Chapter 2 — DeviceNet Option Board Technical Data

General

Table 2-1: DeviceNet Technical Data

Description
DeviceNet Connections
Interface
Data transfer method
Transfer cable
Electrical isolation
Communications
ODVA 2.0 Compliant
Baud rate
Product code
Product type
Vendor ID
Electrical
DeviceNet
Other
Environment
Ambient operating
temperature
Storing temperature
Humidity
Altitude
Vibration
Safety
MN04003005E
Specification
Pluggable connector (5.08 mm)
CAN
2 wire twisted shielded cable with 2 wire bus power
cable and drain
500V DC
125, 250 and 500 kBaud
0x02 (2)
0x02 (AC Drive)
0 x 1BB ()
Network supply voltage:
11 – 25V DC
Network input current:
28 mA typical, 125 mA inrush (24V DC)
All other power derived from inverter power supply
-10°C – 55°C
-40°C – 60°C
<95%, no condensation allowed
Max. 1000m
0.5G at 9 – 200 Hz
Fulfils EN 50178 standard
