human care Altair Quick Reference Manual

Quick Reference Guide
– Altair
Description
The Human Care Altair overhead lift is a lightweight portable lift with a discreet and modern design. Its portability ensures that asset investment is
greatly reduced as the same lift easily can be used in multiple rooms. The Altair features an advanced technology platform that allows tracking of lift
usage and visualization of collected data. Altair features a unique telescoping hanger bar that offers different widths in one product to fit any patient and
resulting in a comfortable sitting position. The lift is available in three weight capacities, 150kg, 220kg and 300kg, and can be used with either a 2, 3 or
4-point suspension.
Using the lift
Select and position sling Attach the head sling loops to
around the patient according carry bar first, than leg straps
to sling instructions. to leg hooks.
Use hand control to position
carry bar directly above the
patient.
Helpful Troubleshooting Tips!
The lift will not work while plugged in and/or if emergency stop is engaged
Part no:
Altair 150kg/330lbs:
North America: 550030-NA
Europe: 55030-EU
Australia: 55030-AU
Great Britain: 55030-GB
Japan: 55030-JP
Altair 220kg/484lbs:
North America: 55040-NA
Europe: 55040-EU
Australia: 55040-AU
Great Britain: 55040-GB
Japan: 55040-JP
Altair 300kg/661lbs:
North America: 55050-NA
Europe: 55050-EU
Australia: 55050-AU
Great Britain: 55050-GB
Japan: 55050-JP
Raise the patient (up on hand
control) and as raises check
to ensure straps are firmly
in place.
Telescopic
hanger bar
Indicator
Leg
hook
Raise the patient up until
obstacles are clear, hold sling
and position/move patient as
needed.
Page 1
Lift belt
Hand control
Emergency lowering
button
Emergency stop
Secondary
control panel
Lower patient (down on hand
control) until in desired posi-
tion. Continue to lower until
all straps are slack to remove
www.humancaregroup.com
