Springfree R132 Installation And User Manual page 8

5
INSIDE VIEW
A B
Inside Person: Locate the ends of the cables that are hanging down at cable clip
the le and have the YELLOW tag. Cable
Inside Person: Next, locate the yellow strip along the top edge of the sensor cable tube. At the yellow strip, feed
cable (YELLOW) through the top of the tube until it comes out the end.
A
Inside Person: Repeat with cable
socket on the back of the controller and tighten the collar. Then, plug the end of cable
B
and tighten.
NOTE - Cable
sockets are designed to only fit one way. Line up the green post in the cable plug with the slot in the controller
socket. Do not force or twist the plug into the socket; when you have correctly aligned them, they will slide
together easily.
Inside Person: Undo the Velcro® strip on the sensor cable tube, wrap it around the mat rod, and refasten, as shown.
Inside Person: Next, locate the eyelets along the top edge of the sensor cable tube. Pass a small cable tie through
the eyelet and the hole in the cable clip, as shown, then fasten. Repeat for both eyelets.
Inside Person: Fasten the strap at the bottom of the sensor cable tube through the back of the controller.
The remaining steps can be completed by just one person.
WARNING - If there is any excess cable, loop it and tuck it back up into the sensor cable tube.
8
INSIDE VIEW
B
A
B should be on the right and have the WHITE tag.
(WHITE). When the end of the cable comes out the end of the tube, plug it into
B
A must be plugged into socket
A B
A
A
B
A and cable B into socket
INSIDE VIEW
A B
A B
B
B
and . Cable should be on
A B A
(YELLOW) into socket
A
B . The cable plugs and controller
A
