-HF-010B MPYE-5-1/8-HF-010B MPYE-5-1/8-HF-010B 1.24 1.20 1.39 1.06 1.21 1.36 1.08 1.23 1.41 1.17 1.28 1.43 1.16 1.33 1.46 1.21 1.36 1.50 1.23 1.39 1.52...
2. Parameters of the SPC11 for the DGP(I)(L)-... Parameters for the DGP(I)(L)-.. in vertical operation 2.4.1 DGP(I)(L)-25-... in vertical operation DGP(I)(L)-25-225 to ...-25-360 in vertical operation DGP(I)(L)-25-225 DGP(I)(L)-25-300 DGP(I)(L)-25-360 MPYE-5-1/8-LF-010B MPYE-5-1/8-LF-010B MPYE-5-1/8-LF-010B 0.49 0.44 0.51 0.45 0.57 0.55 0.50 0.44 0.57...
Page 61
2. Parameters of the SPC11 for the DGP(I)(L)-... DGP(I)(L)-25-450 to ...-25-600 in vertical operation DGP(I)(L)-25-450 DGP(I)(L)-25-500 DGP(I)(L)-25-600 MPYE-5-1/8-LF-010B MPYE-5-1/8-LF-010B MPYE-5-1/8-HF-010B 0.61 0.57 0.62 0.61 0.60 0.53 0.62 0.61 0.69 0.58 0.68 0.59 0.70 0.61 0.83 0.66 0.72 0.58 0.81 0.75 0.81...
Page 62
2. Parameters of the SPC11 for the DGP(I)(L)-... DGP(I)(L)-25-750 to ...-25-1250 in vertical operation DGP(I)(L)-25-750 DGP(I)(L)-25-1000 DGP(I)(L)-25-1250 MPYE-5-1/8-HF-010B MPYE-5-1/4-010B MPYE-5-1/4-010B 0.66 0.59 0.78 0.72 0.95 0.83 0.74 0.63 0.86 0.74 1.01 0.86 0.82 0.66 0.98 0.75 1.15 0.89 0.85 0.63 1.00...
Page 63
2. Parameters of the SPC11 for the DGP(I)(L)-... DGP(I)(L)-25-1500 to ...-25-2000 in vertical operation DGP(I)(L)-25-1500 DGP(I)(L)-25-1750 DGP(I)(L)-25-2000 MPYE-5-1/4-010B MPYE-5-1/4-010B MPYE-5-1/4-010B 1.11 0.95 1.24 1.08 1.39 1.22 1.18 0.95 1.35 1.09 1.52 1.20 1.34 0.99 1.46 1.07 1.69 1.19 1.39 0.97 1.61...
2. Parameters of the SPC11 for the DGP(I)(L)-... 2.4.5 DGP(I)(L)-63-... in vertical operation DGP(I)(L)-63-225 to ...-63-360 in vertical operation DGP(I)(L)-63-225 DGP(I)(L)-63-300 DGP(I)(L)-63-360 MPYE-5-1/8-LF-010B MPYE-5-1/8-HF-010B MPYE-5-1/4-010B 0.99 0.93 1.01 0.92 0.78 0.74 1.03 1.12 1.06 0.93 0.78 0.70 1.12 1.13 1.17 0.93...
Page 77
2. Parameters of the SPC11 for the DGP(I)(L)-... DGP(I)(L)-63-450 to ...-63-600 in vertical operation DGP(I)(L)-63-450 DGP(I)(L)-63-500 DGP(I)(L)-63-600 MPYE-5-1/4-010B MPYE-5-3/8-010B MPYE-5-3/8-010B 0.85 0.81 0.86 0.88 0.91 0.85 0.93 0.81 0.85 0.75 0.99 0.88 1.03 0.87 0.93 0.82 1.03 0.87 1.03 0.79 0.93...
Page 78
2. Parameters of the SPC11 for the DGP(I)(L)-... DGP(I)(L)-63-750 to ...-63-1250 in vertical operation DGP(I)(L)-63-750 DGP(I)(L)-63-1000 DGP(I)(L)-63-1250 MPYE-5-3/8-010B MPYE-5-3/8-010B MPYE-5-3/8-010B 1.06 1.05 1.30 1.22 1.55 1.36 1.11 1.14 1.37 1.13 1.63 1.38 1.15 0.98 1.44 1.23 1.73 1.34 1.26 1.04 1.57...
Page 79
2. Parameters of the SPC11 for the DGP(I)(L)-... DGP(I)(L)-63-1500 to ...-63-2000 in vertical operation DGP(I)(L)-63-1500 DGP(I)(L)-63-1750 DGP(I)(L)-63-2000 MPYE-5-3/8-010B MPYE-5-3/8-010B MPYE-5-3/8-010B On request 2-47 Festo P.BE-SPC11-DGP-EN en 0012NH...
Page 80
2. Parameters of the SPC11 for the DGP(I)(L)-... 2-48 Festo P.BE-SPC11-DGP-EN en 0012NH...
Page 81
Technical appendix Appendix A Festo P.BE-SPC11-DGP-EN en 0012NH...
Page 82
............Festo P.BE-SPC11-DGP-EN en 0012NH...
Page 83
± 0.25 % of the rated length of the measuring system, but not more accurate than ± 2 mm. Please note Observe the instructions on repetition accuracy in the sys- tem manual in order to achieve good positioning behav- iour and the specified repetition accuracy. Festo P.BE-SPC11-DGP-EN en 0012NH...
Page 84
A. Technical appendix Festo P.BE-SPC11-DGP-EN en 0012NH...
Page 85
........Festo P.BE-SPC11-DGP-EN en 0012NH...
