SITRANS F US
Clamp-on Ultrasonic Flowmeters
Communications Protocol Manual
Edition
11/2015
Answers for industry.

Advertisement

Table of Contents
loading

Related Manuals for Siemens SITRANS F US

Summary of Contents for Siemens SITRANS F US

  • Page 1 SITRANS F US Clamp-on Ultrasonic Flowmeters Communications Protocol Manual Edition 11/2015 Answers for industry.
  • Page 3 Introduction Installing/Mounting BACnet Communications SITRANS F US HART Communications Clamp-on Ultrasonic Flowmeters F US Clamp-on Communications Consolidated Modbus Registers Protocol Manual WEB Configuration Utility Hardware Installation Manual Appendix A 11/2015 A5E34981613-AC...
  • Page 4 Note the following: WARNING Siemens products may only be used for the applications described in the catalog and in the relevant technical documentation. If products and components from other manufacturers are used, these must be recommended or approved by Siemens. Proper transport, storage, installation, assembly, commissioning, operation and maintenance are required to ensure that the products operate safely and without any problems.

  • Page 5: Table Of Contents

    Table of contents Introduction ............................. 7 History ............................7 Installing/Mounting ..........................9 Items Supplied .......................... 9 F US Clamp-on Communications Module Installation .............. 9 Flowmeter Setup ........................17 BACnet Communications ........................29 BACnet Communications ......................29 BACnet Protocol Implementation Conformance Statement ........... 31 BACnet Alarms ........................
  • Page 6 Table of contents A.1.19 Profile 18 ..........................101 A.1.20 Profile 19 ..........................104 A.1.21 Profile 20 ..........................107 A.1.22 Profile 21 ..........................111 A.1.23 Profile 22 ..........................115 A.1.24 Profile 23 ..........................119 A.1.25 Profile 24 ..........................120 A.1.26 Profile 25 ..........................122 A.1.27 Profile 26 ..........................
  • Page 7 F_US1010 Clamp-on Communications Module - HART Device Variables ........ 48 Figures Figure 2-1 New Communications Module Installation ................... 11 Figure 2-2 SITRANS F US Clamp-on Communications Module A5E31949269 ........... 12 Figure 2-3 New Communications Module Installation ................... 13 Figure 2-4 DIP Switches SW1-A and SW2-B ....................14 Figure 2-5 Communications Cable Installation....................
  • Page 8 Table of contents Figure 3-1 Typical F US Clamp-on Flowmeter BACnet Application .............. 29 Figure 4-1 HART Connections ........................37 Figure 4-2 Typical Connection of F US flowmeter with HART F_US1010 Option ........47 Figure 4-3 Process Variables View ....................... 49 Figure 4-4 Dynamic Variables Changes View ....................

  • Page 9: Introduction

    Introduction These SITRANS F US Clamp-on Communications Protocol installation instructions are for Siemens SITRANS F US clamp-on ultrasonic flow meters equipped with the communication option. The instructions are aimed at persons that mechanically install the device, connect it electronically, configure the parameters and commission it as well as service and maintenance engineers.
  • Page 10 Introduction 1.1 History F US Clamp-on Communications Protocol Manual Hardware Installation Manual, 11/2015, A5E34981613-AC...

  • Page 11: Installing/Mounting

    Installing/Mounting Items Supplied The following parts are provided when the Communications Module is purchased separately: ● SITRANS F US Clamp-on Communications Module A5E31949269 ● Four captive screws ● Four captive standoffs F US Clamp-on Communications Module Installation WARNING Hazardous Voltage May cause death or serious personal injury.
  • Page 12 Installing/Mounting 2.2 F US Clamp-on Communications Module Installation These Communications Module installation instructions address the three types of installation procedures for the flowmeter: 1. Flowmeters purchased with the correct MLFB number that includes the Communications Module will be installed by the factory and no installation of the Communications Module is required.

  • Page 13: Table 2- 1 Mounting Kit

    Installing/Mounting 2.2 F US Clamp-on Communications Module Installation New Communications Module Installation This installation procedure is for flowmeters with an I/O Module installed but no Modbus Communications Module previously installed. Mounting kits are also required for this installation. Table 2- 1 Mounting Kit Mounting Kit Meter Type...
  • Page 14 Standoff ④ Figure 2-2 SITRANS F US Clamp-on Communications Module A5E31949269 7. Gently press the Communications Module down to connect it to the I/O Module. 8. Tighten the captive screws to secure the Communications Module and I/O Module. 9. If using Ethernet IP, connect the Ethernet connector.
  • Page 15 Installing/Mounting 2.2 F US Clamp-on Communications Module Installation Fielded Upgrade with New Communications Module This installation procedure is intended for flowmeters that are to be upgraded from the 1015N-5M Modbus Communications Module to the new Communications Module. 1. Disconnect power to the unit. ③...
  • Page 16 Installing/Mounting 2.2 F US Clamp-on Communications Module Installation RS-485 Connector J1 Signal Description J1-1 RS-485+ Signal + J1-2 RS-485- Signal - J1-3 RS-485 GND Ground J1-4 No Connection J1-5 HART No Connection J1-6 HART No Connection DIP Switch Settings - SW1-A and SW2-B There are two 8-position switches that are used to select protocols, baud rate, address and profiles.
  • Page 17 Installing/Mounting 2.2 F US Clamp-on Communications Module Installation Baud Rate Selection: SW1-A (7-8) - To Network 9600 A7 OFF A8 OFF 19200 A7 ON A8 OFF 38400 A7 OFF A8 ON 76800 A7 ON A8 ON Profile Selection: SW2-B (1-6) See selection table 2-1.

  • Page 18: Table 2- 2 Profile Selection: 1 - 46

    Installing/Mounting 2.2 F US Clamp-on Communications Module Installation Table 2- 2 Profile Selection: 1 - 46 Profile Selection Profile Flowmeter Firmware Version & Configuration Off Off profile 1 5N01-5.04.05 CH1: Clamp-On Off Off profile 2 5N01-5.04.05 CH1: Reflexor On Off profile 3 5N02-5.04.05 CH1: Clamp-On On Off...

  • Page 19: Flowmeter Setup

    Installing/Mounting 2.3 Flowmeter Setup On Off profile 44 5GN04-5.04.05 Dual Path: Clamp-On Off On profile 45 5GN05-5.04.05 Dual Path: Clamp-On Off On profile 46 5GN07-5.04.05 Quad Path: Clamp-On Flowmeter Setup Note The Flowmeter Setup procedure must be done to every channel of the meter. In order for the Communications Module (P/N A5E31949269) to work properly, all of the possible Logger configuration choices in the site setup must be correct.
  • Page 20 Installing/Mounting 2.3 Flowmeter Setup choices. Use the <Right> arrow key to access the choices. Using the <UP/DN> arrow keys, select the item desired as defined below. Pressing the <ENTER> key will select that choice. ● Logger Mode: Set to RS-232 Output ●...
  • Page 21 Installing/Mounting 2.3 Flowmeter Setup Communications Cable Installation Connect Communication cable (Cat5 type) from J1 to the Ethernet port of your PC. Figure 2-5 Communications Cable Installation FieldServer Toolbox 1. Download FieldServer Toolbox from here if you do not have it installed: http://bit.ly/FStoolbox 2.
  • Page 22 Installing/Mounting 2.3 Flowmeter Setup Figure 2-6 FieldServer Toolbox Tour F US Clamp-on Communications Protocol Manual Hardware Installation Manual, 11/2015, A5E34981613-AC...
  • Page 23 Installing/Mounting 2.3 Flowmeter Setup F US Clamp-on Communications Protocol Manual Hardware Installation Manual, 11/2015, A5E34981613-AC...
  • Page 24 Installing/Mounting 2.3 Flowmeter Setup F US Clamp-on Communications Protocol Manual Hardware Installation Manual, 11/2015, A5E34981613-AC...
  • Page 25 Installing/Mounting 2.3 Flowmeter Setup F US Clamp-on Communications Protocol Manual Hardware Installation Manual, 11/2015, A5E34981613-AC...
  • Page 26 Installing/Mounting 2.3 Flowmeter Setup F US Clamp-on Communications Protocol Manual Hardware Installation Manual, 11/2015, A5E34981613-AC...
  • Page 27 Installing/Mounting 2.3 Flowmeter Setup F US Clamp-on Communications Protocol Manual Hardware Installation Manual, 11/2015, A5E34981613-AC...
  • Page 28 Installing/Mounting 2.3 Flowmeter Setup View - Data Arrays Here you can view the data coming from the meter as it is stored before being mapped to the various protocol parameters. This may be useful to determine that the data is being received by the Communications Module.
  • Page 29 Installing/Mounting 2.3 Flowmeter Setup User Messages Here you can view any messages that may indicate an error. Figure 2-7 User Messages F US Clamp-on Communications Protocol Manual Hardware Installation Manual, 11/2015, A5E34981613-AC...
  • Page 30 Installing/Mounting 2.3 Flowmeter Setup F US Clamp-on Communications Protocol Manual Hardware Installation Manual, 11/2015, A5E34981613-AC...

