FANATEC CSL Elite Wheel Base Manual page 39

Problem description
The tuning display does not show anything or is
not working partially.
Center calibration with Universal Hub is not work-
ing because of missing d-pad / sticks.
After switching on the CSL Elite Wheel Base the
auto calibration is not working properly.
After playing a while the CSL Elite Wheel Base
seems to become weaker or is fading.
After playing a while the CSL Elite Wheel Base
motor has switched OFF.
Fans are always working in full speed even if
ClubSport Wheel Base just was switched ON and
cannot have higher temperatures.
After calibration run at startup of CSL Elite Wheel
Base the attached steering wheel doesn't go to
correct center position.
Some of the tuning menu settings are not availa-
ble on Xbox One and cannot adjust.
39
Solution
Try to use another Steering Wheel. If this is also
not working properly the CSL Elite Wheel Base
might be damaged.
Check the pins inside the quick release of the
Steering Wheel, these must not be bent or
damaged.
For the CSL Steering Wheel P1 for Xbox One, for
Universal Hub and for Universal Hub for Xbox
One there is a different button combination than
for other Fanatec Steering Wheels. See descrip-
tion in chapter 'Hot- keys' of this user manual as
well as the user manual for the Universal Hub.
Make sure that you have updated your CSL Elite
Wheel Base to the latest firmware version which
can be downloaded from www.fanatec.com/sup-
port.
When the motor temperature is close to upper
limit the tuning menu values will be overwritten to
regular maximum values (not higher than 100 %).
Additionally the motor power level is controlled by
firmware so that the FFB strength may fade in this
high temperature range but the motor will not be
damaged. This allows extending the duration of
driving before the motor has to completely stop
operating to calm down.
Let your CSL Elite Wheel Base calm down be-
fore continue using it.
When the temperature is exceeding the upper lim-
it the motor will be deactivated for a while until the
temperature is low enough (to protect the hard-
ware from damages).
Let your CSL Elite Wheel Base calm down be-
fore continue using it. Contact our customer sup-
port if this happens consecutively.
In case of malfunctioning temperature sensor the
fans are working at maximum speed to protect the
hardware from overheat. Please contact our cus-
tomer support.
Please check your tuning menu settings, the value
for SPR (spring) must be higher than '000' as this
effect is required to make correct centering. De-
fault value is '100'.
As the Xbox One uses a different FFB effect sys-
tem the parameters SPR, FOR and DPR cannot
be adjusted separately within this system. The
only option is the adjustment of the overall FFB
strength by parameter FF.
