2.6 Component Data

Indoor Heat Exchanger and Fan
Model
Heat Exchanger Type
TubMaterial
Outer Diameter
Rows
Number of Tube/Coil
Fin Material
Pitch
Maximum Operating Pressure
Total Face Area
Number of Coil/Unit
Indoor Fan
Number/Unit
Outer Diameter
Nominal Air Flow
(Hi-Me-Lo)
Indoor Fan Motor
Starting Method
Nominal Output
Quantity
Insulation Class
TC-16004-rev.2
(H,Y,C)IDM030B21E
φin. (mm) 1/4 (7.0)
4
48
in. (mm) 0.071 (1.8)
psi (MPa) 601 (4.15)
3.20
2
ft
2 (0.30)
(m )
1
2
φin. 7-1/16
(180)
(mm)
1059-953-847
cfm
(30-27-24)
3
(m /min)
250
W
1
E
DUCTED MEDIUM STATIC (ECONOFRESH)
(H,Y,C)IDM036B21E
Multi-Pass Cross Finned Tube
Copper Tube
1/4 (7.0)
4
48
Aluminum
0.071 (1.8)
601 (4.15)
3.20
(0.30)
1
Multi-Blade Centrifugal Fan
2
7-1/16
(180)
1236-1094-988
(35-31-28)
Drip-Proof Type Enclosure
DC Motor
250
1
E
(H,Y,C)IDM048B21E
1/4 (7.0)
4
48
0.063 (1.6)
601 (4.15)
3.20
(0.30)
1
2
7-1/16
(180)
1271-1130-1024
(36-32-29)
250
1
E
2-5