  • Page 31: Bacnet Communications

    BACnet Communications BACnet Communications Introduction uilding utomation and ontrol works BACnet is a standard communication protocol for B developed by the American Society of Heating, Refrigerating and Air-Conditioning Engineers (ASHRAE). BACnet provides the communication infrastructure needed to integrate products made by different vendors. BACnet communication is based on standard objects. Each BACnet device includes a Device Object and other optional objects within the device.
  • Page 32 Device Object Property Identifier Description and/or Example Value Object_Identifier BACnetObjectIdentifier {defined by profile selection} Object_Name Object_Type DEVICE (8) System_Status OPERATIONAL (0) Vendor_Name Siemens Industry, Inc. Vendor_Identifier Model_Name Siemens Option Card (or later) Firmware_Revision 2.04.04a Application_Software_Version 6.11b (A) Protocol_Version Protocol_Revision Protocol_Services_Supported...

  • Page 33: Bacnet Protocol Implementation Conformance Statement

    BACnet communications setup. Typical BACnet Conformance Statement Date: January, 2012 Vendor Name: Siemens Industry, Inc. Product Name: SITRANS F US Clamp-On Ultrasonic Flowmeters Product Model Number: Siemens Option Card Application Software Version: V6.11b (A) Firmware Revision: 2.04.06...
  • Page 34 BACnet Communications 3.2 BACnet Protocol Implementation Conformance Statement ☑ K.1.2 BIBB – Data Sharing – ReadProperty-B (DS-RP-B) ☑ K.1.4 BIBB – Data Sharing – ReadPropertyMultiple-B (DS-RPM-B) ☑ K.1.8 BIBB – Data Sharing – WriteProperty-B (DS-WP-B) ☑ K.1.10 BIBB – Data Sharing – WritePropertyMultiple-B (DS-WPM-B) ☑...
  • Page 35 ☐ ISO 10646 (UCS-2) ☐ ISO 10646 (UCS-4) ☐ JIS X 0208 ☑ ANSI X3.4 If this product is a communication gateway, describe the types of non-BACnet equip- ment/networks(s) that the gateway supports: Siemens F US Clamp-On Flowmeters. F US Clamp-on Communications Protocol Manual Hardware Installation Manual, 11/2015, A5E34981613-AC...

  • Page 36: Bacnet Alarms

    BACnet Communications 3.3 BACnet Alarms BACnet Alarms The BACnet Alarms can be read by using the FieldServer Toolbox. 1. At your desktop, click and open the FieldServer Toolbox. 2. Click on the [Connect] button. 3. Click on [Diagnostics & Debugging] and the menu will open. 4.
  • Page 37 BACnet Communications 3.3 BACnet Alarms BACnet Object Identifiers: Alarms are Binary Inputs F US Clamp-on Communications Protocol Manual Hardware Installation Manual, 11/2015, A5E34981613-AC...

  • Page 39: Hart Communications

    Universal HART Commands Introduction The SITRANS F US Clamp-on Communication Module, in addition to providing various communication protocols, including BACnet, Modbus, EIP, & N2, also includes a HART 4-20 mA output that is always active regardless of other protocols selected.

  • Page 40: Table 4- 1 Rs-485 Connector J1

    No Connection J1-5 HART HART + J1-6 HART HART - HART Commands The following tables list the Universal HART Commands for the SITRANS F US Clamp-on Communication Module. Commands Table 4- 2 Command 0 - Read Unique Identifier Description Byte Response Comments/Value “254”...

  • Page 41: Table 4- 4 Command 2 - Read Loop Current And Percent Of Range

    HART Communications 4.1 Universal HART Commands Table 4- 4 Command 2 - Read Loop Current and Percent of Range Description Byte Format Comments/Value <units in milli-amperes> Primary Variable Loop Current Float Primary Variable Percent of Range Float <range set in CMD 35> Table 4- 5 Command 3 - Read Dynamic Variable and Loop Current Description...

  • Page 42: Table 4- 9 Command 9 - Read Device Variable With Status

    Command 11 - Read Unique identifier Associated with Tag Description Byte Response Comments/Value “254” Device Type 2A04 Siemens FUS Minimum number of Preambles HART Protocol Major Revision Number Device Revision Level Software Revision Level <5 most significant bits> Hardware Revision Level <3 least significant bits>...

  • Page 43: Table 4- 11 Command 12 - Read Message

    HART Communications 4.1 Universal HART Commands Table 4- 11 Command 12 - Read Message Description Byte Format Comments/Value <write Message CMD 17> Message 0-23 Packed Table 4- 12 Command 13 - Read Tag, Descriptor, Date Description Byte Format Comments/Value Packed <write Tag CMD 18>...
  • Page 44 <increments with each write> Configuration Change Counter 14-15 See Common table 17 Extended Field Device Status Manufacturer Identification Code 17-18 002A Siemens Private Label Distribution Code 19-20 002A Siemens Device Profile Process Automation Device F US Clamp-on Communications Protocol Manual...

  • Page 45: Common Practice Hart Commands

    Device Specific Status Reserved for future use Common Practice HART Commands Introduction The following tables list the Common Practice HART Commands for the SITRANS F US Clamp-on Communication Module. Commands Table 4- 24 Command 35 - Write Primary Range Values...
  • Page 46 HART Communications 4.3 Device Specific HART Commands Table 4- 27 Command 45 - Trim Loop Current Zero Description Byte Format Comments/Value <used with CMD 40 to trim 4> Measured Loop Current (milliamperes) Float Table 4- 28 Command 46 - Trim Loop Current Gain Description Byte Format...

  • Page 47: Device Specific Hart Commands

    HART Communications 4.3 Device Specific HART Commands Device Specific HART Commands Introduction The following tables list the Device Specific HART Commands. Commands Command 28 - Read HART Variable Unit Table 4- 32 Request Description Byte Format Comments/Value 0-243 HART_Device_Variable_Number Table 4- 33 Response Description Byte...

  • Page 48: Hart F Us1010 Setup

    Variables (PV, SV, TV, & QV). Figure 4-1 illustrates a typical connection setup. Refer to Section 2 for more details on the SITRANS F US Clamp-on Communication Module. The SITRANS F US Clamp-on Communications Module, in addition to providing various communication protocols, including BACnet, Modbus, EIP &...
  • Page 49 TV, & Energy Total to QV. In some cases it may be desired to change the Dynamic Variable selections. This can be done with a configuration tool such as Siemens PDM software. PDM can also be used to monitor the active HART Device Variables in the SITRANS F_US1010.
  • Page 50 HART Communications 4.4 HART F US1010 Setup Table 4- 40 F_US1010 Clamp-on Communications Module - HART Device Variables HART Device Variab- Variable Date Description Default Value Default Units 00 (0x00) Average Flow Rate GAL/MIN 01 (0x01) Channel 1 Average Flow Rate GAL/MIN 02 (0x02) Channel 2 Average Flow Rate...
  • Page 51 HART Communications 4.4 HART F US1010 Setup 42 (0x2a) Energy Total KBTU 43 (0x2b) Channel 1 Energy Total KBTU 44 (0x2c) Channel 2 Energy Total KBTU Process/Output View The Process/Output can be viewed and edited for desired upper and lower range values that refer to the PV range.
  • Page 52 HART Communications 4.4 HART F US1010 Setup Dynamic Variables Changes The default Dynamic Variables can be changed and downloaded to the SITRANS F_US1010. The Command tab can be selected and Command 51 entered followed by the Hex code that corresponds to the variable desired. Only active variables for the current profile should be selected.
  • Page 53 HART Communications 4.4 HART F US1010 Setup Dynamic Variables View Dynamic Variables (PV, SV, TV, & QV) can be viewed by selecting the View tab/Dynamic/Variables. The four variables will be displayed and the PV will include the value of the current output in both mA and % of range. Figure 4-5 Dynamic Variables View F US Clamp-on Communications Protocol Manual...

  • Page 54: Troubleshooting Diagnostics

    HART Communications 4.5 Troubleshooting Diagnostics Device Information View Device Information can be viewed and changed in an online mode by selecting Device tab. Figure 4-6 Device Information Troubleshooting Diagnostics To take a full diagnostic capture using the FieldServer Toolbox: 1. If not installed, download the FieldServer Toolbox at: http://bit.ly/fstoolbox 2.

