Dip Switches Settings - Johnson Controls (H,Y,C)IDM012B21S Installation And Maintenance Manual

8.5

DIP Switches Settings

(1) Turn OFF the power supply to both indoor and outdoor units before adjusting DIP switch settings.
Otherwise, the setting will be invalidated and not take effect.
(2) Positions of DIP switches are shown below.
(3) Unit No. Setting
Setting is not required.
Indoor unit numbers are set by the auto-address
function. If an indoor unit number setting is
required, set the unit number of all indoor units
respectively and sequentially by following setting
position. It is recommended that you assign a
number to each indoor unit from "1". A maximum
of 64 indoor units per refrigerant cycle can be
connected to an H-LINK ll System. Though the
available numbers range from zero to 63, the
applicable number for the 64
theory supplants the number "zero".
For the centralized control, this setting is
required.
(4) Capacity Code Setting (DSW3)
No setting is required, due to setting before shipment. This switch is utilized for setting the capacity
code which corresponds to the capacity of the indoor unit.
Indoor Unit Capacity
(kBtu/h)
Setting Position
Indoor Unit Capacity
(kBtu/h)
Setting Position
(5) Unit Model Code Setting (DSW4)
No setting is required. It is for setting the model code of the indoor unit.
28
th
indoor unit in
06 08
ON ON
1 2 3 4 5 6 1 2 3 4 5 6
OFF OFF
24 30
ON ON
1 2 3 4 5 6
1 2 3 4 5 6
OFF OFF
DSW7 DSW4
ON
ON
1 2
1 2 3 4
ON
DSW3
1 2 3 4 5 6
ON
DSW9
1 2
ON
DSW8
1 2 3
SW1
Unit No. Setting
DSW6 (Tens Digit)
ON
OFF
1 2 3 4 5 6
Before shipment, DSW6 and RSW1 are set at "0".
For the units supporting H-LINK II,
the unit No. can be set for Max. 64 indoor units
(No.0~63).
12 15
ON ON
1 2 3 4 5 6
1 2 3 4 5 6
OFF OFF
36 48
ON ON
1 2 3 4 5 6 1 2 3 4 5 6
OFF OFF
DSW5 RSW2
ON 0
1 2 3 4 5 6
ON
0
1 2 3 4 5 6
DSW6
RSW1
RSW1 (Units Digit)
Ex.) Set at No.16 Unit
Setting Set by inserting
Position slotted screwdriver
into the groove.
0
Set No.1 Pin at ON side
18
ON
1 2 3 4 5 6
OFF
ON
1 2 3 4
OFF
P00792Q-rev.2
DSW6
ON
OFF
1 2 3 4 5 6
RSW1
0
Set at "6"
