Installation Instructions
ControlNet Modular Repeater
Short-distance Fiber Module
Catalog Number 1786-RPFS
Topic
About the Module
Use the 1786-RPFS module when you need a short-distance fiber link between
two ControlNet products. Maximum distance is 300 m (984 ft). The fiber link
provides ground isolation between nodes and is less susceptible to noisy
environments than copper media.
The supported distance depends on the quality of the fiber,
IMPORTANT
number of splices, and connectors. The total light loss through
the fiber link must be less than 4.2 dB.
Page
2
3
4
5
6
6
10
11
12
16

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 1786-RPFS and is the answer not in the manual?

Questions and answers

Related Manuals for Allen-Bradley 1786-RPFS

Summary of Contents for Allen-Bradley 1786-RPFS

  • Page 1: Table Of Contents

    Additional Resources About the Module Use the 1786-RPFS module when you need a short-distance fiber link between two ControlNet products. Maximum distance is 300 m (984 ft). The fiber link provides ground isolation between nodes and is less susceptible to noisy environments than copper media.

  • Page 2: Important User Information

    2 ControlNet Modular Repeater Short-distance Fiber Module Important User Information Solid-state equipment has operational characteristics differing from those of electromechanical equipment. Safety Guidelines for the Application, Installation and Maintenance of Solid State Controls (Publication SGI-1.1 available from your local Rockwell Automation sales office or online at http://www.rockwellautomation.com/literature/) describes some important differences between solid-state equipment and hard-wired electromechanical devices.

  • Page 3: Environment And Enclosure

    ControlNet Modular Repeater Short-distance Fiber Module 3 Environment and Enclosure ATTENTION: This equipment is intended for use in a Pollution Degree 2 industrial environment, in overvoltage Category II applications (as defined in IEC publication 60664-1), at altitudes up to 2000 m (6562 ft) without derating. This equipment is considered Group 1, Class A industrial equipment according to IEC/CISPR Publication 11.

  • Page 4: North American Hazardous Location Approval

    4 ControlNet Modular Repeater Short-distance Fiber Module North American Hazardous Location Approval The following information applies Informations sur l’utilisation de cet when operating this equipment in équipement en environnements hazardous locations. dangereux. Products marked "CL I, DIV 2, GP A, B, C, D" are Les produits marqués "CL I, DIV 2, GP A, B, C, D"...

  • Page 5: European Hazardous Location Approval

    ControlNet Modular Repeater Short-distance Fiber Module 5 European Hazardous Location Approval European Zone 2 Certification (The following applies when the product bears the Ex Marking.) This equipment is intended for use in potentially explosive atmospheres as defined by European Union Directive 94/9/EC and has been found to comply with the Essential Health and Safety Requirements relating to the design and construction of Category 3 equipment intended for use in potentially explosive atmospheres, given in Annex II to this Directive.

  • Page 6: Module Components

    Both sides of the module contain a backplane connector. Mount the Module Mount the module on a 35 x 7.5 mm (1.38 x 0.30 in.) DIN rail, Allen-Bradley part number 199-DR1, 46277, EN 50022. ATTENTION: This product is grounded through the DIN rail to chassis ground.
  • Page 7 ControlNet Modular Repeater Short-distance Fiber Module 7 Mounting Dimensions (4.44) (2.76) (4.0) 96.8 (3.87) (3.6) 30082 All dimensions are in mm (in.). 1. Position the module at a 30 ° angle. 30075 2. Hook the lip on the back of the module to the top of the DIN rail and press the bottom of the module until the locking tab snaps securely in place.
  • Page 8 8 ControlNet Modular Repeater Short-distance Fiber Module WARNING: If you insert or remove the module while backplane power is on, an electrical arc can occur. This could cause an explosion in hazardous location installations. Be sure that power is removed or the area is nonhazardous before proceeding.
  • Page 9 ControlNet Modular Repeater Short-distance Fiber Module 9 Then You will use a channel Remove the protective cap from the channel. You will not use a channel Keep the protective cap on to protect the channel from dust. You place the module in storage Keep the protective cap on to protect the channel from dust.

  • Page 10: Connect The Fiber Module

    10 ControlNet Modular Repeater Short-distance Fiber Module Connect the Fiber Module This module requires a pre-terminated zipcord wiring kit. The kits are offered in a variety of lengths. Consult with your local distributor for attenuation specifications before you purchase your fiber media components. The zipcord uses a duplex cable that contains two separate fibers, one for transmit and one for receive.

  • Page 11: Troubleshoot The Module

    ControlNet Modular Repeater Short-distance Fiber Module 11 ATTENTION: Under certain conditions, viewing the optical port may expose the eye to hazard. When viewed under some conditions, the optical port may expose the eye beyond the maximum permissible exposure recommendations Troubleshoot the Module Use the channel 1 or 2 status indicators to check module status and troubleshoot the module.

  • Page 12: Specifications

    12 ControlNet Modular Repeater Short-distance Fiber Module Specifications Technical Specifications - 1786-RPFS Attribute Value All supply voltages or voltage ranges Backplane: 5V DC, 300 mA Dissipation Communication rate 5 Mbps Mounting orientation Any mounting orientation Minimum enclosure size (HxWxD), approx 304.8 x 196.8 x 101.6 mm...
  • Page 13 ControlNet Modular Repeater Short-distance Fiber Module 13 Technical Specifications - 1786-RPFS Attribute Value Enclosure type rating None (open-style) North American temp code IEC temp code (1) This includes all loss associated with the fiber link, including splices, fiber attenuation, bulkhead connectors, and the ST terminations.
  • Page 14 14 ControlNet Modular Repeater Short-distance Fiber Module Environmental Specifications - 1786-RPFS Attribute Value Shock, operating 30 g IEC60068-2-27 (Test Ea, Unpackaged Shock) Shock, nonoperating 50 g IEC60068-2-27 (Test Ea, Unpackaged Shock) Emissions Group 1, Class A CISPR 11 ESD immunity...
  • Page 15 ControlNet Modular Repeater Short-distance Fiber Module 15 Certifications - 1786-RPFS Certification Value European Union 2004/108/EC EMC Directive, compliant with: • EN 61326-1; Meas./Control/Lab., Industrial Requirements • EN 61000-6-2; Industrial Immunity • EN 61000-6-4; Industrial Emissions • EN 61131-2; Programmable Controllers (Clause 8, Zone A &...

  • Page 16: Additional Resources

    RA-DU002, available at http://www.rockwellautomation.com/literature/ Allen-Bradley, Rockwell Software, Rockwell Automation, and TechConnect are trademarks of Rockwell Automation, Inc. Trademarks not belonging to Rockwell Automation are property of their respective companies. Rockwell Otomasyon Ticaret A.Ş., Kar Plaza İş Merkezi E Blok Kat:6 34752 İçerenköy, İstanbul, Tel: +90 (216) 5698400...