  • Page 55: Consolidated Modbus Registers

    Consolidated Modbus Registers Consolidated Modbus Registers Introduction The following tables list the Consolidated Modbus Registers for the SITRANS F US Communication Module. Input Registers (Read Only) Description Address Register Type Bytes Type Example Year 3xxxx Input Register Integer 2012 Month...
  • Page 56 Consolidated Modbus Registers 5.1 Consolidated Modbus Registers Sonic Vel Chan1_Path1 3xxxx Input Register Real 1494.67 Sonic Vel Chan2_Path2 3xxxx Input Register Real 1494.67 Sonic Vel Chan3_Path3 3xxxx Input Register Real 1494.67 Sonic Vel Chan4_Path4 3xxxx Input Register Real 1494.67 Signal Strength 3xxxx Input Register Integer Signal Strength Chan1_Path1 167...
  • Page 57 Consolidated Modbus Registers 5.1 Consolidated Modbus Registers Specific Gravity Chan1 3xxxx Input Register Real 0.987 Specific Gravity Chan2 3xxxx Input Register Real 0.987 Specific Gravity Chan3 3xxxx Input Register Real 0.987 Specific Gravity Chan4 3xxxx Input Register Real 0.987 3xxxx Input Register Real 10.00 API Chan1...
  • Page 58 Consolidated Modbus Registers 5.1 Consolidated Modbus Registers Input Status (Read Only) Description Address Register Type Data Type Example Spacing 1xxxx Input Register Coil Empty 1xxxx Input Register Coil Rate 1xxxx Input Register Coil Fault 1xxxx Input Register Coil Aeration 1xxxx Input Register Coil Memory 1xxxx Input Register...
  • Page 59 Consolidated Modbus Registers 5.1 Consolidated Modbus Registers Description Address Register Type Data Type Example Spacing Chan3_Path3 1xxxx Input Register Coil Empty Chan3_Path3 1xxxx Input Register Coil Rate Chan3_Path3 1xxxx Input Register Coil Fault Chan3_Path3 1xxxx Input Register Coil Aeration Chan3_Path3 1xxxx Input Register Coil Memory Chan3_Path3...
  • Page 60 Consolidated Modbus Registers 5.1 Consolidated Modbus Registers Description Address Register Type Bytes Type Example Site ID Chan1 3xxxx Input Register String Chiller1 Site ID Chan2 3xxxx Input Register String Chiller2 Site ID Chan3 3xxxx Input Register String Chiller3 Site ID Chan4 3xxxx Input Register String Chiller4...
  • Page 61 Consolidated Modbus Registers 5.1 Consolidated Modbus Registers Liquident Units Chan2 3xxxx Input Register String Viscosity Units 3xxxx Input Register String SG Units Chan1 3xxxx Input Register String SG Units Chan2 3xxxx Input Register String SG Units Chan3 3xxxx Input Register String SG Units Chan4 3xxxx Input Register...

  • Page 63: Web Configuration Utility

    Web Configuration through the Ethernet port is used for every protocol including Ethernet, N2, BACnet and Modbus except HART. You can connect to the SITRANS F US Clamp-on Communications Module using a Web browser (Chrome 19.0 or higher, Firefox 13.0 or higher, Opera 11.0 or higher, Internet Explorer 8, 9, or 10).
  • Page 64 WEB Configuration Utility 6.1 WEB Configuration Utility Toolbox The Toolbox utility will discover meters with communication modules on the Ethernet network. The meters can be on the same or different subnet as the PC running the Toolbox Utility. You can connect to the module that is on the same Ethernet subnet by using the connect button which will open the default WEB Browser on the PC.
  • Page 65 WEB Configuration Utility 6.1 WEB Configuration Utility BACnet Parameters Figure 6-2 BACnet Parameters network_nr This parameter sets the BACnet network number of the Gateway. All BACnet devices that are created will be on this network. The default is 0 which may be satisfactory for most simple applications.
  • Page 66 WEB Configuration Utility 6.1 WEB Configuration Utility __Dev_Name This parameter can be used to change the default BACnet Device Name of the node. The default names include the communication (IP or MSTP), the meter type, and the firmware type. This name may have to be changed to make the name unique system wide. Modbus Parameters Figure 6-3 Modbus Settings...
  • Page 67 WEB Configuration Utility 6.1 WEB Configuration Utility F US Clamp-on Communications Protocol Manual Hardware Installation Manual, 11/2015, A5E34981613-AC...

  • Page 69: Modbus, Eip, Hart & N2 Profile Mappings

    Appendix A Modbus, EIP, HART & N2 Profile Mappings A.1.1 Introduction To determine the flowmeter firmware version operating system part number: 1. At the meter, press the <MENU> key. 2. At [Meter Type] press the <Down Arrow> and scroll to [Meter Facilities]. 3.

  • Page 70: Profile 1

    Appendix A A.1 Modbus, EIP, HART & N2 Profile Mappings A.1.2 Profile 1 Profile 1 (FUS1010-5N01-5.04.05-1CO) Data Description Modbus Ethernet/IP HART Bytes Type Tag Name OS Format CMD VAR Type Site ID 30501 String String_In UINT16 BD(Byte) Date: Year 30101 Integer Analog_In Float...

  • Page 71: Profile 2

    Appendix A A.1 Modbus, EIP, HART & N2 Profile Mappings A.1.3 Profile 2 Profile 2 (FUS1010-5N01-5.04.05-1RF) Data Description Modbus Ethernet/IP HART Bytes Type Tag Name OS Format CMD VAR Type Ad Sz Site ID 30501 String String_In UINT16 BD(Byte) Date: Year 30101 Integer Analog_In...

  • Page 72: Profile 3

    Appendix A A.1 Modbus, EIP, HART & N2 Profile Mappings A.1.4 Profile 3 Profile 3 (FUS1010-5N02-5.04.05-1CO) Data Description Modbus Ethernet/IP HART Bytes Type Tag Name Format CMD VAR Type Site ID 30501 String String_In UINT16 BD(Byte) Date: Year 30101 Integer Analog_In Float ADI(Int)

  • Page 73: Profile 4

    Appendix A A.1 Modbus, EIP, HART & N2 Profile Mappings Temperature 2 30295 Real Analog_In Float ADF(Float) Temp Units 30753 String String_In UINT16 BD(Byte) Delta Time 30177 Real Analog_In Float ADF(Float) Delta Time Units 30629 String String_In UINT16 BD(Byte) Analog Input 1 30277 Real Analog_In...

  • Page 74: Profile 5

    Appendix A A.1 Modbus, EIP, HART & N2 Profile Mappings Status/Alarms: 10010 1 Bit Coil Binary_In UINT16 DI(Dig In) Zeromatic Temperature 1 30293 Real Analog_In Float ADF(Float) Temperature 2 30295 Real Analog_In Float ADF(Float) Temp Units 30753 String String_In UINT16 BD(Byte) 25 8 Analog Input 1...
  • Page 75 Appendix A A.1 Modbus, EIP, HART & N2 Profile Mappings C1 Aeration 30172 Integer Analog_In Float ADF(Float) C1 Aeration Units 30609 String String_In UINT16 BD(Byte) C1 Status 10021 1 Bit Coil Binary_In UINT16 DI(Dig In) /Alarms: Spacing C1 Status 10022 1 Bit Coil Binary_In...

  • Page 76: Profile 6

    Appendix A A.1 Modbus, EIP, HART & N2 Profile Mappings C2 Aeration 30173 Integer Analog_In Float ADF(Float) C2 Aeration Units 30613 String String_In UINT16 BD(Byte) 113 8 C2 Status 10041 1 Bit Coil Binary_In UINT16 DI(Dig In) /Alarms: Spacing C2 Status 10042 1 Bit Coil...
  • Page 77 Appendix A A.1 Modbus, EIP, HART & N2 Profile Mappings C1 Status/Alarms: 10022 1 Bit Coil Binary_In UINT16 DI(Dig In) Empty C1 Status/Alarms: 10023 1 Bit Coil Binary_In UINT16 DI(Dig In) Rate C1 Status/Alarms: 10024 1 Bit Coil Binary_In UINT16 DI(Dig In) Fault C1 Status/Alarms:...

  • Page 78: Profile 7

    Appendix A A.1 Modbus, EIP, HART & N2 Profile Mappings A.1.8 Profile 7 Profile 7 (FUS1010-5N03-5.04.05-1CO2RF) Data Description Modbus Ethernet/IP HART Bytes Type Tag Name OS Format CMD VAR Type Ad Sz C1 Site ID 30501 String String_In UINT16 BD(Byte) C1 Date: Year 30101 Integer...
  • Page 79 Appendix A A.1 Modbus, EIP, HART & N2 Profile Mappings C1 Status 10030 1 Bit Coil Binary_In UINT16 DI(Dig In) /Alarms: Zeroma- C1 Delta Time 30179 Real Analog_In Float ADF(Float) C1 Delta Time 30629 String String_In UINT16 BD(Byte) 57 8 Units C2 Site ID 30505...

