March 2004
Chapter 1 — General
Instead of sending and receiving information to and from adjustable frequency drives
through I/O, you can connect them to a fieldbus.
Cutler-Hammer
using a fieldbus board. The drive can then be controlled, monitored and programmed from
the Host system.
If you purchase your DeviceNet Option Board separately, please note that the it shall be
installed in Slot E on the control board of the drive.
MN04003005E
®
9000X drives from Eaton Electrical
Internal components and circuit boards are at high potential when
the drive is connected to the power source. This voltage is
extremely dangerous and may cause death or severe injury if you
come into contact with it.
For more information visit: www.eatonelectrical.com
DeviceNet Option Board User Manual
®
can be connected to the DeviceNet
WARNING
1-1
