INVERTER-DRIVEN
MULTI-SPLIT SYSTEM
HEAT PUMP
AIR CONDITIONERS
Models:
Outdoor Units;
<208/230V >
Standard Type
(H,Y)VAH(P,R)072B31S, (H,Y)VAH(P,R)096B31S,
(H,Y)VAH(P,R)120B31S, (H,Y)VAH(P,R)144B31S,
(H,Y)VAH(P,R)168B31S, (H,Y)VAH(P,R)192B31S,
(H,Y)VAH(P,R)216B31S, (H,Y)VAH(P,R)240B31S,
(H,Y)VAH(P,R)264B31S, (H,Y)VAH(P,R)288B31S,
(H,Y)VAH(P,R)312B31S, (H,Y)VAH(P,R)336B31S,
(H,Y)VAH(P,R)360B31S
Less Module Type
(H,Y)VAH(P,R)240B31LM, (H,Y)VAH(P,R)336B31LM,
(H,Y)VAH(P,R)360B31LM
< 460V >
Standard Type
(H,Y)VAH(P,R)072B41S, (H,Y)VAH(P,R)096B41S,
(H,Y)VAH(P,R)120B41S, (H,Y)VAH(P,R)144B41S,
(H,Y)VAH(P,R)168B41S, (H,Y)VAH(P,R)192B41S,
(H,Y)VAH(P,R)216B41S, (H,Y)VAH(P,R)240B41S,
(H,Y)VAH(P,R)264B41S, (H,Y)VAH(P,R)288B41S,
(H,Y)VAH(P,R)312B41S, (H,Y)VAH(P,R)336B41S,
(H,Y)VAH(P,R)360B41S
Less Module Type
(H,Y)VAH(P,R)240B41LM, (H,Y)VAH(P,R)336B41LM,
(H,Y)VAH(P,R)360B41LM
IMPORTANT:
READ AND UNDERSTAND
THIS MANUAL BEFORE
USING THIS HEAT PUMP
AIR CONDITIONER.
KEEP THIS MANUAL FOR
FUTURE REFERENCE.
P00796Q