  • Page 80: Profile 8

    Appendix A A.1 Modbus, EIP, HART & N2 Profile Mappings A.1.9 Profile 8 Profile 8 (FUS1010-5N03-5.04.05-DPCO) Data Description Modbus Ethernet/IP HART Bytes Type Tag Name OS Format Type Ad Sz Site ID 30501 String String_In UINT16 BD(Byte) Date: Year 30101 Integer Analog_In Float...
  • Page 81 Appendix A A.1 Modbus, EIP, HART & N2 Profile Mappings Status: Makeup 10027 1 Bit Coil Binary_In UINT16 DI(Dig In) Path 1 Status: Interface 10028 1 Bit Coil Binary_In UINT16 DI(Dig In) Path 1 Status: Zeromatic 10030 1 Bit Coil Binary_In UINT16 DI(Dig In)

  • Page 82: Profile 9

    Appendix A A.1 Modbus, EIP, HART & N2 Profile Mappings A.1.10 Profile 9 Profile 9 (FUS1010-5N03-5.04.05-1+2CO) Data Description Modbus Ethernet/IP HART Bytes Type Tag Name Format Type Ad Sz Site ID 30501 String String_In UINT16 BD(Byte) Date: Year 30101 Integer Analog_In Float ADI(Int)

  • Page 83: Profile 10

    Appendix A A.1 Modbus, EIP, HART & N2 Profile Mappings C2 Status/Alarms: 10042 1 Bit Coil Binary_In UINT16 DI(Dig In) 12 1 Empty C2 Status/Alarms: 10043 1 Bit Coil Binary_In UINT16 DI(Dig In) 13 1 Rate C2 Status/Alarms: 10044 1 Bit Coil Binary_In UINT16...
  • Page 84 Appendix A A.1 Modbus, EIP, HART & N2 Profile Mappings C1 Flow Rate 30517 String String_In UINT16 6-06h BD(Byte) Units C2 Inst.Flow 30111 Real Analog_In Float 7-07h Q ADF(Float) Rate C2 Flow Rate 30521 String String_In UINT16 7-07h BD(Byte) 17 8 Units C3 Inst.Flow 30113...

  • Page 85: Profile 11

    Appendix A A.1 Modbus, EIP, HART & N2 Profile Mappings C2 Status 10044 1 Bit Coil Binary_In UINT16 DI(Dig In) 14 1 /Alarms: Fault C2 Status 10045 1 Bit Coil Binary_In UINT16 DI(Dig In) 15 1 /Alarms: Aeration C2 Status 10046 1 Bit Coil...
  • Page 86 Appendix A A.1 Modbus, EIP, HART & N2 Profile Mappings C1 Inst.Flow Rate 30109 Real Analog_In Float 6-06h ADF(Float) C1 Avg Flow Rate 30121 Real Analog_In Float 1-01h P ADF(Float) C1 Flow Rate Units 30517 String String_In UINT16 1-01h BD(Byte) C1 Raw Flow 30133 Real...

  • Page 87: Profile 12

    Appendix A A.1 Modbus, EIP, HART & N2 Profile Mappings C2 Total 30147 Real Analog_In Float 35-23h Q ADF(Float) C2 Total Units 30561 String String_In UINT16 35-23h BD(Byte) 121 8 C2 Sonic Vel 30159 Real Analog_In Float ADF(Float) C2 Sonic Vel Units 30581 String String_In...
  • Page 88 Appendix A A.1 Modbus, EIP, HART & N2 Profile Mappings Date: Day 30103 Integer Analog_In Float ADI(Int) Time: Hour 30104 Integer Analog_In Float ADI(Int) Time: Minute 30105 Integer Analog_In Float ADI(Int) Time: Second 30106 Integer Analog_In Float ADI(Int) C1 Inst.Flow Rate 30109 Real Analog_In...

  • Page 89: Profile 13

    Appendix A A.1 Modbus, EIP, HART & N2 Profile Mappings C2 Status/Alarms: 10044 1 Bit Coil Binary_In UINT16 DI(Dig In) Fault C2 Status/Alarms: 10045 1 Bit Coil Binary_In UINT16 DI(Dig In) Aeration C2 Status/Alarms: 10046 1 Bit Coil Binary_In UINT16 DI(Dig In) Memory C2 Status/Alarms:...
  • Page 90 Appendix A A.1 Modbus, EIP, HART & N2 Profile Mappings C1 Sonic Vel 30157 Real Analog_In 10 Float (Float) C1 Sonic Vel 30577 String String_In UINT16 BD(Byte) Units C1 Signal 30167 Integer Analog_In 11 Float Strength (Float) C1 Sig Strength 30593 String String_In...
  • Page 91 Appendix A A.1 Modbus, EIP, HART & N2 Profile Mappings C2 Inst.Flow 30111 Real Analog_In 18 Float 7-07h Rate (Float) C2 Avg Flow 30123 Real Analog_In 19 Float 2-02 Rate (Float) C2 Flow Rate 30521 String String_In UINT16 2-02h BD(Byte) Units C2 Total 30147...

  • Page 92: Profile 14

    Appendix A A.1 Modbus, EIP, HART & N2 Profile Mappings A.1.15 Profile 14 Profile 14 (FUS1010-5N04-5.04.05-DPCO) Data Description Modbus Ethernet/IP HART Bytes Type Tag Name OS Format CMD VAR Type Site ID 30501 String String_In UINT16 BD(Byte) Date: Year 30101 Integer Analog_In 0 Float ADI(Int)
  • Page 93 Appendix A A.1 Modbus, EIP, HART & N2 Profile Mappings Status: Aeration 10025 1 Bit Coil Binary_In UINT16 DI(Dig In) Path 1 Status: Memory 10026 1 Bit Coil Binary_In UINT16 DI(Dig In) Path 1 Status: Makeup 10027 1 Bit Coil Binary_In UINT16 DI(Dig In)

  • Page 94: Profile 15

    Appendix A A.1 Modbus, EIP, HART & N2 Profile Mappings Delta Time 30181 Real Analog_In 24 Float ADF(Float) Path 2 Delta Time Units 30629 String String_In UINT16 BD(Byte) Aux Input 1 30285 Real Analog_In 25 Float ADF(Float) Aux 1 Type 30813 String String_In...
  • Page 95 Appendix A A.1 Modbus, EIP, HART & N2 Profile Mappings Sonic Vel Units 30577 String String_In UINT16 BD(Byte) 57 8 C1 Status 10021 1 Bit Coil Binary_In UINT16 DI(Dig In) /Alarms: Spacing C1 Status 10022 1 Bit Coil Binary_In UINT16 DI(Dig In) /Alarms: Empty C1 Status...
  • Page 96 Appendix A A.1 Modbus, EIP, HART & N2 Profile Mappings C3 Status 10065 1 Bit Coil Binary_In UINT16 DI(Dig In) 24 1 /Alarms: Aeration C3 Status 10066 1 Bit Coil Binary_In UINT16 DI(Dig In) 25 1 /Alarms: Memory C3 Status 10067 1 Bit Coil...

  • Page 97: Profile 16

    Appendix A A.1 Modbus, EIP, HART & N2 Profile Mappings A.1.17 Profile 16 Profile 16 (FUS1010-5N04-5.04.05-1-2CO) Data Description Modbus Ethernet/IP HART Bytes Type Tag Name OS Format CMD VAR Type Ad Sz Site ID 30501 String String_In UINT16 BD(Byte) Date: Year 30101 Integer Analog_In...
  • Page 98 Appendix A A.1 Modbus, EIP, HART & N2 Profile Mappings C1 Status 10027 1 Bit Coil Binary_In UINT16 DI(Dig In) /Alarms: Makeup C1 Status 10028 1 Bit Coil Binary_In UINT16 DI(Dig In) /Alarms: Interface C1 Status 10030 1 Bit Coil Binary_In UINT16 DI(Dig In)

  • Page 99: Profile 17

    Appendix A A.1 Modbus, EIP, HART & N2 Profile Mappings Temp Units 30753 String String_In UINT16 BD(Byte) 65 8 Aux Input 1 30285 Real Analog_In Float ADF(Float) 12 1 Aux 1 Type 30813 String String_In UINT16 BD(Byte) 73 8 Aux Input 2 30287 Real Analog_In...
  • Page 100 Appendix A A.1 Modbus, EIP, HART & N2 Profile Mappings C1 Status 10025 1 Bit Coil Binary_In UINT16 DI(Dig In) /Alarms: Aeration C1 Status 10026 1 Bit Coil Binary_In UINT16 DI(Dig In) /Alarms: Memory C1 Status 10027 1 Bit Coil Binary_In UINT16 DI(Dig In)
  • Page 101 Appendix A A.1 Modbus, EIP, HART & N2 Profile Mappings C2 Status 10047 1 Bit Coil Binary_In UINT16 DI(Dig In) /Alarms: Makeup C2 Status 10048 1 Bit Coil Binary_In UINT16 DI(Dig In) /Alarms: Interface C2 Status 10050 1 Bit Coil Binary_In UINT16 DI(Dig In)
  • Page 102 Appendix A A.1 Modbus, EIP, HART & N2 Profile Mappings C3 Status 10070 1 Bit Coil Binary_In UINT16 DI(Dig In) /Alarms: Zeroma- C3 Delta Time 30183 Real Analog_In Float ADF(Float) C3 Delta Time 30637 String String_In UINT16 BD(Byte) 185 8 Units C4 Site ID 30513...

