ScanMeg Inc.
Module SIM‐P
Analog output: 4‐20mA
The analog terminals are located on the top left side of the module.
The first analog 4‐20 mA output shows the dimension of the object
inside the field of view. The second analog output shows the position
of the object starting from the connector side of the sensor head.
User Manual
10
Version 1.3
