DeviceNet Features and Functionality

Table 2-2: DeviceNet Features and Functionality

Description
Network size
Network length
Data packets
Bus topology
Bus addressing
System features
2-2
Specification
Up to 64 nodes
Selectable end-to-end network distance varies with speed
Baud Rate
125 Kbps
250 Kbps
500 Kbps
0 – 8 bytes
Linear (trunk-line/drop-line); power and signal on the same network cable
Peer-to-peer with Multi-Cast (one-to-many); Multi-Master and Master/Slave
special case; polled or change-of-state (exception-based)
Removal and replacement of devices from the network under power
For more information visit: www.eatonelectrical.com
Distance
500m
250m
100m