  • Page 103: Profile 18

    Appendix A A.1 Modbus, EIP, HART & N2 Profile Mappings A.1.19 Profile 18 Profile 18 (FUS1010-5MN01-5.04.05-1+2+3+4CO) Data Description Modbus Ethernet/IP HART Bytes Type Tag Name OS Format Type Site ID 30501 String String_In UINT16 BD(Byte) Date: Year 30101 Integer Analog_In Float ADI(Int) Date: Month...
  • Page 104 Appendix A A.1 Modbus, EIP, HART & N2 Profile Mappings C1 Status 10021 1 Bit Coil Binary_In UINT16 DI(Dig In) /Alarms: Spacing C1 Status 10022 1 Bit Coil Binary_In UINT16 DI(Dig In) /Alarms: Empty C1 Status 10023 1 Bit Coil Binary_In UINT16 DI(Dig In)
  • Page 105 Appendix A A.1 Modbus, EIP, HART & N2 Profile Mappings C3 Status 10064 1 Bit Coil Binary_In UINT16 DI(Dig In) /Alarms: Fault C3 Status 10065 1 Bit Coil Binary_In UINT16 DI(Dig In) /Alarms: Aeration C3 Status 10066 1 Bit Coil Binary_In UINT16 DI(Dig In)

  • Page 106: Profile 19

    Appendix A A.1 Modbus, EIP, HART & N2 Profile Mappings C5 Status 10108 1 Bit Coil Binary_In UINT16 DI(Dig In) /Alarms: Interface C5 Status 10110 1 Bit Coil Binary_In UINT16 DI(Dig In) /Alarms: Zeroma- A.1.20 Profile 19 Profile 19 (FUS1010-5MN01-5.04.05-QPCO) Data Description Modbus Ethernet/IP...
  • Page 107 Appendix A A.1 Modbus, EIP, HART & N2 Profile Mappings Signal Strength 30169 Integer Analog_In Float ADF(Float) Path 3 Signal Strength 30170 Integer Analog_In Float ADF(Float) Path 4 Signal Strength 30165 Integer Analog_In Float ADF(Float) Sig Strength 30593 String String_In UINT16 BD(Byte) Units...
  • Page 108 Appendix A A.1 Modbus, EIP, HART & N2 Profile Mappings Status: Fault 10064 1 Bit Coil Binary_In UINT16 DI(Dig In) Path 3 Status: Aeration 10065 1 Bit Coil Binary_In UINT16 DI(Dig In) Path 3 Status: Memory 10066 1 Bit Coil Binary_In UINT16 DI(Dig In)

  • Page 109: Profile 20

    Appendix A A.1 Modbus, EIP, HART & N2 Profile Mappings Delta Time 30183 Real Analog_In Float ADF(Float) Path 3 Delta Time 30185 Real Analog_In Float ADF(Float) Path 4 Delta Time Units 30629 String String_In UINT16 BD(Byte) A.1.21 Profile 20 Profile 20 (FUS1010-5MN02-5.04.05-1CO2CO3CO4CO) Data Description Modbus Ethernet/IP...
  • Page 110 Appendix A A.1 Modbus, EIP, HART & N2 Profile Mappings C1 Status 10023 1 Bit Coil Binary_In UINT16 DI(Dig In) /Alarms: Rate C1 Status 10024 1 Bit Coil Binary_In UINT16 DI(Dig In) /Alarms: Fault C1 Status 10025 1 Bit Coil Binary_In UINT16 DI(Dig In)
  • Page 111 Appendix A A.1 Modbus, EIP, HART & N2 Profile Mappings C2 Status 10042 1 Bit Coil Binary_In UINT16 DI(Dig In) /Alarms: Empty C2 Status 10043 1 Bit Coil Binary_In UINT16 DI(Dig In) /Alarms: Rate C2 Status 10044 1 Bit Coil Binary_In UINT16 DI(Dig In)
  • Page 112 Appendix A A.1 Modbus, EIP, HART & N2 Profile Mappings C3 S.G. Units 30697 String String_In UINT16 ADI(Int) 123 8 C3 Status 10061 1 Bit Coil Binary_In UINT16 DI(Dig In) /Alarms: Spacing C3 Status 10062 1 Bit Coil Binary_In UINT16 DI(Dig In) /Alarms: Empty C3 Status...

  • Page 113: Profile 21

    Appendix A A.1 Modbus, EIP, HART & N2 Profile Mappings C4 Sig Strength 30605 String String_In UINT16 ADI(Int) 159 8 Units C4 Aeration 30175 Integer Analog_In Float ADF(Float) C4 Aeration Units 30621 String String_In UINT16 ADI(Int) 163 8 C4 Specific 30245 Real Analog_In...
  • Page 114 Appendix A A.1 Modbus, EIP, HART & N2 Profile Mappings Time: Hour 30104 Integer Analog_In Float ADI(Int) Time: Minute 30105 Integer Analog_In Float ADI(Int) Time: Second 30106 Integer Analog_In Float ADI(Int) C1 Inst.Flow 30109 Real Analog_In Float 6-06h T ADF(Float) Rate C1 Flow Rate 30517...
  • Page 115 Appendix A A.1 Modbus, EIP, HART & N2 Profile Mappings C1 Status 10025 1 Bit Coil Binary_In UINT16 DI(Dig In) /Alarms: Aeration C1 Status 10026 1 Bit Coil Binary_In UINT16 DI(Dig In) /Alarms: Memory C1 Status 10027 1 Bit Coil Binary_In UINT16 DI(Dig In)
  • Page 116 Appendix A A.1 Modbus, EIP, HART & N2 Profile Mappings C3 Status 10070 1 Bit Coil Binary_In UINT16 DI(Dig In) /Alarms: Zeromatic C4 Status 10081 1 Bit Coil Binary_In UINT16 DI(Dig In) /Alarms: Spacing C4 Status 10082 1 Bit Coil Binary_In UINT16 DI(Dig In)

  • Page 117: Profile 22

    Appendix A A.1 Modbus, EIP, HART & N2 Profile Mappings A.1.23 Profile 22 Profile 22 (FUS1010-5MN02-5.04.05-QPCO) Data Description Modbus Ethernet/IP HART Bytes Type Tag Name OS Format CMD VAR Type Site ID 30501 String String_In UINT16 BD(Byte) Date: Year 30101 Integer Analog_In Float ADI(Int)
  • Page 118 Appendix A A.1 Modbus, EIP, HART & N2 Profile Mappings Aeration Units 30609 String String_In UINT16 BD(Byte) Specific Gravity 30237 Real Analog_In Float 14-0Eh ADF(Float) S.G. Units 30689 String String_In UINT16 14-0Eh BD(Byte) Status: Spacing 10021 1 Bit Coil Binary_In UINT16 DI(Dig In) Path 1...
  • Page 119 Appendix A A.1 Modbus, EIP, HART & N2 Profile Mappings Status: Makeup 10067 1 Bit Coil Binary_In UINT16 DI(Dig In) Path 3 Status: Interface 10068 1 Bit Coil Binary_In UINT16 DI(Dig In) Path 3 Status: Zeromatic 10070 1 Bit Coil Binary_In UINT16 DI(Dig In)
  • Page 120 Appendix A A.1 Modbus, EIP, HART & N2 Profile Mappings Delta Time 30185 Real Analog_In Float ADF(Float) Path 4 Delta Time Units 30629 String String_In UINT16 BD(Byte) Aux I Input 30285 Real Analog_In Float ADF(Float) Aux 1 Type 30813 String String_In UINT16 BD(Byte)

  • Page 121: Profile 23

    Appendix A A.1 Modbus, EIP, HART & N2 Profile Mappings A.1.24 Profile 23 Profile 23 (FUE1010-5EN02-5.04.05-1CO) Data Description Modbus Ethernet/IP HART Bytes Type Tag Name OS Format CMD VAR Type Site ID 30501 String String_In UINT16 BD(Byte) Date: Year 30101 Integer Analog_In Float...

  • Page 122: Profile 24

    Appendix A A.1 Modbus, EIP, HART & N2 Profile Mappings Status/Alarms: 10007 1 Bit Coil Binary_In UINT16 DI(Dig In) Makeup Status/Alarms: 10008 1 Bit Coil Binary_In UINT16 DI(Dig In) Interface Status/Alarms: 10010 1 Bit Coil Binary_In UINT16 DI(Dig In) Zeromatic Delta Time 30177 Real...
  • Page 123 Appendix A A.1 Modbus, EIP, HART & N2 Profile Mappings Supply Temp 30773 String String_In UINT16 BD(Byte) Units Return Temp 30307 Real Analog_In Float ADF(Float) Return Temp 30781 String String_In UINT16 BD(Byte) Units Temp Difference 30313 Real Analog_In Float ADF(Float) Temp Diff Units 30789 String...

  • Page 124: Profile 25

    Appendix A A.1 Modbus, EIP, HART & N2 Profile Mappings A.1.26 Profile 25 Profile 25 (FUE1010-5EN03-5.04.05-1CO2CO) Data Description Modbus Ethernet/IP HART Bytes Type Tag Name OS Format CMD VAR Type C1 Site ID 30501 String String_In UINT16 BD(Byte) Date: Year 30101 Integer Analog_In Float...
  • Page 125 Appendix A A.1 Modbus, EIP, HART & N2 Profile Mappings C1 Aeration 30172 Integer Analog_In Float ADF(Float) C1 Aeration Units 30609 String String_In UINT16 BD(Byte) C1 Status 10021 1 Bit Coil Binary_In UINT16 DI(Dig In) /Alarms: Spacing C1 Status 10022 1 Bit Coil Binary_In...

