selecting a location
Consider these points as you choose the location for your hu-
midifier.
Locate humidifier on supply air plenum (Fig. 1) or return air
plenum. If the humidifier is installed on the return air plenum,
the flexible hose, round opening, is connected to the supply air
plenum.
If furnace is equipped with air conditioning,
humidifier should
be mounted above or at slope side of "A" coil to avoid possible
splashing (Fig. 2) of water in reservoir.
Humidifier should be installed so that if the humidifier or any
other connections should leak, the resulting flow of water will
not cause damage. Under no condition is Sears and the manu-
facturer to be held liable for any water damage in connection
with this humidifier. Never install humidifier in attic or crawl space
where freezing may occur or leaking
If holes between supply air plenum and return air
be located more than 36 inches apart (Fig. 1),
round pipe and fittings (not supplied)
section
of flexible tube No. 281152-05
through the Sears
type installation are available at Sears.
)urchased
for this
Supply
9 inch minimum
Air
36 inch maximum
using flex
Plenum
hose provided*
(Warm to
Touch
* Purchase additional
During
hose for greater spans.
Heating
Return Air
Plenum
Furnace
Supply
Plenum
Place Humidifier
Duct
Air Conditioner Coil
inspection
This humidifier is a_molea
with the bypass d_t" on the left
side (Fig. 3)._is
is suitable
for install p_on
as shown
in
Fig. l:._is
is suitable for your
inst_ation,
remove parts as
_wn
under Disassembly.
f_Sl_lp
conversion
steps A, B,
f_
and IX Start your installation
with
C and then skip to [] 1.
If you require the bypass duct
on the right (Fig. 4), remove
parts as shown under Disas-
sembly and start with A.
AS RECEIVED
(Left Hand Flange)
"-U
Bypass Duct
AS CONVERTED
MT
Bypas
l
l
otor
(Right Hand Flange)
disassembly
I=l[e'l.3
Remove front cover. Lift top cover to lock position.
Pull pivot pin and remove float assembly from valve.
Lift out media wheel.
Remove water reservoir.
conversion- (,f
r equired-
see "inspection"
above)
A
Pull motor bracket and wire bearing support to remove
from lances (Fig. 5).
Motor Bracket Top Flange-
Pull Up--7
-Wire Bearing Support -- Pull Up
/
,Top Cover
_
-Lances
Wire Support
4
