human care FL180 Quick Reference Manual

Quick Reference Guide
– FL180
Description
The FL180 is a stable and flexible floor lift that can be used in all types of lifting situations. It allows lifting from high surfaces, such as a chair, bed, wheel-
chair or commode, in addition to lifting from the floor. Easy to maneuver and transport, store and set up, the FL180 has everything you need in a floor lift.
Its base can be adjusted electrically or manually for greater flexibility. The floor lift also has manual or electrical emergency lowering.
Using the lift
Select and position sling around the
patient according to sling instructions.
Use hand control to position carry bar
directly above the patient.
Helpful Troubleshooting Tips!
If lift is NOT working, make sure unit is unplugged but has
charge and emergency stop button is not engaged.
Part no:
FL180 kit North America: 70967-NA
FL180 kit Australia: 70967-AU
FL180 kit Great Britain: 70967-GB
FL180 kit Japan: 70967-JP
FL180 kit Europe: 70967-EU
Attach the head sling loops to carry
bar first, than leg straps to leg hooks.
Hand
control
Drive handle
Battery
Emergency
stop
Raise the patient (up on hand control)
and as raises check to ensure straps
are firmly in place. Raise the patient
up until obstacles are clear, hold sling
and position/move patient as needed.
Page 1
Lifting arm
Hanger bar
Actuator
Legs
Lower patient (down on hand control)
until in desired position. Continue
to lower until all straps are slack to
remove
www.humancaregroup.com