  • Page 126: Profile 26

    Appendix A A.1 Modbus, EIP, HART & N2 Profile Mappings C2 Supply Temp 30777 String String_In UINT16 BD(Byte) 161 8 Units C2 Return Temp 30311 Real Analog_In Float ADF(Float) C2 Return Temp 30785 String String_In UINT16 BD(Byte) 169 8 Units C2 Temp 30317 Real...
  • Page 127 Appendix A A.1 Modbus, EIP, HART & N2 Profile Mappings Date: Day 30103 Integer Analog_In Float ADI(Int) Time: Hour 30104 Integer Analog_In Float ADI(Int) Time: Minute 30105 Integer Analog_In Float ADI(Int) Time: Second 30106 Integer Analog_In Float ADI(Int) C1 Avg Energy 30201 Real Analog_In...
  • Page 128 Appendix A A.1 Modbus, EIP, HART & N2 Profile Mappings C1 Status 10030 1 Bit Coil Binary_In UINT16 DI(Dig In) /Alarms: Zeromatic C1 Percent 30189 Real Analog_In Float ADF(Float) Deviation C1 Deviation 30645 String String_In UINT16 BD(Byte) Units C2 Site ID 30505 String String_In...
  • Page 129 Appendix A A.1 Modbus, EIP, HART & N2 Profile Mappings C2 Status 10048 1 Bit Coil Binary_In UINT16 DI(Dig In) /Alarms: Interface C2 Status 10050 1 Bit Coil Binary_In UINT16 DI(Dig In) /Alarms: Zeroma- C2 Percent Devi- 30191 Real Analog_In Float ADF(Float) ation...

  • Page 130: Profile 27

    Appendix A A.1 Modbus, EIP, HART & N2 Profile Mappings A.1.28 Profile 27 Profile 27 (FUE1010-5EN03-5.04.05-1CO2RF) Data Description Modbus Ethernet/IP HART Bytes Type Tag Name OS Format CMD VAR Type C1 Site ID 30501 String String_In UINT16 BD(Byte) Date: Year 30101 Integer Analog_In Float...
  • Page 131 Appendix A A.1 Modbus, EIP, HART & N2 Profile Mappings C1 Aeration Units 30609 String String_In UINT16 BD(Byte) C1 Status 10021 1 Bit Coil Binary_In UINT16 DI(Dig In) /Alarms: Spacing C1 Status 10022 1 Bit Coil Binary_In UINT16 DI(Dig In) /Alarms: Empty C1 Status 10023...
  • Page 132 Appendix A A.1 Modbus, EIP, HART & N2 Profile Mappings C2 Temp Diff 30793 String String_In UINT16 BD(Byte) 161 8 Units C2 Status 10041 1 Bit Coil Binary_In UINT16 DI(Dig In) /Alarms: Spacing C2 Status 10042 1 Bit Coil Binary_In UINT16 DI(Dig In) /Alarms: Empty...

  • Page 133: Profile 28

    Appendix A A.1 Modbus, EIP, HART & N2 Profile Mappings A.1.29 Profile 28 Profile 28 (FUE1010-5EN03-5.04.05-DPCO) Data Description Modbus Ethernet/IP HART Bytes Type Tag Name OS Format CMD VAR Type Site ID 30501 String String_In UINT16 BD(Byte) Date: Year 30101 Integer Analog_In Float ADI(Int)
  • Page 134 Appendix A A.1 Modbus, EIP, HART & N2 Profile Mappings Sig Strength 30593 String String_In UINT16 BD(Byte) Units Aeration 30171 Integer Analog_In Float ADF(Float) Aeration Units 30609 String String_In UINT16 BD(Byte) Status: Spacing 10021 1 Bit Coil Binary_In UINT16 DI(Dig In) Path 1 Status: Empty 10022...

  • Page 135: Profile 29

    Appendix A A.1 Modbus, EIP, HART & N2 Profile Mappings Status/Alarms: 10007 1 Bit Coil Binary_In UINT16 DI(Dig In) Makeup Status/Alarms: 10008 1 Bit Coil Binary_In UINT16 DI(Dig In) Interface Status/Alarms: 10010 1 Bit Coil Binary_In UINT16 DI(Dig In) Zeromatic Delta Time 30179 Real...
  • Page 136 Appendix A A.1 Modbus, EIP, HART & N2 Profile Mappings C2 Total Units 30561 String String_In UINT16 35-23h BD(Byte) C3 Total 30149 Real Analog_In 15 Float 36-24h S ADF(Float) C3 Total Units 30565 String String_In UINT16 36-24h BD(Byte) C1 Sonic Vel 30157 Real Analog_In 16...

  • Page 137: Profile 30

    Appendix A A.1 Modbus, EIP, HART & N2 Profile Mappings C2 Status 10048 1 Bit Coil Binary_In UINT16 DI(Dig In) /Alarms: Interface C2 Status 10050 1 Bit Coil Binary_In UINT16 DI(Dig In) /Alarms: Zeroma- C3 Status 10061 1 Bit Coil Binary_In UINT16 DI(Dig In)
  • Page 138 Appendix A A.1 Modbus, EIP, HART & N2 Profile Mappings C1 Inst.Flow 30109 Real Analog_In Float 6-06h ADF(Float) Rate C1 Avg Flow 30121 Real Analog_In Float 1-01h P ADF(Float) Rate C1 Flow Rate 30517 String String_In UINT16 1-01h BD(Byte) Units C1 Raw Flow 30133 Real...
  • Page 139 Appendix A A.1 Modbus, EIP, HART & N2 Profile Mappings C1 Delta Time 30179 Real Analog_In 19 Float ADF(Float) C1 Delta Time 30629 String String_In UINT16 BD(Byte) Units C1 Analog 30277 Real Analog_In 20 Float ADF(Float) Input 1 C1 AI1 Units 30797 String String_In...

  • Page 140: Profile 31

    Appendix A A.1 Modbus, EIP, HART & N2 Profile Mappings C2 Sig Strength 30597 String String_In UINT16 BD(Byte) 201 8 Units C2 Aeration 30173 Integer Analog_In Float ADF(Float) C2 Aeration Units 30613 String String_In UINT16 BD(Byte) 209 8 C2 Status 10041 1 Bit Coil...
  • Page 141 Appendix A A.1 Modbus, EIP, HART & N2 Profile Mappings Time: Hour 30104 Integer Analog_In Float ADI(Int) Time: Minute 30105 Integer Analog_In Float ADI(Int) Time: Second 30106 Integer Analog_In Float ADI(Int) C1 Avg Energy 30201 Real Analog_In Float 40-28h S ADF(Float) Rate C1 Inst.Energy...
  • Page 142 Appendix A A.1 Modbus, EIP, HART & N2 Profile Mappings C1 Analog 30277 Real Analog_In Float ADF(Float) Input 1 C1 AI1 Units 30797 String String_In UINT16 BD(Byte) C1 Percent 30189 Real Analog_In Float ADF(Float) Deviation C1 Deviation 30645 String String_In UINT16 BD(Byte) Units...

  • Page 143: Profile 32

    Appendix A A.1 Modbus, EIP, HART & N2 Profile Mappings C2 Status 10044 1 Bit Coil Binary_In UINT16 DI(Dig In) /Alarms: Fault C2 Status 10045 1 Bit Coil Binary_In UINT16 DI(Dig In) /Alarms: Aeration C2 Status 10046 1 Bit Coil Binary_In UINT16 DI(Dig In)
  • Page 144 Appendix A A.1 Modbus, EIP, HART & N2 Profile Mappings C1 Energy Total 30207 Real Analog_In Float 43-2Bh ADF(Float) C1 EnergyTotal 30661 String String_In UINT16 43-2Bh BD(Byte) Units C1 Inst.Flow 30109 Real Analog_In Float 6-06h ADF(Float) Rate C1 Avg Flow 30121 Real Analog_In...
  • Page 145 Appendix A A.1 Modbus, EIP, HART & N2 Profile Mappings C1 Status 10030 1 Bit Coil Binary_In UINT16 DI(Dig In) /Alarms: Zeroma- C1 Delta Time 30179 Real Analog_In Float ADF(Float) C1 Delta Time 30629 String String_In UINT16 BD(Byte) Units C1 Analog 30277 Real Analog_In...
  • Page 146 Appendix A A.1 Modbus, EIP, HART & N2 Profile Mappings C2 Status 10044 1 Bit Coil Binary_In UINT16 DI(Dig In) /Alarms: Fault C2 Status 10045 1 Bit Coil Binary_In UINT16 DI(Dig In) /Alarms: Aeration C2 Status 10046 1 Bit Coil Binary_In UINT16 DI(Dig In)

