7. State of each cell sensor (Red)
Shows the state of each individual cell. When a cell is obstructed, the equivalent LED is set "on". Each
LED "on" can have two intensity levels. An LED at half intensity shows an obstructed cell but means
that according to the minimum diameter, there are not enough consecutive LEDs obstructed to
activate the output. A total of 31 LEDs is present. In low resolution only 16 LEDs are functioning, one
of every two LED. The other stays "off" all the time. In medium resolution, all the 31 LEDs are
functioning. In coarse resolution, each LED is associated with two consecutive cells. When a cell is
cancelled the LED will flash 2 times per second until a reset cancellation is performed or the
cancellation is disabled.
