Year of Manufacture:
Assembly, Operating, and Maintenance Instructions
For Vastex Autoflash Attachment with Touch Screen Controls
Contents
•
Introduction / Safety
•
Spec Tag Info
•
Stand Assembly
•
Component Identification
•
Assembly
•
Controls / Operation
•
Maintenance
•
Troubleshooting
•
Warranty / Terms & Conditions
•
CE Declaration
Electrical Drawing #:
Serial Number:
VTX
(Please log your machine's serial number and date of purchase for future reference.)
Autoflash
Page#
2-3
4
5-6
7
7-8
9
10
10
11
12
Rev:______
/
/
Date:____
____
______
Original Instructions
Vastex International, Inc.
7 Emery St
Bethlehem, Pa. 18015 USA
Phone# 610 625-2702 Fax# 610 625-2775
Web Site www.vastex.com
Authorized Representative in Europe:
Certification Experts BV
Nieuwstad 100 1381 CE Weesp,
The Netherlands
Tel : + 31 (0) 294 – 48 33 55
Fax : + 31 (0) 294 – 41 46 87
Vastex E-mail assistance
Purchasing & Product Info:
sales@vastex.com
Electrical Support:
stech@vastex.com
Tech Support, Mechanical Setup, and Operation:
techsupport@vastex.com
Doc. # 01-03-038

Advertisement

loading
Need help?

Need help?

Do you have a question about the Autoflash and is the answer not in the manual?

Questions and answers

Related Manuals for VASTEX Autoflash

Summary of Contents for VASTEX Autoflash

  • Page 1 Year of Manufacture: Doc. # 01-03-038 Original Instructions Autoflash Assembly, Operating, and Maintenance Instructions For Vastex Autoflash Attachment with Touch Screen Controls Contents Page# • Introduction / Safety Vastex International, Inc. 7 Emery St • Spec Tag Info Bethlehem, Pa. 18015 USA •...
  • Page 2 • VASTEX Autoflash attachment is for use on Vastex Flash units in accordance to the language in this manual. Do not use for any other purpose unless authorized by Vastex International, Inc. Use of this equipment for any other purpose can be danger- ous and may cause damage to this equipment, voiding the warranty.
  • Page 3 Do not store items, especially food or drink, on the top of your Vastex equipment. • The room that you are operating your Autoflash in should be adequately ventilated. Please refer to the MSDS sheet of the ink you are flashing/curing.
  • Page 4 Please read and understand your Flash Head manual before attempting to use or assemble this Autoflash Attachment. Flash head manuals can be found at www.vastex.com or call us to have one emailed/mailed to you directly. This manual only covers the assem- bly, operation, and maintenance of your Autoflash Attachment.
  • Page 5 Assembly (SHHD-STAND) Remove all parts from the box they were shipped in. Place Legs and Middle on floor as shown. Note hole in left leg for orientation. Install and Tighten -(16) #14 Sheet Metal Screws Use 3/8 Socket or Wrench Install and Tighten (4x) -Attach Wheel and Stud to each bracket with 1/2”...
  • Page 6 Assembly (SH-STAND) Install and Leave Loose -(2) Legs -(2) 1/4” Bolts and Nuts Note Orientation of legs Install and Leave Loose -(1) Leg -(2) 1/4” Bolts and Nuts Install and Leave Loose -(1) Leg -(4) 1/4” Bolts and Nuts Install and Tighten -(4) Wheels with studs -(4) 3/8”...
  • Page 7 Min Height: 32" With Levelers Max Height: 40" Min Height : 30" Foot Pedal Select home position Installing AutoFlash Unit on to SHHD Stand -Orientation is based on user operation Flash Flash Operator Operator 1)Loosen 3/8 bolts with 9/16 wrench...
  • Page 8 9/16 wrench. 6) Install pitch knob and tighten until flash head is level to your pallet. 7) Plug in your Autoflash and Flash head. Refer to wiring diagram and Flash Head manual. Do Not position the flash head over the control box when in the home position.
  • Page 9 Select appropriate home Position • Set Dwell time with Arrows -See Pg 7 for desired orientation • Press Go to Operate • After pressing go, AutoFlash is • Displays remaining Dwell Time. ready to run. • Press Cancel to return to home •...

  • Page 10: Maintenance And Troubleshooting

    In the event of a malfunction or breakdown: Shut off power to the equipment and unplug from electrical outlet. Then, following the trouble- shooting charts below. If this does not resolve your issue, please contact Vastex for support. Troubleshooting Chart—Additional Considerations for AutoFlash Units:...
  • Page 11 The defective part or parts will be repaired or replaced at the discretion of Vastex International, Inc. If the equipment in question is less than one (1) year old, it will be shipped to the customer at no charge, with an RGA issued by Vastex for the defective part. The defective part must be shipped back to Vastex freight prepaid within 30 days or the account will be billed.