  • Page 147: Profile 33

    Appendix A A.1 Modbus, EIP, HART & N2 Profile Mappings A.1.34 Profile 33 Profile 33 (FUE1010-5EN04-5.04.05-1+2CO) Data Description Modbus Ethernet/IP HART Bytes Type Tag Name OS Format CMD VAR Type Site ID 30501 String String_In UINT16 BD(Byte) Date: Year 30101 Integer Analog_In Float ADI(Int)
  • Page 148 Appendix A A.1 Modbus, EIP, HART & N2 Profile Mappings Temp Diff Units 30789 String String_In UINT16 BD(Byte) C1 Status 10021 1 Bit Coil Binary_In UINT16 DI(Dig In) /Alarms: Spacing C1 Status 10022 1 Bit Coil Binary_In UINT16 DI(Dig In) /Alarms: Empty C1 Status 10023...
  • Page 149 Appendix A A.1 Modbus, EIP, HART & N2 Profile Mappings C3 Status 10065 1 Bit Coil Binary_In UINT16 DI(Dig In) /Alarms: Aeration C3 Status 10066 1 Bit Coil Binary_In UINT16 DI(Dig In) /Alarms: Memory C3 Status 10067 1 Bit Coil Binary_In UINT16 DI(Dig In)

  • Page 150: Profile 34

    Appendix A A.1 Modbus, EIP, HART & N2 Profile Mappings A.1.35 Profile 34 Profile 34 (FUE1010-5EN04-5.04.05-DPCO) Data Description Modbus Ethernet/IP HART Bytes Type Tag Name Format CMD VAR Type Site ID 30501 String String_In UINT16 BD(Byte) Date: Year 30101 Integer Analog_In Float ADI(Int) Date: Month...
  • Page 151 Appendix A A.1 Modbus, EIP, HART & N2 Profile Mappings Sig Strength 30593 String String_In UINT16 BD(Byte) Units Aeration 30171 Integer Analog_In Float ADF(Float) Aeration Units 30609 String String_In UINT16 BD(Byte) Status: Spacing 10021 1 Bit Coil Binary_In UINT16 DI(Dig In) Path 1 Status: Empty 10022...

  • Page 152: Profile 35

    Appendix A A.1 Modbus, EIP, HART & N2 Profile Mappings Status/Alarms: 10007 1 Bit Coil Binary_In UINT16 DI(Dig In) Makeup Status/Alarms: 10008 1 Bit Coil Binary_In UINT16 DI(Dig In) Interface Status/Alarms: 10010 1 Bit Coil Binary_In UINT16 DI(Dig In) Zeromatic Delta Time 30179 Real...
  • Page 153 Appendix A A.1 Modbus, EIP, HART & N2 Profile Mappings Sig Strength 30593 String String_In UINT16 BD(Byte) Units Aeration 30171 Integer Analog_In Float ADF(Float) Aeration Units 30609 String String_In UINT16 BD(Byte) Liquident 30229 Real Analog_In Float ADF(Float) Liquident Units 30677 String String_In UINT16...

  • Page 154: Profile 36

    Appendix A A.1 Modbus, EIP, HART & N2 Profile Mappings A.1.37 Profile 36 Profile 36 (FUH1010-5PVN02-5.04.05-DPCO) Data Description Modbus Ethernet/IP HART Bytes Type Tag Name Format CMD VAR Type Site ID 30501 String String_In UINT16 BD(Byte) Date: Year 30101 Integer Analog_In Float ADI(Int) Date: Month...
  • Page 155 Appendix A A.1 Modbus, EIP, HART & N2 Profile Mappings Status: Fault 10024 1 Bit Coil Binary_In UINT16 DI(Dig In) Path 1 Status: Aeration 10025 1 Bit Coil Binary_In UINT16 DI(Dig In) Path 1 Status: Memory 10026 1 Bit Coil Binary_In UINT16 DI(Dig In)
  • Page 156 Appendix A A.1 Modbus, EIP, HART & N2 Profile Mappings Status/Alarms: 10010 1 Bit Coil Binary_In UINT16 DI(Dig In) Zeromatic Temperature 1 30293 Real Analog_In Float ADF(Float) Temperature 2 30295 Real Analog_In Float ADF(Float) Temp Units 30753 String String_In UINT16 BD(Byte) Delta Time 30179...

  • Page 157: Profile 37

    Appendix A A.1 Modbus, EIP, HART & N2 Profile Mappings A.1.38 Profile 37 Profile 37 (FUH1010-5PVN03-5.04.05-DPCO) Data Description Modbus Ethernet/IP HART Bytes Type Tag Name OS Format CMD VAR Type Site ID 30501 String String_In UINT16 BD(Byte) Date: Year 30101 Integer Analog_In Float ADI(Int)
  • Page 158 Appendix A A.1 Modbus, EIP, HART & N2 Profile Mappings Status: Fault 10024 1 Bit Coil Binary_In UINT16 DI(Dig In) Path 1 Status: Aeration 10025 1 Bit Coil Binary_In UINT16 DI(Dig In) Path 1 Status: Memory 10026 1 Bit Coil Binary_In UINT16 DI(Dig In)

  • Page 159: Profile 38

    Appendix A A.1 Modbus, EIP, HART & N2 Profile Mappings Status/Alarms: 10010 1 Bit Coil Binary_In UINT16 DI(Dig In) Zeromatic Temperature 1 30293 Real Analog_In Float ADF(Float) Temperature 2 30295 Real Analog_In Float ADF(Float) Temp Units 30753 String String_In UINT16 BD(Byte) Delta Time 30179...
  • Page 160 Appendix A A.1 Modbus, EIP, HART & N2 Profile Mappings Specific Gravity 30237 Real Analog_In Float 14-0Eh P ADF(Float) S.G. Units 30689 String String_In UINT16 14-0Eh BD(Byte) 30247 Real Analog_In Float 17-11h S ADF(Float) API Units 30705 String String_In UINT16 17-11h BD(Byte) Kg/m3...

  • Page 161: Profile 39

    Appendix A A.1 Modbus, EIP, HART & N2 Profile Mappings A.1.40 Profile 39 Profile 39 (FUH1010-5BN02-5.04.05-1CO2CO) Data Description Modbus Ethernet/IP HART Bytes Type Tag Name Format CMD VAR Type C1 Site ID 30501 String String_In UINT16 BD(Byte) Date: Year 30101 Integer Analog_In Float ADI(Int)
  • Page 162 Appendix A A.1 Modbus, EIP, HART & N2 Profile Mappings C1 Status 10023 1 Bit Coil Binary_In UINT16 DI(Dig In) /Alarms: Rate C1 Status 10024 1 Bit Coil Binary_In UINT16 DI(Dig In) /Alarms: Fault C1 Status 10025 1 Bit Coil Binary_In UINT16 DI(Dig In)

  • Page 163: Profile 40

    Appendix A A.1 Modbus, EIP, HART & N2 Profile Mappings C2 Base S.G. 30725 String String_In UINT16 25-19h BD(Byte) 209 8 Units C2 Base API 30269 Real Analog_In Float 28-1Ch ADF(Float) C2 Base API 30733 String String_In UINT16 28-1Ch BD(Byte) 217 8 Units C2 Base Kg/m3...
  • Page 164 Appendix A A.1 Modbus, EIP, HART & N2 Profile Mappings Date: Day 30103 Integer Analog_In Float ADI(Int) Time: Hour 30104 Integer Analog_In Float ADI(Int) Time: Minute 30105 Integer Analog_In Float ADI(Int) Time: Second 30106 Integer Analog_In Float ADI(Int) Inst.Flow Rate 30109 Real Analog_In...
  • Page 165 Appendix A A.1 Modbus, EIP, HART & N2 Profile Mappings Status: Empth 10022 1 Bit Coil Binary_In UINT16 DI(Dig In) Path 1 Status: Rate 10023 1 Bit Coil Binary_In UINT16 DI(Dig In) Path 1 Status: Fault 10024 1 Bit Coil Binary_In UINT16 DI(Dig In)

  • Page 166: Profile 41

    Appendix A A.1 Modbus, EIP, HART & N2 Profile Mappings Status/Alarms: 10008 1 Bit Coil Binary_In UINT16 DI(Dig In) Interface Status/Alarms: 10009 1 Bit Coil Binary_In UINT16 DI(Dig In) Status/Alarms: 10010 1 Bit Coil Binary_In UINT16 DI(Dig In) Zeromatic Temperature 1 30293 Real Analog_In...
  • Page 167 Appendix A A.1 Modbus, EIP, HART & N2 Profile Mappings Raw Flow Units 30537 String String_In UINT16 BD(Byte) Total 30143 Real Analog_In 12 Float 33-21h S ADF(Float) Total Units 30557 String String_In UINT16 33-21h BD(Byte) Sonic Vel Path 1 30157 Real Analog_In 13 Float...
  • Page 168 Appendix A A.1 Modbus, EIP, HART & N2 Profile Mappings Status: Pig 10029 1 Bit Coil Binary_In UINT16 DI(Dig In) Path 1 Status: Zeromatic 10030 1 Bit Coil Binary_In UINT16 DI(Dig In) Path 1 Status: Spacing 10041 1 Bit Coil Binary_In UINT16 DI(Dig In)

