Springfree R132 Installation And User Manual page 7

TOP VIEW
3
2
TIP - If you are having trouble inserting the cable sensors into the sensor mounts, try flipping them over.
They are designed to only fit one way.
Inside Person: Before installing the cables, note that they are di erent lengths and have di erent color labels.
Inside Person: Starting at sensor position
place. Take the cable with the WHITE tag and install the end cable sensor into the sensor mount. Once it is in place,
fasten with new cable ties as shown.
Inside Person: Then, working towards sensor position
Inside Person: At sensor position
ties.
Inside Person: Continue installing the cable into the cable clips until you reach position
the end of the cable hanging down near the controller.
Inside Person: Starting at sensor position
sensor position and then to position
1
4
A
1
, carefully cut the cable ties that are currently holding the sensor in
3
, install the cable into each cable clip, as shown.
2
, install the middle cable sensor into the sensor mount and fasten the cable
2
, take the cable with the YELLOW tag and repeat the above process to
4
. Be sure to fasten the cable ties at each sensor.
A
INSIDE VIEW
A B
B
3
as shown above. Leave
B
4
7
