I. DESCRIPTION AND SCOPE

Model C-CS is a pressure reducing regulator used to control down stream (outlet or P

sizes are 3/4" (DN20), 1" (DN25), 1-1/2" (DN40), 2" (DN50) and 3" (DN80) with Tri-Clamp

regulator is primarily designed for steam service at tem per a tures equal to or less than 366°F (185°C); this cor re sponds

to 150 psig (10.3 Barg) sat u rat ed steam; however, the unit may also be used for clean gaseous or liquid applications.

II. INSTALLATION

1. An inlet block valve should always be in stalled.

2. If service application is continuous such that

shutdown is not readily accomplished, it is

recommended that inlet and outlet block valves

and a manual bypass valve be in stalled.

3. An outlet pressure gauge should be lo cat ed

ap prox i mate ly ten pipe diameters down stream

and within sight.

4. All installations should include a down stream

re lief device if the inlet pressure could exceed

the pressure rating of any down stream

equip ment.

5. Flow Direction: Install so the flow enters

through the bottom connection and exits the

side connection.

6. Install in a well drained pipe, properly trapped,

with spring chamber (2) in the vertical position

to allow for proper drain ing.

III. PRINCIPLE OF OPERATION

1. Movement occurs as pressure variations

reg is ter on the diaphragm. The registering

pres sure is the outlet, P

pressure. The range spring opposes di a phragm

move ment. As the outlet pressure drops, the

range spring pushes the diaphragm down,

INSTALLATION, OPERATION, & MAINTENANCE MANUAL

MODEL C-CS

"CLEAN STEAM"

PRESSURE REDUCING REGULATOR

SECTION l

The Model C-CS should never be used as a shut-off device.

SECTION II

SECTION III

or down stream

CAUTION

Inlet

@ P

Model C-CS

Reducing Regulator

Blowdown Drain

(Recommended Piping Schematic for Pressure Reducing Station)

7. For insulated piping systems, the regulator

should not be insulated.

Installation of adequate overpressure protection

is recommended to protect the regulator from

overpressure and all downstream equipment from

damage in the event of regulator failure.

Do not apply spring load or operate regulator with

hitch pin (21) removed from top of guide post (27 ).

Pre ma ture di a phragm failure will re sult.

IOM-C-CS

12-16

) pressure. Inlet and outlet

fitting connections. This

Outlet

@ P

SRV

Bypass

Blowdown Drain

CAUTION