  • Page 169: Profile 42

    Appendix A A.1 Modbus, EIP, HART & N2 Profile Mappings Delta Time Units 30629 String String_In UINT16 BD(Byte) 129 8 Analog Input 1 30277 Real Analog_In 31 Float ADF(Float) AI1 Units 30797 String String_In UINT16 BD(Byte) 137 8 Analog Input 2 30279 Real Analog_In 32...
  • Page 170 Appendix A A.1 Modbus, EIP, HART & N2 Profile Mappings Sonic Vel 30155 Real Analog_In Float ADF(Float) Sonic Vel Units 30577 String String_In UINT16 BD(Byte) Signal Strength 30167 Integer Analog_In Float ADF(Float) Path 1 Signal Strength 30168 Integer Analog_In Float ADF(Float) Path 2 Signal Strength...
  • Page 171 Appendix A A.1 Modbus, EIP, HART & N2 Profile Mappings Status: Zeromatic 10030 1 Bit Coil Binary_In UINT16 DI(Dig In) Path 1 Status: Spacing 10041 1 Bit Coil Binary_In UINT16 DI(Dig In) Path 2 Status: Empty 10042 1 Bit Coil Binary_In UINT16 DI(Dig In)
  • Page 172 Appendix A A.1 Modbus, EIP, HART & N2 Profile Mappings Status: Memory 10086 1 Bit Coil Binary_In UINT16 DI(Dig In) Path 4 Status: Makeup 10087 1 Bit Coil Binary_In UINT16 DI(Dig In) Path 4 Status: Interface 10088 1 Bit Coil Binary_In UINT16 DI(Dig In)

  • Page 173: Profile 43

    Appendix A A.1 Modbus, EIP, HART & N2 Profile Mappings AI4 Units 30809 String String_In UINT16 BD(Byte) 161 8 Note: Turn off Sonilocate A.1.44 Profile 43 Profile 43 (FUG1010-5GN03-5.04.05-1CO) Data Description Modbus Ethernet/IP HART Bytes Type Tag Name OS Format CMD VAR Type Site ID...
  • Page 174 Appendix A A.1 Modbus, EIP, HART & N2 Profile Mappings Status/Alarms: 10007 1 Bit Coil Binary_In UINT16 DI(Dig In) Makeup Status/Alarms: 10008 1 Bit Coil Binary_In UINT16 DI(Dig In) Interface Status/Alarms: 10010 1 Bit Coil Binary_In UINT16 DI(Dig In) Zeromatic Status/Alarms: 10011 1 Bit...

  • Page 175: Profile 44

    Appendix A A.1 Modbus, EIP, HART & N2 Profile Mappings A.1.45 Profile 44 Profile 44 (FUG1010-5GN04-5.04.05-DPCO) Data Description Modbus Ethernet/IP HART Bytes Type Tag Name OS Format CMD VAR Type Site ID 30501 String String_In UINT16 BD(Byte) Date: Year 30101 Integer Analog_In Float ADI(Int)
  • Page 176 Appendix A A.1 Modbus, EIP, HART & N2 Profile Mappings Status: Rate 10023 1 Bit Coil Binary_In UINT16 DI(Dig In) Path 1 Status: Fault 10024 1 Bit Coil Binary_In UINT16 DI(Dig In) Path 1 Status: Memory 10006 1 Bit Coil Binary_In UINT16 DI(Dig In)

  • Page 177: Profile 45

    Appendix A A.1 Modbus, EIP, HART & N2 Profile Mappings Temperature 1 30293 Real Analog_In Float ADF(Float) Temperature 2 30295 Real Analog_In Float ADF(Float) Temp Units 30753 String String_In UINT16 BD(Byte) Delta Time 30179 Real Analog_In Float ADF(Float) Path 1 Delta Time 30181 Real...
  • Page 178 Appendix A A.1 Modbus, EIP, HART & N2 Profile Mappings Sonic Vel Path 2 30159 Real Analog_In 15 Float ADF(Float) Sonic Vel 30155 Real Analog_In 16 Float ADF(Float) Sonic Vel Units 30577 String String_In UINT16 BD(Byte) Signal Strength 30167 Real Analog_In 17 Float ADF(Float)

  • Page 179: Profile 46

    Appendix A A.1 Modbus, EIP, HART & N2 Profile Mappings Status: Turbu- 10051 1 Bit Coil Binary_In UINT16 DI(Dig In) lence Path 2 Status/Alarms: 10001 1 Bit Coil Binary_In UINT16 DI(Dig In) Spacing Status/Alarms: 10002 1 Bit Coil Binary_In UINT16 DI(Dig In) Empty Status/Alarms:...
  • Page 180 Appendix A A.1 Modbus, EIP, HART & N2 Profile Mappings Time: Minute 30105 Integer Analog_In Float ADI(Int) Time: Second 30106 Integer Analog_In Float ADI(Int) Inst.Flow Rate 30109 Real Analog_In Float 10-0Ah ADF(Float) Path 1 Inst.Flow Rate 30111 Real Analog_In Float 11-0Bh ADF(Float) Path 2...
  • Page 181 Appendix A A.1 Modbus, EIP, HART & N2 Profile Mappings Status: Spacing 10021 1 Bit Coil Binary_In UINT16 DI(Dig In) Path 1 Status: Empty 10022 1 Bit Coil Binary_In UINT16 DI(Dig In) Path 1 Status: Rate 10023 1 Bit Coil Binary_In UINT16 DI(Dig In)
  • Page 182 Appendix A A.1 Modbus, EIP, HART & N2 Profile Mappings Status: Turbu- 10071 1 Bit Coil Binary_In UINT16 DI(Dig In) lence Path 3 Status: Spacing 10081 1 Bit Coil Binary_In UINT16 DI(Dig In) Path 4 Status: Empty 10082 1 Bit Coil Binary_In UINT16...
  • Page 183 Appendix A A.1 Modbus, EIP, HART & N2 Profile Mappings Analog Input 1 30277 Real Analog_In Float ADF(Float) AI1 Units 30797 String String_In UINT16 BD(Byte) Analog Input 2 30279 Real Analog_In Float ADF(Float) AI2 Units 30801 String String_In UINT16 BD(Byte) 105 8 Analog Input 3 30281...

  • Page 185: Glossary

    Glossary Alphanumeric Field An 8-character data entry field that allows you to specify a Site Name or a Security code. Arrow Keys Use the <Up, Down, Left and Right> Arrows to navigate through the Installation Menu in their respective directions. The <Up or Down> Arrows allow you also to scroll through option list items.
  • Page 186 Glossary Flow Meter Refers to the flow meter itself (the transmitter and sensors combined). Graphic Screen Refers to the integral LCD display screen. Initial Makeup An internal process performed during installation, where the flow meter acquires its receive signal and enhances other parameters for optimal operation at a site. In-process Makeup An internal process where the flow meter recovers its Initial Makeup parameters after a fault condition interrupts operation.
  • Page 187 Glossary registers to address data which can be formatted in various types including, real, integer, & binary (coils). NEGFLOW Totalizer mode for negative flow total only. NETFLOW Totalizer mode that combines positive and negative flow totals. NOTOT System function that disables the internal Totalizer. Number Index Computed sensor spacing index based on the estimated sonic velocity measurement.
  • Page 188 Site Storage Memory to store configurable operating parameters such as pipe, liquid or gas tables. Si-Ware Siemens software program that interfaces with Siemens flow meters to assess flow meter installation conditions and to collect data for comparison with prior baseline data. Spacing Index Refers to the Number Index used by the flow meter to determine the space between the upstream and downstream sensors on clamp-on systems.
  • Page 189 Glossary Transducer Also known as sensor. Vaer The flow meter’s aeration percent output. The sonic propagation velocity of a pipe. The sonic velocity of a liquid or gas. F US Clamp-on Communications Protocol Manual Hardware Installation Manual, 11/2015, A5E34981613-AC...
  • Page 190 Glossary F US Clamp-on Communications Protocol Manual Hardware Installation Manual, 11/2015, A5E34981613-AC...

  • Page 191: Index

    Index firmware version, 67 Flowmeter Firmware Version, 15 Flowmeter Setup, 17 Address Selection: SW1-A (1-6), Analog Input Object, 30 HART, 37 HART Connections, 37 BACnet, 29 HART Installation, 37 BACnet Conformance Statement, 31 HART Setup procedure, 46 BACnet Object Tables, 29 History, 7 Baud Rate Selection: SW1-A (7-8) - To Network, Binary Input Object, 31...
  • Page 192 Index RS-485, 12 RS-485 Connector J1, 14 Safety Considerations and Ratings, 7 Troubleshooting Diagnostic procedures, 52 Typical Connection of F US flowmeter with HART F_US1010 Option, 47 Universal HART Commands, 38 Web Configuration, 61 F US Clamp-on Communications Protocol Manual Hardware Installation Manual, 11/2015, A5E34981613-AC...
  • Page 194 For more information www.siemens.com/flow Siemens Industry, Inc. Subject to change without prior notice Industry Automation Division Order No.: A5E34981613 Ultrasonic Flow Lit. No.: A5E34981613-AC Hauppauge, NY 11788 © Siemens 11.2015 www.siemens.com/processautomation...

Table of Contents
