Springfree R132 Installation And User Manual page 4

1
A
B
C
Part
A
Tablet Holder Rods
B Sensor Cables
C
Tablet Holder
D Sensor Cable Tube
E
Controller
F Battery Pack
G
Sensor Top Plate
NOTE - TWO people are required for assembly.
NOTE - Installation typically takes ONE hour to complete.
Layout all parts listed as shown.
TIP - Throughout this manual, certain images contain parts that have been colored orange. This is meant
to bring specific attention to a particular installation step and is not a representation of their actual color.
SCAN HERE or visit http://springfr.ee/install-tgoma for a helpful installation video.
4
E
B
F
D
Description Part
H
1 Sensor Mount
2 I Cable Clips
J
1 Nut and Hex Key
K Large Cable Ties
1
L
1 Small Cable Ties
M Spare Small Cable Ties and Cable Clips
1
4
G I
J
H
K
L
Description
4
54
1
2
10
8+4
